WCS

COMBINATION METER

WCS-43

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

Information display

Odo/trip meter

An indicated value is maintained at communications blackout.

Shift position indicator

The display turns OFF by suspending communication.

Chassis control display

The display turns no effect by suspending communication.

4WD torque distribution display

The gauge displays 0% by suspending communication.

Trip com-
puter

Current fuel consump-
tion

The last result calculated during normal condition is indicated.

Average fuel consump-
tion

Average vehicle speed

Distance to empty

ECO pedal guide

The indicator turns OFF by suspending communication.

Warning/
Indicator

4WD warning

The display turns ON by suspending communication.

Chassis control warning

Other than the above

The display turns OFF by suspending communication.

Buzzer

The buzzer turns OFF by suspending communication.

Warning lamp/indicator lamp

ABS warning lamp

The lamp turns ON by suspending communication.

VDC warning lamp

Brake warning lamp

Electric power steering warning lamp

Malfunction indicator lamp (MIL) (yel-
low)

SRS air bag warning lamp

Brake system warning lamp

FEB warning lamp

Low tire pressure warning lamp

The lamp turns ON after flashing for 2 minutes.

Electric parking brake indicator lamp

The lamp blinking caused by suspending communication.

High beam indicator lamp

The lamp turns OFF by suspending communication.

VDC OFF indicator lamp

Turn signal indicator lamp

Front fog lamp indicator lamp

Rear fog lamp indicator lamp

Position lamp indicator lamp

Charge warning lamp

ECO mode indicator lamp

4WD indicator lamp

LOCK indicator lamp

Dipped beam indicator lamp

hill descent control indicator lamp

Water-in-fuel-filter warning lamp

Glow indicator lamp

Malfunction indicator lamp (MIL) (red)

High beam assist indicator lamp

hill start assist indicator lamp

Function

Specifications

WCS-44

< ECU DIAGNOSIS INFORMATION >

COMBINATION METER

DTC Inspection Priority Chart

INFOID:0000000010726646

If multiple DTCs are detected simultaneously, check them one by one depending on the following DTC inspec-
tion priority chart.

DTC Index

INFOID:0000000010726647

Priority

Detected items (DTC)

1

• U1000: CAN COMM CIRCUIT
• U1010: CONTROL UNIT (CAN)

2

• B2205: VEHICLE SPEED
• B2267: ENGINE SPEED
• B2268: WATER TEMP
• B2321: OIL LEV SEN OPEN
• B2322: OIL LEV SEN SHORT
• B2323: ILLUMINATION OUTPUT CIRCUIT

DTC

CONSULT display

Refer to

U1000

CAN COMM CIRCUIT

MWI-121, "DTC Description"

U1010

CONTROL UNIT (CAN)

MWI-122, "DTC Description"

B2205

VEHICLE SPEED

MWI-123, "DTC Description"

B2267

ENGINE SPEED

MWI-124, "DTC Description"

B2268

WATER TEMP

MWI-125, "DTC Description"

B2321

OIL LEV SEN OPEN

MWI-126, "DTC Description"

B2322

OIL LEV SEN SHORT

MWI-126, "DTC Description"

B2323

ILLUMINATION OUTPUT CIRCUIT

MWI-128, "DTC Description"

WCS

BCM

WCS-45

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

BCM

List of ECU Reference

INFOID:0000000010726599

ECU

Reference

BCM

BCS-53, "Reference Value"

BCS-76, "Fail-safe"

BCS-77, "DTC Inspection Priority Chart"

BCS-78, "DTC Index"

WCS-46

< WIRING DIAGRAM >

WARNING CHIME SYSTEM

WIRING DIAGRAM

WARNING CHIME SYSTEM

Wiring Diagram

INFOID:0000000010726600

JRNWD4090GB
