SEC-152
< ECU DIAGNOSIS >
[INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
39
(BR/W)
Ground
Rear bumper anten-
na (+)
Output
When the trunk lid
opener request
switch is operat-
ed with ignition
switch OFF
When Intelligent Key is in
the antenna detection
area
When Intelligent Key is
not in the antenna detec-
tion area
47
(BR/W)
Ground
Ignition relay (IPDM
E/R) control
Output
Ignition switch
OFF or ACC
Battery voltage
ON
0 V
50
(W)
Ground
Trunk room lamp
switch
Input
Trunk room lamp
switch
OFF (When trunk lid clos-
es)
11.8 V
ON (When trunk lid
opens)
0 V
52
(R)
Ground
Starter relay control
Output
Ignition switch
ON
When selector lever is in
P or N position
Battery voltage
When selector lever is
not in P or N position
0.3 V
Ignition switch OFF
0 V
61
(G/R)
Ground
Trunk lid request
switch
Input
Trunk lid request
switch
ON (Pressed)
0 V
OFF (Not pressed)
1.0 V
64
(GR)
Ground
Request switch
buzzer
Output
Request switch
buzzer
Sounding
0 V
Not sounding
Battery voltage
Terminal No.
(Wire color)
Description
Condition
Value
(Approx.)
Signal name
Input/
Output
+
–
