EXL-304
< ECU DIAGNOSIS INFORMATION >
[HALOGEN TYPE]
BCM (BODY CONTROL MODULE)
92
(R)
Ground
Key slot illumination
Output
Key slot illumina-
tion
OFF
0 V
Blinking
6.5 V
ON
Battery voltage
93
(P)
Ground
ON indicator lamp
Output
Ignition switch
OFF (LOCK and ACC indi-
cator lamps are not illumi-
nated.)
Battery voltage
ON
0 V
95
(L)
Ground
ACC relay control
Output
Ignition switch
OFF
0 V
ACC or ON
Battery voltage
96
(Y)
Ground
CVT shift selector
(detention switch)
power supply
Output
—
Battery voltage
99
(V)
Ground
Selector lever P posi-
tion switch
Input
Selector lever
P position
0 V
Any position other than P
Battery voltage
100
(P)
Ground
Passenger door re-
quest switch
Input
Passenger door
request switch
ON (Pressed)
0 V
OFF (Not pressed)
1.0 V
101
(W)
Ground
Driver door request
switch
Input
Driver door re-
quest switch
ON (Pressed)
0 V
OFF (Not pressed)
1.0 V
102
(Y)
Ground
Blower fan motor re-
lay control
Output
Ignition switch
OFF or ACC
0 V
ON
Battery voltage
103
(L)
Ground
Remote keyless entry
receiver power sup-
ply
Output
Ignition switch OFF
Battery voltage
Terminal No.
(Wire color)
Description
Condition
Value
(Approx.)
Signal name
Input/
Output
+
–
JPMIA0015GB
JPMIA0016GB
JPMIA0016GB
