Nissan Murano Z51. Manual - part 1387
SRC-318
< ECU DIAGNOSIS INFORMATION >
[FOR MEXICO]
DIAGNOSIS SENSOR UNIT
WARNING LAMP FLASH CODE CHART (Without CONSULT-lll)
NOTE:
Follow the procedures in numerical order when repairing malfunctioning parts. Confirm whether malfunction is
eliminated using air bag warning lamp or CONSULT-IlI each time repair is completed. If malfunction is still
observed, proceed to the next step. When malfunction is eliminated, further repair work is not required.
FRONTAL COLLISION
DETECTION
[B1209]
• Seat belt pre-tensioner and front air bags is deployed
Go to
SRC-302, "Diagnosis Procedure"
SIDE COLLISION DE-
TECTION
[B1210]
• Front side air bag and curtain air bag is deployed
SRC-304, "Diagnosis Procedure"
ROLLOVER
DETECTION
[B1211]
• Front seat belt pre-tensioner, side curtain air bag are deployed
because of rollover detection
SRC-306, "Diagnosis Procedure"
RH1 SAT-SENS
[B1212]
[B1213]
[B1214]
RH satellite sensor is malfunctioning
1.
Repair or replace wiring harness/
harness connector
2.
Replace RH satellite sensor
3.
Replace air bag diagnosis sensor
unit
LH1 SAT-SENS
[B1215]
[B1216]
[B1217]
LH satellite sensor is malfunctioning
1.
Repair or replace wiring harness/
harness connector
2.
Replace LH satellite sensor
3.
Replace air bag diagnosis sensor
unit
CONTROL UNIT
[B1218]
[B1219]
Air bag diagnosis sensor unit is malfunctioning or out of the speci-
fied specification
Replace air bag diagnosis sensor unit
Diagnostic item
Explanation
Repair order
“Recheck SRS at each replacement”
PHIA0532E
JMHIA0523GB
