Nissan Murano. Manual - part 1162





RF-32

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

76

(V)

Ground

Driver door antenna
(-)

Output

When the driver
door request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

77

(P)

Ground

Driver door antenna
(+)

Output

When the driver
door request
switch is operat-
ed with ignition
switch OFF

When Intelligent Key is in
the antenna detection area

When Intelligent Key is not
in the antenna detection
area

80

(SB)

Ground

NATS antenna amp.

Input/

Output

During waiting

Ignition switch is pressed
while inserting Intelligent
Key into the key slot.

Just after pressing ignition

switch. Pointer of tester should

move.

81

(O)

Ground

NATS antenna amp.

Input/

Output

During waiting

Ignition switch is pressed
while inserting Intelligent
Key into the key slot.

Just after pressing ignition

switch. Pointer of tester should

move.

82

(BR)

Ground

Ignition relay [fuse
block (J/B)] control

Output

Ignition switch

OFF or ACC

0 V

ON

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

BCM (BODY CONTROL MODULE)

RF-33

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

83

(P)

Ground

Remote keyless entry
receiver communica-
tion

Input/

Output

During waiting

When operating either button on Intelligent Key

87

(R)

Ground

Combination switch
INPUT 5

Input

Combination
switch

All switches OFF
(Wiper intermittent dial 4)

1.4 V

Front fog lamp switch ON
(Wiper intermittent dial 4)

1.3 V

Rear wiper switch ON
(Wiper intermittent dial 4)

1.3 V

Any of the conditions below
with all switches OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 6
• Wiper intermittent dial 7

1.3 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JMKIA0064GB

JMKIA0065GB

JPMIA0041GB

JPMIA0037GB

JPMIA0039GB

JPMIA0040GB

RF-34

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

88

(GR)

Ground

Combination switch
INPUT 3

Input

Combination
switch

All switches OFF
(Wiper intermittent dial 4)

1.4 V

Lighting switch HI
(Wiper intermittent dial 4)

1.3 V

Lighting switch 2ND
(Wiper intermittent dial 4)

1.3 V

Rear washer switch ON
(Wiper intermittent dial 4)

1.3 V

Any of the conditions below
with all switches OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 3

1.3 V

90

(P)

Ground

CAN-L

Input/

Output

91

(L)

Ground

CAN-H

Input/

Output

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JPMIA0041GB

JPMIA0036GB

JPMIA0037GB

JPMIA0039GB

JPMIA0040GB

BCM (BODY CONTROL MODULE)

RF-35

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

92

(R)

Ground

Key slot illumination

Output

Key slot illumina-
tion

OFF

0 V

Blinking

6.5 V

ON

Battery voltage

93

(P)

Ground

ON indicator lamp

Output

Ignition switch

OFF (LOCK and ACC indi-
cator lamps are not illumi-
nated.)

Battery voltage

ON

0 V

95

(L)

Ground

ACC relay control

Output

Ignition switch

OFF

0 V

ACC or ON

Battery voltage

96

(Y)

Ground

CVT shift selector
(detention switch)
power supply

Output

Battery voltage

99

(V)

Ground

Selector lever P posi-
tion switch

Input

Selector lever

P position

0 V

Any position other than P

Battery voltage

100

(P)

Ground

Passenger door re-
quest switch

Input

Passenger door
request switch

ON (Pressed)

0 V

OFF (Not pressed)

1.0 V

101
(W)

Ground

Driver door request
switch

Input

Driver door re-
quest switch

ON (Pressed)

0 V

OFF (Not pressed)

1.0 V

102

(Y)

Ground

Blower fan motor re-
lay control

Output

Ignition switch

OFF or ACC

0 V

ON

Battery voltage

103

(L)

Ground

Remote keyless entry
receiver power sup-
ply

Output

Ignition switch OFF

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JPMIA0015GB

JPMIA0016GB

JPMIA0016GB
