Nissan Murano. Manual - part 1017
MIR-46
< ECU DIAGNOSIS INFORMATION >
[WITH ADP]
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
22
(V)
Ground
Door mirror motor (pas-
senger side) down out-
put signal
Output
Door mirror (RH)
Operate
(down)
Battery voltage
Other than
above
0
Door mirror motor (pas-
senger side) right output
signal
Operate
(right)
Battery voltage
Other than
above
0
23
(L)
Ground
Door mirror motor (driv-
er side)up output signal
Output
Door mirror (LH)
Operate
(up)
Battery voltage
Other than
above
0
24
(SB)
Ground
Door mirror motor (driv-
er side)left output signal
Output
Door mirror (LH)
Operate
(left)
Battery voltage
Other than
above
0
25
(W)
Ground
Power source
Input
—
Battery voltage
26
(L)
Ground
Telescopic motor back-
ward output signal
Output
Steering tele-
scopic
Operate
(back-
ward)
Battery voltage
Other than
above
0
27
(P)
Ground
Tilt&telescopic motor
power source
—
Battery voltage
28
(G)
Ground
Tilt motor down output
signal
Output
Steering tilt
Operate
(down)
Battery voltage
Other than
above
0
29
(LG)
Ground
Tilt motor up output sig-
nal
Output
Steering tilt
Operate
(up)
Battery voltage
Other than
above
0
Telescopic motor for-
ward output signal
Steering tele-
scopic
Operate
(forward)
Battery voltage
Other than
above
0
30
(B)
Ground
Ground
—
—
0
Terminal No.
(wire color)
Description
Condition
Voltage (V)
(Approx.)
+
-
Signal name
Input/
Output
