AV

CAMERA CONTROL UNIT

AV-479

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

19

(GR)

—

AV communication signal
(L)

Input/

Output

—

—

—

20

(G)

—

AV communication signal
(H)

Input/

Output

—

—

—

22

(R)

Ground

Reverse signal

Input

Ignition

switch

ON

R position.

12.0 V

Other than R position.

0 V

23

(G)

Ground

Sensor signal 1

Input

Ignition

switch

ON

Turn the steering to the
right.

A: Sensor signal 1
B: Sensor signal 2

Turn the steering to the left.

A: Sensor signal 1
B: Sensor signal 2

24

(SB)

Ground

Sensor signal 2

Input

Ignition

switch

ON

Turn the steering to the
right.

A: Sensor signal 1
B: Sensor signal 2

Turn the steering to the left.

A: Sensor signal 1
B: Sensor signal 2

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3827E

SKIB3828E

SKIB3827E

SKIB3828E

AV-480

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

CAMERA CONTROL UNIT

Wiring Diagram - BOSE AUDIO WITHOUT NAVIGATION WITHOUT DVD ENTER-
TAINMENT SYSTEM -

INFOID:0000000005528605

NOTE:

25

(O)

Ground

Sensor signal 3

Input

Ignition

switch

ON

Turn the steering around
the neutral position.

A: Sensor signal 3
B: Sensor signal 1

26

(BR)

Ground

Vehicle speed signal
(8-pulse)

Input

Ignition

switch

ON

When vehicle speed is ap-
prox. 40 km/h (25 MPH).

NOTE:
Maximum voltage may be 12 V
due to specifications (connected
units).

30

(GR)

Ground

ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

31

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

32

(V)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3829E

SKIA6649J

AV

CAMERA CONTROL UNIT

AV-481

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

In this section, PRESET SWITCH and MULTIFUNCTION SWITCH are written as the MULTIFUNCTION
SWITCH.

JCNWM3177GB

AV-482

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

CAMERA CONTROL UNIT

JCNWM3178GB
