Nissan X-Trail 32. Manual - part 332
DAS
PUMP CONTROL UNIT
DAS-69
< ECU DIAGNOSIS INFORMATION >
[DRIVER ASSISTANCE SYSTEM]
C
D
E
F
G
H
I
J
K
L
M
B
N
P
A
8
(BR)
Ground
Communication line
(CAMERA
→
PUMP)
Input
Ignition
switch
ON
—
Input the waveform synchronized
with the communication status.
9
(LG)
5
(B)
Rear washer status
Output
Ignition
switch
ON
Rear washer switch is ON.
0 – 0.1 V
0 V
Rear washer switch is
OFF.
9.5 – 16 V
12 V
10
(BR)
5
(B)
Rear washer switch
input
Input
Ignition
switch
ON
Rear washer switch is ON.
9.5 – 16 V
12 V
Rear washer switch is
OFF.
0 – 0.1 V
0 V
12
(LG)
Ground
Ignition power sup-
ply
Input
Ignition switch ON
12 – 14 V
Battery voltage
Terminal
(Wire color)
Description
Condition
Standard value
Reference value
(Approx.)
+
–
Signal name
Input/
Output
PKIB5039J
