DLN-32

< WIRING DIAGRAM >

[TRANSFER: TY21C]

4WD SYSTEM

JRDWC2522GB

DIAGNOSIS AND REPAIR WORK FLOW

DLN-33

< BASIC INSPECTION >

[TRANSFER: TY21C]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

BASIC INSPECTION

DIAGNOSIS AND REPAIR WORK FLOW

Work Flow

INFOID:0000000010755247

DETAILED FLOW

1.

INTERVIEW FROM THE CUSTOMER

Clarify customer complaints before inspection. First of all, perform an interview utilizing

DLN-34, "Diagnostic

Work Sheet"

 and reproduce symptoms as well as fully understand it. Ask customer about his/her complaints

carefully. Check symptoms by driving vehicle with customer, if necessary.

CAUTION:

Customers are not professional. Never guess easily like “maybe the customer means that...,” or
“maybe the customer mentions this symptom”.

>> GO TO 2.

2.

CHECK SYMPTOM

Reproduce the symptom that is indicated by the customer, based on the information from the customer
obtained by interview. Also check that the symptom is not caused by protection function. Refer to

DLN-26,

"Protection Function"

.

CAUTION:

When the symptom is caused by normal operation, fully inspect each portion and obtain the under-
standing of customer that the symptom is not caused by a malfunction.

>> GO TO 3.

3.

PERFORM SELF-DIAGNOSIS

With CONSULT

Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is any DTC detected?

YES

>> Record or print self-diagnosis results. GO TO 4.

NO

>> GO TO 6.

4.

RECHECK SYMPTOM

With CONSULT

1.

Erase self-diagnostic results for “ALL MODE AWD/4WD”.

2.

Perform DTC confirmation procedures for the error detected system.

NOTE:
If some DTCs are detected at the same time, determine the order for performing the diagnosis based on

DLN-

26, "DTC Inspection Priority Chart"

.

Is any DTC detected?

YES

>> GO TO 5.

NO

>> Check harness and connectors based on the information obtained by interview. Refer to

GI-41,

"Intermittent Incident"

.

5.

REPAIR OR REPLACE ERROR-DETECTED PARTS

• Repair or replace error-detected parts.
• Reconnect part or connector after repairing or replacing.
• When DTC is detected, erase self-diagnostic results for “ALL MODE AWD/4WD”.

>> GO TO 7.

6.

IDENTIFY ERROR-DETECTED SYSTEM BY SYMPTOM DIAGNOSIS

Estimate error-detected system based on symptom diagnosis and perform inspection.
Can the error-detected system be identified?

DLN-34

< BASIC INSPECTION >

[TRANSFER: TY21C]

DIAGNOSIS AND REPAIR WORK FLOW

YES

>> GO TO 7.

NO

>> Check harness and connectors based on the information obtained by interview. Refer to

GI-41,

"Intermittent Incident"

.

7.

FINAL CHECK

With CONSULT

1.

Check the reference value for 4WD control unit.

2.

Recheck the symptom and check that symptom is not reproduced on the same conditions.

Is the symptom reproduced?

YES

>> GO TO 3.

NO

>> INSPECTION END

Diagnostic Work Sheet

INFOID:0000000010755248

Description

• In general, customers have their own criteria for a problem. Therefore, it is important to understand the

symptom and status well enough by asking the customer about his/her concerns carefully. To systemize all
the information for the diagnosis, prepare the interview sheet referring to the interview points.

• In some cases, multiple conditions that appear simultaneously may cause a DTC to be detected.

Interview sheet sample

Interview sheet

Customer
name

MR/MS

Registration
number

Initial year
registration

Vehicle type

VIN

Storage date

Engine

Mileage

km (Mile)

Symptom

†

Vehicle does not enter 4WD mode.

†

4WD warning (4WD Error) is displayed.

†

Heavy tight-corner braking symptom occurs

†

Noise

†

Vibration

†

Others

(

)

First occurrence

†

Recently

†

Others (

)

Frequency of occurrence

†

Always

†

Under a certain conditions of

†

Sometimes (time(s)/day)

Climate con-
ditions

†

Irrelevant

Weather

†

Fine

†

Cloud

†

Rain

†

Snow

†

Others (

)

Temperature

†

Hot

†

Warm

†

Cool

†

Cold

†

Temperature (Approx.

°

C)

Relative humidity

†

High

†

Moderate

†

Low

Road conditions

†

Urban area

†

Suburb area

†

High way

†

Mounting road (uphill or down hill)

†

Rough road

Operation conditions, etc.

†

Irrelevant

†

When engine starts

†

During idling

†

During driving

†

During acceleration

†

At constant speed driving

†

During deceleration

†

During cornering (right curve or left curve)

DIAGNOSIS AND REPAIR WORK FLOW

DLN-35

< BASIC INSPECTION >

[TRANSFER: TY21C]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

Other conditions

Memo

Interview sheet

Customer
name

MR/MS

Registration
number

Initial year
registration

Vehicle type

VIN

Storage date

Engine

Mileage

km (Mile)
