EXL-78

< COMPONENT DIAGNOSIS >

[XENON TYPE]

REAR FOG LAMP CIRCUIT

4.

CHECK REAR FOG LAMP SHORT CIRCUIT

Check continuity between BCM harness connector and ground.

Does continuity exist?

YES

>> GO TO 5.

NO

>> Repair the harnesses or connectors.

5.

CHECK REAR FOG LAMP GROUND OPEN CIRCUIT

Check continuity between rear fog lamp harness connector and ground.

Does continuity exist?

YES

>> Replace the rear fog lamp.

NO

>> Repair the harnesses or connectors.

BCM

Ground

Continuity

Connector

Terminal

M120

24

Not existed

Rear fog lamp

Ground

Continuity

Connector

Terminal

B70

2

Existed

HEADLAMP SYSTEM

EXL-79

< COMPONENT DIAGNOSIS >

[XENON TYPE]

C

D

E

F

G

H

I

J

K

M

A

B

EXL

N

O

P

HEADLAMP SYSTEM

Wiring Diagram - HEADLAMP -

INFOID:0000000003773582

JCLWM1437GB

EXL-80

< COMPONENT DIAGNOSIS >

[XENON TYPE]

HEADLAMP SYSTEM

JCLWM1438GB

HEADLAMP SYSTEM

EXL-81

< COMPONENT DIAGNOSIS >

[XENON TYPE]

C

D

E

F

G

H

I

J

K

M

A

B

EXL

N

O

P

JCLWM1439GB
