EXL-116 < ECU DIAGNOSIS INFORMATION > [XENON TYPE] BCM (BODY CONTROL MODULE) 73 (W) Ground Room antenna (+) Output Ignition switch When Intelligent Key is in When Intelligent Key is not 74 (Y) Ground Passenger door an- Output When the pas- When Intelligent Key is in When Intelligent Key is not 75 (LG) Ground Passenger door an- Output When the pas- When Intelligent Key is in When Intelligent Key is not Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JMKIA0062GB JMKIA0063GB JMKIA0062GB JMKIA0063GB JMKIA0062GB JMKIA0063GB |
