Nissan Teana J32. Manual - part 77





AV

CAMERA CONTROL UNIT

AV-163

< ECU DIAGNOSIS >

[BASE AUDIO AND DISPLAY SYSTEM]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

NOTE:
The name MULTIFUNCTION SWITCH indicates the integration of PRESET SWITCH and MULTIFUNCTION
SWITCH virtually.

JCNWM0896GB

AV-164

< SYMPTOM DIAGNOSIS >

[BASE AUDIO AND DISPLAY SYSTEM]

MULTI AV SYSTEM SYMPTOMS

SYMPTOM DIAGNOSIS

MULTI AV SYSTEM SYMPTOMS

Symptom Table

INFOID:0000000003882785

RELATED TO VEHICLE INFORMATION

RELATED TO REAR VIEW MONITOR

RELATED TO RGB IMAGE

Symptoms

Check items

Possible malfunction location / Action to take

Multifunction switch and preset
switch operation does not work.

• All switches cannot be operated.
• “Multi AV” is displayed on system se-

lection display when the CONSULT-
III is initialized.

Perform CONSULT-III self-diagnosis.
Refer to

AV-68, "CONSULT-III Function (MULTI AV)"

.

• All switches cannot be operated
• “Multi AV” is not displayed on system

selection screen when the CON-
SULT-III is initialized.

AV control unit power supply and ground circuits mal-
function.
Refer to

AV-82, "AV CONTROL UNIT : Diagnosis Proce-

dure"

.

Only specified switch cannot be operat-
ed

Multifunction switch or preset switch malfunction.
Replace multifunction switch or preset switch.
For multifunction switch, refer to

AV-176, "Removal and

Installation"

.

For preset switch, refer to

AV-177, "Removal and Instal-

lation"

.

Fuel economy display, vehicle set-
ting operation is abnormal

There is malfunction in the CONSULT-
III self-diagnosis result

Perform detected DTC self-diagnosis.

There is no malfunction in the self-diag-
nosis results

Ignition signal. Refer to

AV-82, "AV CONTROL UNIT :

Diagnosis Procedure"

.

Symptoms

Check items

Probable malfunction location / Action

to take

It cannot be switched to rear view
monitor even when the selector le-
ver is in the reverse position.

There is malfunction in the CONSULT-III self-diagno-
sis result.

Perform CONSULT-III self-diagnosis.
Refer to

AV-68, "CONSULT-III Function

(MULTI AV)"

.

There is not malfunction in the CONSULT-III self-diag-
nosis result.

Reverse signal circuit malfunction.(AV
control unit)

Camera image is not shown.

AUX images are normal.

• Rear view camera power supply cir-

cuit malfunction.
Refer to

AV-84, "CAMERA CON-

TROL UNIT : Diagnosis Procedure"

.

• Camera image signal circuit malfunc-

tion.
Refer to

AV-96, "Diagnosis Proce-

dure"

.

Possible route line is indicated ab-
normally when camera image is dis-
played.

The “Steer. Angle Sensor” is not turned ON at “Con-
nection Confirmation” of “Camera Cont.”

Steering angle sensor signal circuits.
Refer to

AV-98, "Diagnosis Procedure"

.

Camera image is rolling.

AUX image is rolling

• Horizontal synchronizing (HP) signal

circuit malfunction between AV con-
trol unit and display unit.
Refer to

AV-91, "Diagnosis Proce-

dure"

.

• Vertical synchronizing (VP) signal cir-

cuit malfunction between AV control
unit and display unit.
Refer to

AV-92, "Diagnosis Proce-

dure"

.

AV

MULTI AV SYSTEM SYMPTOMS

AV-165

< SYMPTOM DIAGNOSIS >

[BASE AUDIO AND DISPLAY SYSTEM]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

RELATED TO AUDIO

RELATED TO STEERING SWITCH

Trouble diagnosis chart by symptom

RELATED TO AUXILIARY INPUT

NOTE:

Symptoms

Check items

Possible malfunction location / Action to take

RGB image is not shown.

• All RGB images are not shown.
• Composite images are not dis-

played.(camera and AUX image)

• Display unit power supply and ground circuit malfunc-

tion.
Refer to

AV-82, "DISPLAY UNIT : Diagnosis Proce-

dure"

.

• Communication Circuit malfunction between AV control

unit and display unit.

Perform CONSULT-III self-diagnosis.
 Refer to

AV-68, "CONSULT-III Function (MULTI AV)"

.

• All RGB images are not shown.
• Camera image is normal.
• AUX images are not displayed.

Perform CONSULT-III self-diagnosis.
Refer to

AV-68, "CONSULT-III Function (MULTI AV)"

.

• All RGB images are not shown.
• “Multi AV” is not displayed on system

selection screen when the CONSULT-
III is initialized.

AV control unit power supply and ground circuit malfunc-
tion.
Refer to

AV-82, "AV CONTROL UNIT : Diagnosis Proce-

dure"

.

• All RGB images are not shown.
• Composite images are normal. (cam-

era and AUX image)

RGB area (YS) signal circuit malfunction.
Refer to

AV-90, "Diagnosis Procedure"

.

Color of RGB image is not
proper. (All RGB image)

Light blue (Cyan) tint.

RGB signal (R: red) circuit malfunction between AV con-
trol unit and display unit.
Refer to

AV-86, "Diagnosis Procedure"

.

Purple (Magenta) tint.

RGB signal (G: green) circuit malfunction between AV
control unit and display unit.
Refer to

AV-87, "Diagnosis Procedure"

.

Screen looks yellowish.

RGB signal (B: blue) circuit malfunction between AV con-
trol unit and display unit.
Refer to

AV-88, "Diagnosis Procedure"

.

RGB screen is rolling.

All RGB screen is rolling.

RGB synchronizing signal circuit malfunction between AV
control unit and display unit.
 Refer to

AV-89, "Diagnosis Procedure"

.

Symptoms

Check items

Possible malfunction location / Action to take

The CD cannot be removed.

Disk eject signal circuit.
Refer to

AV-94, "Diagnosis Procedure"

.

Audio sound is not heard.

No sound from all speakers.

Perform CONSULT-III self-diagnosis.
Refer to

AV-68, "CONSULT-III Function (MULTI AV)"

Sound is not heard only from the specific
places (RH front, RH rear, LH front and
LH rear).

Sound signal circuit of suspect system

AM/FM radio is not received.

Other audio sounds are normal.

Antenna amp. ON signal circuit.

Symptoms

Probable malfunction location

None of the steering switch operations work.

Steering switch signal GND circuit. Refer to

AV-105, "Component In-

spection"

.

Only specified switch cannot be operated

Replace steering switch. Refer to

ST-12, "Exploded View"

.

Steering switch's “SOURCE”, “MENU UP”, “MENU DOWN”
switches do not work.

Steering switch signal A circuit. Refer to

AV-100, "Diagnosis Procedure"

.

Steering switch's “VOL UP”, “VOL DOWN” switches do not
work.

Steering switch signal B circuit. Refer to

AV-102, "Diagnosis Procedure"

.

AV-166

< SYMPTOM DIAGNOSIS >

[BASE AUDIO AND DISPLAY SYSTEM]

MULTI AV SYSTEM SYMPTOMS

Check that there is no malfunction of AUX equipment main body before performing a diagnosis.

RELATED TO REAR CONTROL SWITCH

Symptoms

Check items

Probable malfunction location

No voice sound is heard when
AUX mode is selected.

Voice sound is heard when other modes
are selected.

AUX sound signal circuits malfunction between auxiliary
input jacks and AV control unit.

AUX image is not displayed

displayed in black and nothing can be dis-
played

• RGB area synchronizing (YS) signal circuit malfunc-

tion between AV control unit and display unit.
Refer to

AV-90, "Diagnosis Procedure"

.

• Horizontal synchronizing (HP) signal circuit malfunc-

tion between AV control unit and display unit.
Refer to

AV-91, "Diagnosis Procedure"

.

• Vertical synchronizing (VP) signal circuit malfunction

between AV control unit and display unit.
Refer to

AV-92, "Diagnosis Procedure"

.

Camera image is normal.

AUX image signal circuit malfunction between auxiliary
input jacks and AV control unit.
Refer to

AV-93, "Diagnosis Procedure"

.

Symptoms

Check items

Probable malfunction location

None of the rear control switch operations
work.

Perform CONSULT-III self-diagnosis. Refer
to

AV-68, "CONSULT-III Function (MULTI

AV)"

.
