Fail-Safe

INFOID:0000000009718114

AWD system

• If any malfunction occurs in AWD electrical system, and control unit detects the malfunction, AWD warning

lamp on combination meter turns ON to indicate system malfunction.

• When AWD warning lamp is ON, vehicle changes to front-wheel drive or shifts to 4-wheel drive (rear-wheels

still have some driving torque).

JRDWC1708GB

DLN-36

< ECU DIAGNOSIS INFORMATION >

[TRANSFER: TY20A]

AWD CONTROL UNIT

• AWD system activates its protection function (shuts down AWD system temporarily) if AWD system detects

high load continuously or the front wheel tire size differs from the rear tire size. (AWD system is automati-
cally restored if AWD system no longer detects any overload or the tire size difference is eliminated.)

*1: Quick blinking: 2 times/second (blinking for approximately 1 minute and then turned OFF)

*2: Slow blinking: 1 time/2 seconds (continuing to blink until ignition switch is turned OFF)

DTC Inspection Priority Chart

INFOID:0000000009718115

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.

DTC Index

INFOID:0000000009718116

Mode

Warning

lamp

DTC

Detected area (Error area)

Error area and root cause

Protection

function

 Blinking

*1

—

AWD control unit

Transfer assembly in protection mode. It is not malfunction.
(Internal temperature rise of electronic controlled coupling)

Blinking

*2

—

AWD control unit

Malfunction in each tire or different tire diameter

Fail-safe

ON

C1201

AWD control unit

Internal malfunction of AWD control unit

C1203

ABS actuator and electric
unit (control unit)

ABS malfunction
• Vehicle speed signal error

C1204

AWD solenoid

• Internal malfunction of electronic controlled coupling
• Malfunction of AWD solenoid power supply circuit (open or

short)

• Malfunction of AWD solenoid command current

C1205

AWD control unit

Internal malfunction of AWD control unit

C1210

ECM

Malfunction of engine control system

U1000

CAN communication line

• CAN communication error
• Malfunction of AWD control unit

U1010

AWD control unit

Malfunction of AWD control unit

Priority

Detected items (DTC)

1

• U1000 CAN COMM CIRCUIT
• U1010 CONTROL UNIT (CAN)

2

• C1201 CONTROLLER FAILURE
• C1205 4WD ACTUATOR RLY

3

• C1204 4WD SOLENOID

4

• C1203 ABS SYSTEM
• C1210 ENGINE SIGNAL 1

DTC

Display Item

Reference

C1201

CONTROLLER FAILURE

DLN-12, "DTC Logic"

C1203

ABS SYSTEM

DLN-13, "DTC Logic"

C1204

4WD SOLENOID

DLN-14, "DTC Logic"

C1205

4WD ACTUATOR RLY

DLN-16, "DTC Logic"

C1210

ENGINE SIGNAL 1

DLN-18, "DTC Logic"

U1000

CAN COMM CIRCUIT

DLN-19, "DTC Logic"

U1010

CONTROL UNIT (CAN)

DLN-20, "DTC Logic"

AWD WARNING LAMP DOES NOT TURN ON
