EC-486 < ECU DIAGNOSIS INFORMATION > [VQ35DE] ECM : Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.) *1: This may vary depending on internal resistance of the tester. *2: Before measuring the terminal voltage, confirm that the battery is fully charged. Refer to 100 (G) — Sensor ground — — — 102 (R) 112 (B) PNP signal Input [Ignition switch: ON] BATTERY VOLTAGE [Ignition switch: ON] position 0 V 104 (SB) — Sensor ground — — — 105 (V) 112 (B) Power supply for ECM Input [Ignition switch: ON] BATTERY VOLTAGE 106 (SB) 112 (B) Stop lamp switch Input [Ignition switch: OFF] 0 V [Ignition switch: OFF] pressed BATTERY VOLTAGE 107 (B) 108 (B) — ECM ground — — — 109 112 (B) EVAP canister vent control Output [Ignition switch: ON] BATTERY VOLTAGE 110 (G) 112 (B) ASCD brake switch Input [Ignition switch: ON] pressed 0 V [Ignition switch: ON] BATTERY VOLTAGE 111 (B) 112 (B) — ECM ground — — — Terminal No. Description Condition Value (Approx.) + -– Signal name Input/ Output |
