EC-292 < DTC/CIRCUIT DIAGNOSIS > [VQ35DE] P0448 EVAP CANISTER VENT CONTROL VALVE • EVAP hose between EVAP canister and vehicle frame for clogging or poor connection >> Repair hose or replace EVAP canister. 6. CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR CONNECTOR 1. Disconnect EVAP control system pressure sensor harness connector. 2. Check that water is not inside connectors. Is the inspection result normal? YES >> GO TO 7. NO >> Replace EVAP control system pressure sensor. 7. CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR EC-296, "Component Inspection" Is the inspection result normal? YES >> GO TO 8. NO >> Replace EVAP control system pressure sensor. 8. CHECK INTERMITTENT INCIDENT GI-39, "Intermittent Incident" >> INSPECTION END Component Inspection INFOID:0000000005536685 1. CHECK EVAP CANISTER VENT CONTROL VALVE-I 1. Remove EVAP canister vent control valve from EVAP canister. 2. Check portion (A) of EVAP canister vent control valve for rust. Is it rusted? YES >> Replace EVAP canister vent control valve. NO >> GO TO 2. 2. CHECK EVAP CANISTER VENT CONTROL VALVE-II With CONSULT-III 1. Reconnect harness connectors disconnected. 2. Turn ignition switch ON. 3. Perform “VENT CONTROL/V” in “ACTIVE TEST” mode. 4. Check air passage continuity and operation delay time. Operation takes less than 1 second. Without CONSULT-III 1. Disconnect EVAP canister vent control valve harness connector. 2. Check air passage continuity and operation delay time under the Check that new O-ring is installed properly. JMBIA0168ZZ Condition VENT CONTROL/V Air passage continuity between (A) and (B) ON Not existed OFF Existed JMBIA0169ZZ |
