Nissan Murano Z51. Manual - part 365
BCM (BODY CONTROL MODULE)
DEF-51
< ECU DIAGNOSIS INFORMATION >
C
D
E
F
G
H
I
J
K
M
A
B
DEF
N
O
P
144
(P)
Ground
Combination switch
OUTPUT 2
Output
Combination
switch
All switches OFF
(Wiper intermittent dial 4)
0 V
Front washer switch ON
(Wiper intermittent dial 4)
10.7 V
Rear wiper switch ON
(Wiper intermittent dial 4)
Rear washer switch ON
(Wiper intermittent dial 4)
Any of the conditions below
with all switches OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 5
• Wiper intermittent dial 6
145
(V)
Ground
Combination switch
OUTPUT 3
Output
Combination
switch
(Wiper intermit-
tent dial 4)
All switches OFF
0 V
Front wiper switch INT/
AUTO
10.7 V
Front wiper switch LO
Lighting switch AUTO
146
(Y)
Ground
Combination switch
OUTPUT 4
Output
Combination
switch
(Wiper intermit-
tent dial 4)
All switches OFF
0 V
Front fog lamp switch ON
10.7 V
Lighting switch 2ND
Lighting switch PASS
Turn signal switch LH
149
(W)
Ground
Tire pressure warn-
ing check switch
Input
Ignition switch ON
11.8 V
150
(SB)
Ground
Driver door switch
Input
Driver door
switch
OFF (When driver door
closes)
11.8 V
ON (When driver door
opens)
0 V
Terminal No.
(Wire color)
Description
Condition
Value
(Approx.)
Signal name
Input/
Output
+
–
JPMIA0033GB
JPMIA0034GB
JPMIA0035GB
JPMIA0011GB
JPMIA0011GB
