PS-18
[F9Q]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
PFP:00030
Steering Wheel
EGS000NM
Steering Angle
EGS000NN
Steering Column
EGS000NO
Steering Linkage
EGS000NP
Steering wheel axial end play:
0 mm (0 in)
Steering wheel free play
0 - 35 mm (0 - 1.38 in)
Inner wheel
37.5
°
+1
°
−
3
°
Outer wheel
30.5
°
Steering column length L
560.9 mm (22.08 in)
STC1136D
Steering gear type
PR25T
Tie rod ball joint outer
socket
Tensile force
0.3 - 2.9 N·m (0.03 - 0.29 kg·m, 3 - 25 in-lb)
Measurement on spring balance
(Measuring point: stud bolt hole)
6.6 - 63.7N (0.67 - 6.50 kg, 1.48 - 14.32 lb)
Sliding torque
0.3 - 2.9 N·m (0.03 - 0.29 kg·m, 3 - 25 in-lb)
Axial end play
0.1 mm (0.004 in) or less
Tie rod ball joint inner
socket
Tensile force
0.1 - 7.8 N·m (0.01 - 0.79 kg·m, 1 - 69 in·lb)
Measured value of spring scale (measuring
point: mark)
0.3 - 24.3 N (0.03 - 2.48 kg, 0.07 - 5.46 lb)
Axial end play
0.1 mm (0.004 in) or less
Tie rod length L
130 mm (5.12 in)
STC1006D
