Nissan Murano Z51. Manual - part 36

ADP-136

< ECU DIAGNOSIS INFORMATION >

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

22

(V)

Ground

Door mirror motor (pas-
senger side) down out-
put signal

Output

Door mirror (RH)

Operate
(down)

Battery voltage

Other than
above

0

Door mirror motor (pas-
senger side) right output
signal

Operate
(right)

Battery voltage

Other than
above

0

23

(L)

Ground

Door mirror motor (driv-
er side)up output signal

Output

Door mirror (LH)

Operate
(up)

Battery voltage

Other than
above

0

24

(SB)

Ground

Door mirror motor (driv-
er side)left output signal

Output

Door mirror (LH)

Operate
(left)

Battery voltage

Other than
above

0

25

(W)

Ground

Power source

Input

—

Battery voltage

26

(L)

Ground

Telescopic motor back-
ward output signal

Output

Steering tele-
scopic

Operate
(back-
ward)

Battery voltage

Other than
above

0

27

(P)

Ground

Tilt&telescopic motor
power source

—

Battery voltage

28

(G)

Ground

Tilt motor down output
signal

Output

Steering tilt

Operate
(down)

Battery voltage

Other than
above

0

29

(LG)

Ground

Tilt motor up output sig-
nal

Output

Steering tilt

Operate
(up)

Battery voltage

Other than
above

0

Telescopic motor for-
ward output signal

Steering tele-
scopic

Operate
(forward)

Battery voltage

Other than
above

0

30

(B)

Ground

Ground

—

—

0

Terminal No.

(wire color)

Description

Condition

Voltage (V)

(Approx.)

+

-

Signal name

Input/

Output

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

ADP-137

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

Wiring Diagram - AUTOMATIC DRIVE POSITIONER CONTROL SYSTEM -

INFOID:0000000005713373

JCJWM0709GB

ADP-138

< ECU DIAGNOSIS INFORMATION >

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

JCJWM0710GB

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

ADP-139

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

JCJWM0711GB
