DLN-140

< ECU DIAGNOSIS INFORMATION >

[TRANSFER: TY30A]

AWD CONTROL UNIT

Fail Safe

INFOID:0000000010288308

AWD system

• If any malfunction occurs in AWD electrical system, and control unit detects the malfunction, AWD warning

lamp on combination meter turns ON to indicate system malfunction.

JRDWC2219GB

AWD CONTROL UNIT

DLN-141

< ECU DIAGNOSIS INFORMATION >

[TRANSFER: TY30A]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

• When AWD warning lamp is ON, vehicle changes to front-wheel drive or shifting driving force-AWD (rear

wheels still have some driving torque).

• AWD system activates its protection function (shuts down AWD system temporarily) if AWD system detects

high load continuously or the front wheel tire size differs from the rear tire size. (AWD system is automati-
cally restored if AWD system no longer detects any overload or the tire size difference is eliminated.)

*1: Quick blinking: 2 times/second (blinking for approx. 1 minute and then turned OFF)

*2: Slow blinking: 1 time/2 seconds (Continuing to blink until ignition switch is turned OFF)

DTC Inspection Priority Chart

INFOID:0000000010288309

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.

DTC Index

INFOID:0000000010288310

Mode

Warning

lamp

DTC

Detected area (Error area)

Error area and root cause

Protection

function

 Blinking

*1

—

AWD  control  unit

Transfer assembly in protection mode
(Internal temperature rise of electronic controlled coupling)

Blinking

*2

—

AWD control unit

Malfunction in each tire or different tire diameter

Fail-safe

ON

C1201

AWD control unit

Internal malfunction of AWD control unit

C1203

ABS actuator and electric
unit (control unit)

ABS malfunction
• Vehicle speed signal error
• Stop lamp switch signal (brake signal) error

C1204

AWD solenoid

Internal malfunction of electronic controlled coupling

C1205

AWD control unit

Internal malfunction of AWD control unit

C1209

AWD mode switch

Malfunction of AWD mode switch or AWD mode switch circuit

C1210

ECM

Malfunction of engine control system
• Accelerator pedal position signal error
• Engine speed signal error

P1804

AWD CONTROL UNIT

Internal malfunction of AWD control module

P181F

AWD CONTROL UNIT

Writing unit characteristics is incomplete

U1000

CAN communication line

• CAN communication error
• Malfunction of AWD control unit

U1010

AWD control unit

Malfunction of AWD control unit

Priority

Detected items (DTC)

1

• U1000 CAN COMM CIRCUIT
• U1010 CONTROL UNIT (CAN)

2

• C1201 CONTROLLER FAILURE
• C1205 AWD ACTUATOR RLY

3

• C1203 ABS SYSTEM
• C1210 ENGINE SIGNAL 1

4

• C1204 AWD SOLENOID
• C1209 MODE SW

5

• P1804 CONTROL UNIT 3
• P181F INCOMP CALIBRATION

DTC

Items

(CONSULT screen terms)

Reference

C1201

CONTROLLER FAILURE

DLN-111, "Description"

C1203

ABS SYSTEM

DLN-112, "Description"

C1204

AWD SOLENOID

DLN-113, "Description"

DLN-142

< ECU DIAGNOSIS INFORMATION >

[TRANSFER: TY30A]

AWD CONTROL UNIT

C1209

MODE SW

DLN-116, "Description"

C1210

ENGINE SIGNAL 1

DLN-119, "Description"

P1804

CONTROL UNIT 3

DLN-120, "DTC Logic"

P181F

INCOMP CALIBRATION

DLN-121, "DTC Logic"

U1000

CAN COMM CIRCUIT

DLN-122, "Description"

U1010

CONTROL UNIT (CAN)

DLN-123, "Description"

DTC

Items

(CONSULT screen terms)

Reference

AWD SYSTEM SYMPTOMS

DLN-143

< SYMPTOM DIAGNOSIS >

[TRANSFER: TY30A]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

SYMPTOM DIAGNOSIS

AWD SYSTEM SYMPTOMS

Symptom Table

INFOID:0000000010288311

If AWD warning lamp turns ON, perform self-diagnosis.

NOTE:

Light tight-corner braking symptom may occur depending on driving conditions. This is not malfunction.

Symptom

Condition

Check item

Reference

AWD warning lamp does not turn ON when
the ignition switch is turned to ON.
(AWD warning lamp check)

Ignition switch: ON

Power supply and ground for AWD con-
trol unit

DLN-144, "De-

scription"

CAN communication line

AWD control unit

Combination meter

AWD warning lamp does not turn OFF sev-
eral seconds after engine started.

Engine running

AWD control unit self-diagnosis

DLN-145, "De-

scription"

AWD warning lamp

Power supply and ground for AWD con-
trol unit

Heavy tight-corner braking symptom occurs
when the vehicle is driven and the steering
wheel is turned fully to either side after the
engine is started. (See NOTE.)

• While driving
• Steering wheel is

turned fully to either
sides

ECM self-diagnosis

DLN-146, "De-

scription"

AWD control unit self-diagnosis

AWD solenoid

Mechanical malfunction of electric con-
trolled coupling (clutch sticking etc.)

Vehicle does not enter AWD mode even
though AWD warning lamp turned to OFF.

While driving

CAN communication line

DLN-147, "De-

scription"

AWD solenoid

Mechanical malfunction of electric con-
trolled coupling (Mechanical engage-
ment of clutch is not possible.)

While driving, AWD warning lamp blinks
quickly. (When blinking in approx. 1 minute
and then turning OFF.)
Quick blinking: 2 times/second

While driving

Protection function is activated due to
heavy load to electric controlled cou-
pling. (AWD system is not malfunction-
ing. Also, optional distribution of torque
sometimes becomes rigid before lamp
blinks quickly, but it is not malfunction.)

DLN-148, "De-

scription"

While driving, AWD warning lamp blinks
slowly. (When continuing to blink until turn-
ing ignition switch OFF)
Slow blinking: 1 time/2 seconds

• While driving
• Vehicle speed: 20 km/h

(12 MPH) or more

Tire size is different between front and
rear of vehicle.

DLN-149, "De-

scription"
