ADP-164

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

92

(R)

Ground

Key slot illumination

Output

Key slot illumina-
tion

OFF

0 V

Blinking

6.5 V

ON

Battery voltage

93

(P)

Ground

ON indicator lamp

Output

Ignition switch

OFF (LOCK and ACC indi-
cator lamps are not illumi-
nated.)

Battery voltage

ON

0 V

95

(L)

Ground

ACC relay control

Output

Ignition switch

OFF

0 V

ACC or ON

Battery voltage

96

(Y)

Ground

CVT shift selector
(detention switch)
power supply

Output

Battery voltage

97*

1

(O)

Ground

Steering lock condi-
tion No. 1

Input

Steering lock

LOCK status

0 V

UNLOCK status

Battery voltage

98*

1

(L)

Ground

Steering lock condi-
tion No. 2

Input

Steering lock

LOCK status

Battery voltage

UNLOCK status

0 V

99

(V)

Ground

Selector lever P posi-
tion switch

Input

Selector lever

P position

0 V

Any position other than P

Battery voltage

100

(P)

Ground

Passenger door re-
quest switch

Input

Passenger door
request switch

ON (Pressed)

0 V

OFF (Not pressed)

1.0 V

101
(W)

Ground

Driver door request
switch

Input

Driver door re-
quest switch

ON (Pressed)

0 V

OFF (Not pressed)

1.0 V

102

(Y)

Ground

Blower fan motor re-
lay control

Output

Ignition switch

OFF or ACC

0 V

ON

Battery voltage

103

(L)

Ground

Remote keyless entry
receiver power sup-
ply

Output

Ignition switch OFF

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JPMIA0015GB

JPMIA0016GB

JPMIA0016GB

BCM (BODY CONTROL MODULE)

ADP-165

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

106*

1

(Y)

Ground

Steering lock unit
power supply

Output

Ignition switch

OFF or ACC

Battery voltage

ON

0 V

107

(O)

Ground

Combination switch
INPUT 1

Input

Combination
switch
(Wiper intermit-
tent dial 4)

All switches OFF

1.4 V

Turn signal switch LH

1.3 V

Turn signal switch RH

1.3 V

Front wiper switch LO

1.3 V

Front washer switch ON

1.3 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JPMIA0041GB

JPMIA0037GB

JPMIA0036GB

JPMIA0038GB

JPMIA0039GB

ADP-166

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

108

(P)

Ground

Combination switch
INPUT 4

Input

Combination
switch

All switches OFF
(Wiper intermittent dial 4)

1.4 V

Lighting switch AUTO
(Wiper intermittent dial 4)

1.3 V

Lighting switch 1ST
(Wiper intermittent dial 4)

1.3 V

Rear wiper switch INT
(Wiper intermittent dial 4)

1.3 V

Any of the conditions below
with all switches OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 5
• Wiper intermittent dial 6

1.3 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JPMIA0041GB

JPMIA0038GB

JPMIA0036GB

JPMIA0040GB

JPMIA0039GB

BCM (BODY CONTROL MODULE)

ADP-167

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

109

(SB)

Ground

Combination switch
INPUT 2

Input

Combination
switch
(Wiper intermit-
tent dial 4)

All switches OFF

1.4 V

Lighting switch PASS

1.3 V

Lighting switch 2ND

1.3 V

Front wiper switch INT/
AUTO

1.3 V

Front wiper switch HI

1.3 V

110

(G)

Ground

Hazard switch

Input

Hazard switch

ON

0 V

OFF

1.1 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JPMIA0041GB

JPMIA0037GB

JPMIA0036GB

JPMIA0038GB

JPMIA0040GB

JPMIA0012GB
