B2196 DONGLE UNIT
SEC-119
< DTC/CIRCUIT DIAGNOSIS >
[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
M
A
B
SEC
N
O
P
B2196 DONGLE UNIT
DTC Description
INFOID:0000000010926566
BCM performs ID verification between BCM and dongle unit.
When verification result is OK, BCM permits cranking.
DTC DETECTION LOGIC
POSSIBLE CAUSE
• Harness or connectors
(Dongle unit circuit is open or shorted.)
• Dongle unit
FAIL-SAFE
Inhibit engine cranking
DTC CONFIRMATION PROCEDURE
1.
PERFORM DTC CONFIRMATION PROCEDURE
1.
Turn ignition switch ON.
2.
Turn ignition switch OFF.
3.
Turn ignition switch ON.
4.
Check DTC in “Self-diagnosis result” mode of “BCM” using CONSULT.
Is the DTC detected?
YES
>> Refer to
SEC-119, "Diagnosis Procedure"
NO-1
>> To check malfunction symptom before repair: Refer to
GI-44, "Intermittent Incident"
NO-2
>> Confirmation after repair: INSPECTION END
Diagnosis Procedure
INFOID:0000000010926567
1.
PERFORM INITIALIZATION
1.
Perform initialization of BCM and registration of all mechanical keys using CONSULT.
For initialization and registration procedures, refer to CONSULT Immobilizer mode and follow the on-
screen instructions.
2.
Start the engine.
Dose the engine start?
YES
>> INSPECTION END
NO
>> GO TO 2.
2.
CHECK DONGLE UNIT CIRCUIT
1.
Turn ignition switch OFF.
2.
Disconnect BCM connector and dongle unit connector.
3.
Check continuity between BCM harness connector and dongle unit harness connector.
4.
Check continuity between BCM harness connector and ground.
DTC No.
CONSULT screen items
(Trouble diagnosis content)
DTC detecting condition
B2196-00
DONGLE NG
(Dongle unit not good)
The ID verification results between BCM and dongle unit is invalid.
BCM
Dongle unit
Continuity
Connector
Terminal
Connector
Terminal
M87
56
M53
1
Existed
BCM
Ground
Continuity
Connector
Terminal
M87
56
Not existed
