EC-26 < BASIC INSPECTION > [VQ35DE] HOW TO SET SRT CODE *: Normal conditions - Sea level ° C (68 – 86 ° F) NOTE: ° C (68 – 86 ° F)] Work Procedure INFOID:0000000009719818 1. CHECK DTC Check DTC. YES >> Repair malfunction(s) and erase DTC. Refer to NO >> GO TO 2. 2. CHECK SRT STATUS With CONSULT Select “SRT STATUS” in “DTC & SRT CONFIRMATION” mode with CONSULT. Without CONSULT Perform “SRT status” mode with EC-126, "On Board Diagnosis Function" With GST Select Service $01 with GST. Is SRT code(s) set? YES >> GO TO 12. NO-1 >> With CONSULT: GO TO 3. NO-2 >> Without CONSULT: GO TO 4. 3. DTC CONFIRMATION PROCEDURE 1. Select “SRT WORK SUPPORT” in “DTC & SRT CONFIRMATION” mode with CONSULT. 2. For SRT(s) that is not set, perform the corresponding “DTC CONFIRMATION PROCEDURE” according to . 3. Check DTC. Is any DTC detected? YES >> Repair malfunction(s) and erase DTC. Refer to NO >> GO TO 11. 4. PERFORM ROAD TEST • Check the “Performance Priority” in the “SRT ITEM” table. Refer to . • Perform the most efficient SRT set driving pattern to set the SRT properly. Refer to . In order to set all SRTs, the SRT set driving pattern must be performed at least once. >> GO TO 5. 5. PATTERN 1 1. Check the vehicle condition; - Engine coolant temperature is − 10 to 35 ° C (14 to 95 ° F). - Fuel tank temperature is more than 0 ° C (32 ° F). 2. Start the engine. 3. Keep engine idling until the engine coolant temperature is greater than 70 ° C (158 ° F) NOTE: − 10 to 35 ° C (14 to 95 ° F): 3.0 – 4.3 V - 70 ° (158 ° F): Less than 4.1 V • Fuel tank temperature: Less than 1.4 V . |
