DTC P0705 PARK/NEUTRAL POSITION SWITCH AT-111 D E F G H I J K L M A B AT 2006 Pathfinder DTC P0705 PARK/NEUTRAL POSITION SWITCH PFP:32006 Description ECS00EG0 ● The park/neutral position (PNP) switch includes a transmission position switch. ● The transmission range switch detects the selector lever position and sends a signal to the TCM. CONSULT-II Reference Value ECS00EG1 On Board Diagnosis Logic ECS00EG2 ● This is an OBD-II self-diagnostic item. ● Diagnostic trouble code “P0705 PNP SW/CIRC” with CONSULT-II or 9th judgement flicker without CON- – When TCM does not receive the correct voltage signal from the PNP switch 1, 2, 3, 4 based on the gear – When no other position but “P” position is detected from “N” positions. Possible Cause ECS00EG3 ● Harness or connectors ● Park/neutral position (PNP) switch 1, 2, 3, 4 DTC Confirmation Procedure ECS00EG4 CAUTION: Always drive vehicle at a safe speed. NOTE: WITH CONSULT-II 1. Turn ignition switch “ON”. (Do not start engine.) 2. Select “DATA MONITOR” mode for “ENGINE” with CONSULT-II. 3. Start engine. 4. Drive vehicle and maintain the following conditions for at least 2 5. If DTC is detected, go to AT-113, "Diagnostic Procedure" WITH GST Follow the procedure “WITH CONSULT-II”. Item name Condition Display value SLCTLVR POSI Selector lever in “N”,“P” positions. N/P Selector lever in “R” position. R Selector lever in “D” position. D Selector lever in “3” position. 3 Selector lever in “2” position. 2 Selector lever in “1” position. 1 BCIA0030E |
