A/C AUTO AMP.

HAC-213

< ECU DIAGNOSIS >

[WITH 7 INCH DISPLAY]

C

D

E

F

G

H

J

K

L

M

A

B

HAC

N

O

P

*: Perform self-diagnosis under sunshine. When performing indoors, aim a light (more than 60 W) at sunload sensor, otherwise self-diag-
nosis indicates even though the sunload sensor is functioning normally.

WITH INTELLIGENT AIR CONDITIONER SYSTEM

WITH INTELLIGENT AIR CONDITIONER SYSTEM : Reference Value

INFOID:0000000003884794

VALUES ON THE DIAGNOSIS TOOL

CONSULT-III MONITOR ITEM

TERMINAL LAYOUT

B2634

PASS AIRMIX ACTR (SHORT)

HAC-183, "DTC Logic"

B2635

PASS AIRMIX ACTR (OPEN)

HAC-183, "DTC Logic"

B2636

DR VENT DOOR FAIL

HAC-185, "DTC Logic"

B2637

DR B/L DOOR FAIL

HAC-185, "DTC Logic"

B2638

DR D/F1 DOOR FAIL

HAC-185, "DTC Logic"

B2639

DR DEF DOOR FAIL

HAC-185, "DTC Logic"

B263D

FRE DOOR FAIL

HAC-188, "DTC Logic"

B263E

20P FRE DOOR FAIL

HAC-188, "DTC Logic"

B263F

REC DOOR FAIL

HAC-188, "DTC Logic"

B2654

D/F2 DOOR FAIL

HAC-185, "DTC Logic"

B2655

B/L2 DOOR FAIL

HAC-185, "DTC Logic"

B2656

BTC FRE DOOR FAIL

HAC-188, "DTC Logic"

DTC

Items

(CONSULT-III screen terms)

Reference

Monitor item

Condition

Value/Status

COMP REQ SIG

Engine: Run at idle after
warming up

A/C switch: ON
(Compressor operation sta-
tus)

On

A/C switch: OFF

Off

FAN REQ SIG

Engine: Run at idle after
warming up

Blower fan: ON

On

Blower fan: OFF

Off

AMB TEMP SEN

Ignition switch ON

—



−

30 - 55

°

C (

−

22 - 131

°

F)

IN-VEH TEMP

Ignition switch ON

—



−

30 - 55

°

C (

−

22 - 131

°

F)

INT TEMP SEN

Ignition switch ON

—



−

30 - 55

°

C (

−

22 - 131

°

F)

SUNLOAD SEN

Ignition switch ON

—

0 - 1045 W/m

2

(0 - 900 kcal/m

2

·h)

AMB SEN CAL

Ignition switch ON

—

−

30 - 55

°

C (

−

22 - 131

°

F)

IN-VEH CAL

Ignition switch ON

—

−

30 - 55

°

C (

−

22 - 131

°

F)

INT TEMP CAL

Ignition switch ON

—

−

30 - 55

°

C (

−

22 - 131

°

F)

SUNL SEN CAL

Ignition switch ON

—

0 - 1045 W/m

2

(0 - 900 kcal/m

2

·h)

FAN DUTY

Engine: Run at idle after
warming up

Blower fan: ON

21 - 91%

Blower fan: OFF

0%

XM

Ignition switch ON

—

−

100 - 150

ENG COOL TEMP

Ignition switch ON

—

Values according to coolant
temperature

VEHICLE SPEED

Driving

—

Equivalent to speedometer
reading

HAC-214

< ECU DIAGNOSIS >

[WITH 7 INCH DISPLAY]

A/C AUTO AMP.

PHYSICAL VALUES

JSIIA1205ZZ

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

−

Signal name

Input/

Output

10

(L/R)

Ground

LAN signal

Input/

Output

—

11

(L/W)

Ground

Power supply for each door
motor

Input

Ignition switch ON

Battery voltage

12

(O)

Ground

ION ON/OFF signal

Output

Blower fan ON

0 V

Blower fan OFF

12 V

14

(G)

Ground

Gas sensor signal

Input

NOTE:
The signal is different by mea-
surement environment of a ve-
hicle

15

(O)

Ground

Sunload sensor signal

Input

—

—

16

(R/G)

Ground

Intake sensor signal

Input

—

—

17

(V/W)

Ground

ACC Power supply

—

Ignition switch ACC

Battery voltage

19

(B)

Ground

Ground

—

Ignition switch ON

0 V

20

(G/W)

Ground

IGN Power supply

—

Ignition switch ON

Battery voltage

28

(G/Y)

Ground

Ion control mode output sig-
nal

Output

Clean mode

12 V

Ion control mode

0 V

SJIA1453J

ZJIA1163J

A/C AUTO AMP.

HAC-215

< ECU DIAGNOSIS >

[WITH 7 INCH DISPLAY]

C

D

E

F

G

H

J

K

L

M

A

B

HAC

N

O

P

WITH INTELLIGENT AIR CONDITIONER SYSTEM : Wiring Diagram - AIR CONDI-

32

(L/Y)

Ground

Blower motor control signal

Output

• Ignition switch ON
• Blower speed: 1st speed

(manual)

34

(P)

Ground

A/C auto amp. connection
recognition signal

Output

Ignition switch ON

5V

35

(O/B)

Ground

Ambient sensor signal

Input

—

—

36

(LG)

Ground

In-vehicle sensor signal

Input

—

—

37

(B/Y)

Ground

Sensor ground

—

Ignition switch ON

 0 V

39

(B)

Ground

Ground

—

Ignition switch ON

 0 V

40

(Y/R)

Ground

BATT Power supply

—

Ignition switch OFF

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

−

Signal name

Input/

Output

JSIIA0096ZZ

HAC-216

< ECU DIAGNOSIS >

[WITH 7 INCH DISPLAY]

A/C AUTO AMP.

TIONER CONTROL SYSTEM -

INFOID:0000000003941767

JCIWM0211GB
