PCS-86 < ECU DIAGNOSIS INFORMATION > [POWER DISTRIBUTION SYSTEM] BCM (BODY CONTROL MODULE) 52 (R) Ground Starter relay control Output Ignition switch When selector lever is in P Battery voltage When selector lever is not 0.3 V Ignition switch OFF 0 V 60 (BR) Ground Push-button ignition Input Push-button igni- Pressed 0 V Not pressed Battery voltage 61 (R) Ground Back door request Input Back door re- ON (Pressed) 0 V OFF (Not pressed) 1.0 V 64 (GR) Ground Intelligent key warn- Output Warning buzzer Sounding 0 V Not sounding Battery voltage 65 (O) Ground Rear wiper stop posi- Input Rear wiper In stop position 1.0 V Not in stop position 0 V 66 (Y) Ground Back door switch Input Back door switch OFF (When back door 11.8 V ON (When back door 0 V 67 (LG) Ground Back door opener Input Back door opener Pressed 0 V Not pressed 11.8 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JPMIA0016GB JPMIA0016GB JPMIA0011GB JPMIA0011GB |
