ENGINE COOLANT CO-13 < PERIODIC MAINTENANCE > C D E F G H I J K L M A CO N P O 6. Install air duct assembly and air cleaner cases (upper and lower) assembly. Refer to . 7. Install radiator cap. 8. Warm up engine until opening thermostat. Standard for warming-up time is approximately 10 minutes at CAUTION: Watch water temperature gauge so as not to overheat engine. 9. Stop the engine and cool down to less than approximately 50 ° C (122 ° F). • Cool down using fan to reduce the time. CAUTION: Never adhere the engine coolant to electronic equipments. (alternator etc.) 10. Refill reservoir tank to “MAX” level line with engine coolant. 11. Repeat steps 7 through 10 two or more times with radiator cap installed until engine coolant level no longer drops. 12. Check cooling system for leakage with engine running. 3,000 rpm with heater temperature controller set at several position between “COOL” and “WARM”. 14. Repeat step 13 three times. 15. If sound is heard, bleed air from cooling system by repeating step 5, and steps from 7 to 14 until engine coolant level no longer drops. Flushing INFOID:0000000009720479 1. Install reservoir tank if removed and radiator drain plug. CAUTION: Be sure to clean drain plug and install with new O-ring. If water drain plugs on cylinder block are removed, close and tighten them. Refer to 2. Remove air duct assembly and air cleaner cases (upper and lower) assembly. Refer to . A : MAX B : MIN JPBIA0102ZZ Tightening torque |
