ADDITIONAL SERVICE WHEN REPLACING IPDM E/R

PCS-47

< BASIC INSPECTION >

[IPDM E/R]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

BASIC INSPECTION

ADDITIONAL SERVICE WHEN REPLACING IPDM E/R

Description

INFOID:0000000010741713

After replaced IPDM E/R, it is necessary to perform control unit configuration and height sensor initialize (For
LED headlamp models) with CONSULT.

BEFORE REPLACEMENT

When replacing IPDM E/R, save or print current vehicle specification with CONSULT configuration before
replacement.
NOTE:
If “Before Replace ECU” of “Read/Write Configuration” cannot be used, use the “Manual Configuration” after
replacing IPDM E/R.

AFTER REPLACEMENT

CAUTION:

• When replacing IPDM E/R, always perform “Read/Write Configuration” or “Manual Configuration”

with CONSULT. Or not doing so, IPDM E/R control function does not operate normally.

• Never perform “Read / Write Configuration” or “Manual Configuration” except for new IPDM E/R or

the control function may not operate normally.

Work Procedure

INFOID:0000000010741714

1.

SAVING VEHICLE SPECIFICATION (IPDM E/R)

CONSULT Configuration

Perform “Before Replace ECU” of “Read / Write Configuration” to save or print current vehicle specification.
Refer to

PCS-48, "Description"

.

NOTE:
If “Before Replace ECU” of “Read/Write Configuration” cannot be used, use the “Manual Configuration” after
replacing IPDM E/R.

>> GO TO 2.

2.

REPLACE IPDM E/R

Replace IPDM E/R. Refer to

PCS-60, "Removal and Installation"

.

>> GO TO 3.

3.

WRITING VEHICLE SPECIFICATION (IPDM E/R)

CONSULT Configuration

Perform “After Replace ECU” of “Read/Write Configuration” or “Manual Configuration” to write vehicle specifi-
cation. Refer to

PCS-48, "Work Procedure"

.

>> GO TO 4.

4.

CHECK HEADLAMP TYPE

Check headlamp type.

LED headlamp>>GO TO 5.
Halogen headlamp>>WORK END

5.

HEIGHT SENSOR INITIALIZE

Perform height sensor initialize. Refer to

EXL-99, "Work Procedure"

.

>> WORK END

PCS-48

< BASIC INSPECTION >

[IPDM E/R]

CONFIGURATION (IPDM E/R)

CONFIGURATION (IPDM E/R)

Description

INFOID:0000000010741715

There is no vehicle specification in new IPDM E/R, so the vehicle specification needs to be written in IPDM E/
R with CONSULT.
Configuration has three functions as follows.

CAUTION:

• When replacing IPDM E/R, always perform “Read/Write Configuration” or “Manual Configuration”

with CONSULT. Or not doing so, IPDM E/R control function does not operate normally.

• Never perform “Read / Write Configuration” or “Manual Configuration” except for new IPDM E/R or

the control function may not operate normally.

Work Procedure

INFOID:0000000010741716

1.

WRITING MODE SELECTION

CONSULT Configuration

Select “CONFIGURATION” of IPDM E/R.

When writing saved data>>GO TO 2.
When writing manually>>GO TO 3.

2.

PERFORM “WRITE CONFIGURATION”

CONSULT Configuration

1.

Select “READ/WRITE CONFIGURATION”.

2.

Select “After Replace ECU”.

>> GO TO 4.

3.

PERFORM “MANUAL CONFIGURATION”

CONSULT Configuration

1.

Select “MANUAL CONFIGURATION”.

2.

Identify the correct model and configuration list. Refer to

PCS-49, "Configuration list"

.

CAUTION:

• Thoroughly read and understand the vehicle specification. ECU control may not operate nor-

mally if the setting is not correct.

• Make sure to select “SETTING” even if the indicated configuration of brand new IPDM E/R is

same as the desirable configuration. If not, configuration which is set automatically by selecting
vehicle model cannot be memorized

3.

Sets the displayed item and then select “NEXT”.
NOTE:
If item is not displayed, select “NEXT”.

4.

Check that the configuration has been successfully written and touch “End”.

>> GO TO 4.

4.

OPERATION CHECK

Confirm that each function controlled by IPDM E/R operates normally.

>> WORK END

Function

Description

READ/WRITE CON-
FIGURATION

Before Replace ECU

• Reads the vehicle configuration of current BCM.
• Saves the read vehicle configuration.

After Replace ECU

Writes the vehicle configuration with saved data.

MANUAL CONFIGURATION

Writes the vehicle configuration with manual selection.

PCS

CONFIGURATION (IPDM E/R)

PCS-49

< BASIC INSPECTION >

[IPDM E/R]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

Configuration list

INFOID:0000000010741717

CAUTION:

Check vehicle specifications before servicing.

MANUAL SETTING ITEM

NOTE

System

Item

Setting value

IPDM-E

Data part number

284B7-4CB1A

All of the following are satisfied
• MR20 engine
• M/T
• Headlamp aiming control system (manual)
• Halogen headlamp
• Without Intelligent Key system
• Without stop/start system

IPDM-E

Data part number

284B7-4CB1C

All of the following are satisfied
• MR20 engine
• CVT
• Headlamp aiming control system (manual)
• Halogen headlamp
• With Intelligent Key system
• Without stop/start system

IPDM-E

Data part number

284B7-4CB1E

All of the following are satisfied
• MR20 engine
• CVT
• Headlamp aiming control system (manual)
• Halogen headlamp
• Without Intelligent Key system
• Without stop/start system

IPDM-E

Data part number

284B7-4CB2B

All of the following are satisfied
• MR20 engine
• CVT
• Headlamp aiming control system (auto)
• LED headlamp
• With Intelligent Key system
• Without stop/start system

IPDM-E

Data part number

284B7-4CB2E

All of the following are satisfied
• QR25 engine
• CVT
• Headlamp aiming control system (manual)
• Halogen headlamp
• With Intelligent Key system
• Without stop/start system

IPDM-E

Data part number

284B7-4CB3B

All of the following are satisfied
• QR25 engine
• CVT
• Headlamp aiming control system (auto)
• LED headlamp
• With Intelligent Key system
• Without stop/start system

IPDM-E

Data part number

284B7-4CB3D

All of the following are satisfied
• R9M engine
• M/T
• Headlamp aiming control system (manual)
• Halogen headlamp
• Without Intelligent Key system
• With stop/start system
