REMINDER FUNCTION DOES NOT OPERATE DLK-557 < SYMPTOM DIAGNOSIS > [TYPE 2] C D E F G H I J L M A B DLK N O P REMINDER FUNCTION DOES NOT OPERATE DOOR REQUEST SWITCH DOOR REQUEST SWITCH : Description INFOID:0000000010754993 Reminder function does not operate using door request switch. DOOR REQUEST SWITCH : Diagnosis Procedure INFOID:0000000010754994 1. CHECK DTC WITH BCM AND COMBINATION METER Check that DTC is not detected with BCM and combination meter. Is the inspection result normal? YES >> GO TO 2. NO-1 >> Refer to NO-2 >> Refer to . (Combination meter) 2. CHECK HAZARD FUNCTION Check hazard function. DLK-502, "Component Function Check" Is the inspection result normal? YES >> GO TO 3. NO >> Repair or replace the malfunctioning parts. 3. REPLACE BCM 1. Replace BCM. Refer to BCS-121, "Removal and Installation" . 2. Confirm the operation after replacement. Is the result normal? YES >> INSPECTION END NO >> Check intermittent incident. Refer to GI-44, "Intermittent Incident" . INTELLIGENT KEY INTELLIGENT KEY : Description INFOID:0000000010754995 Reminder function does not operate using Intelligent Key. INTELLIGENT KEY : Diagnosis Procedure INFOID:0000000010754996 1. CHECK DTC WITH BCM AND COMBINATION METER Check that DTC is not detected with BCM and combination meter. Is the inspection result normal? YES >> GO TO 2. NO-1 >> Refer to NO-2 >> Refer to . (Combination meter) 2. CHECK HAZARD FUNCTION Check hazard function. DLK-502, "Component Function Check" Is the inspection result normal? YES >> GO TO 3. NO >> Repair or replace the malfunctioning parts. 3. REPLACE BCM 1. Replace BCM. Refer to BCS-121, "Removal and Installation" . 2. Confirm the operation after replacement. Is the result normal? YES >> INSPECTION END NO >> Check intermittent incident. Refer to GI-44, "Intermittent Incident" . |
