RF-32 < ECU DIAGNOSIS INFORMATION > BCM (BODY CONTROL MODULE) 83 (P) Ground Remote keyless entry Input/ Output During waiting When operating either button on Intelligent Key 87 (R) Ground Combination switch Input Combination All switches OFF 1.4 V Front fog lamp switch ON 1.3 V Rear wiper switch ON 1.3 V Any of the conditions below 1.3 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JMKIA0064GB JMKIA0065GB JPMIA0041GB JPMIA0037GB JPMIA0039GB JPMIA0040GB |
