BR-114 < REMOVAL AND INSTALLATION > [RHD] FRONT DISC BRAKE 5. Apply rubber grease to mating faces between sliding pin and bushing , and install bushing to sliding pin. 6. Apply rubber grease to mating faces between sliding pins and sliding pin boots , and install sliding pins and sliding pin boots to torque member . 7. Install the cylinder body to tighten sliding pin bolts to the speci- BRAKE CALIPER ASSEMBLY (1 PISTON TYPE) : Inspection INFOID:0000000010838603 INSPECTION AFTER DISASSEMBLY Check the following items and replace if necessary. Cylinder Body Check the cylinder inner wall for rust, wear, cracks or damage. CAUTION: Always clean with new brake fluid. Never clean with mineral oil such as gasoline and light oil. Torque Member Check the torque member for rust, wear, cracks or damage. Pistons Check the surface of the piston for rust, wear, cracks or damage. CAUTION: A piston sliding surface is plated. Never polish with sandpaper. Sliding Pin, Sliding Pin Boot and Bushing Check the sliding pins, sliding pin boots and bushing for rust, wear, cracks or damage. INSPECTION AFTER INSTALLATION • Check a drag of front disc brake. If any drag is found, follow the procedure described below. Remove brake pads. Refer to BR-103, "BRAKE PAD (1 PISTON TYPE) : Removal and Installation" . 2. Press the pistons. Refer to BR-103, "BRAKE PAD (1 PISTON TYPE) : Removal and Installation" . 3. Install brake pads. Refer to BR-103, "BRAKE PAD (1 PISTON TYPE) : Removal and Installation" 4. Depress the brake pedal several times. 5. Check a drag of front disc brake again. When any drag is found, disassemble the cylinder body and BR-112, "BRAKE CALIPER ASSEMBLY (1 PISTON TYPE) : Disassembly . • Burnish contact surfaces brake pads and disc rotor after refinishing or replacing disc rotor, or if a soft pedal occurs at very low mileage. Refer to BR-81, "BRAKE PAD : Inspection and Adjustment" . BRAKE CALIPER ASSEMBLY (2 PISTON TYPE) JPFIA0836ZZ JPFIA0837ZZ |
