Nissan Qashqai J11. Manual - part 372





ECK-48

< SYSTEM DESCRIPTION >

[K9K]

OPERATION

SET SPEED RANGE

Speed limiter system can be set the following vehicle speed.

SWITCH OPERATION

OIL CONTROL SYSTEM

OIL CONTROL SYSTEM : Switch Name and Function

INFOID:0000000010289662

SWITCHES AND INDICATORS

SWITCH OPERATION

RESET OPERATION

CAUTION:

When an alert was displayed, change the engine oil, and reset the engine oil data.
1.

Turn ignition switch ON.

2.

On information display, select “Settings” >> “Maintenance” >> “Service”.

3.

Press “ENTER” switch until “YES/NO” is appeared.

1.

Speed limiter indicator

2.

CANCEL switch

3.

ACCL/RES switch

4.

COAST/SET switch

5.

Speed limiter MAIN Switch

6.

ASCD MAIN switch

A.

On the combination meter

B.

On the steering wheel

Minimum speed (Approx.)

Maximum speed (Approx.)

30 km/h (20 MPH)

180 km/h (119 MPH)

Item

Function

CANCEL switch

Cancels the speed limiter control.

ACCL/RES switch

• Resumes the set speed.
• Increases the set speed incrementally.

COAST/SET switch

• Sets desired speed.
• Decreases the set speed incrementally.

Speed limiter MAIN switch

Master switch to activate the speed limiter system.

A.

Combination meter

B.

Steering

1.

Information display

2.

Enter/Up/Down switch

3.

Back switch

4.

Display switch

JSBIA5023ZZ

Item

Function

Steering switch

Refer to

MWI-26, "Switch Name and Function"

.

OPERATION

ECK-49

< SYSTEM DESCRIPTION >

[K9K]

C

D

E

F

G

H

I

J

K

L

M

A

ECK

N

P

O

4.

Select “YES”.

5.

Check that “– – –” is displayed.

STOP/START SYSTEM

STOP/START SYSTEM : Switch Name and Function

INFOID:0000000010289663

SWITCHES AND INDICATORS

SWITCH OPERATION

NOTE:
If stop/start OFF switch turn ON when stop/start system is operating, stop/start system is canceled and engine
restart.

1.

Stop/start indicator lamp

2.

Stop/start OFF switch

A.

On the combination meter

B.

Lower instrument panel (driver side)

JSBIA3803ZZ

Item

Function

Stop/start OFF switch

When the switch is pressed, switch indicator (LED) turns ON and the stop/start
system can be deactivated.

ECK-50

< SYSTEM DESCRIPTION >

[K9K]

HANDLING PRECAUTION

HANDLING PRECAUTION

Precaution for Stop/Start System

INFOID:0000000010499112

PRECAUTIONS FOR STOP/START SYSTEM OPERATION

The operation of the stop/start system needs to satisfy various conditions. For details of the conditions, refer to

ECK-39, "STOP/START SYSTEM : System Description"

.

The stop/start system may not operate under the conditions listed below:
• After restarting the engine, the vehicle is repeatedly stopped and started at a low speed due to traffic con-

gestion.

• When driving the vehicle repeatedly back and forth at a low speed due to parallel parking.
• When the intelligent key is not authenticated. (In this case, the KEY warning lamp built in the combination

meter blinks.)

• The battery is deteriorated. (High discharge rate.)
• A battery other than the stop/start system-specific battery is used.
• Ambient temperature is extremely low.

HANDLING PRECAUTIONS

• When engine restart conditions are satisfied during the electric parking brake operation, ECM performs the

engine restart after the completion of the electric parking brake operation. This may cause delay in engine
restart, compared with a usual engine restart.
For a smooth engine restart under the stop/start system operating condition, restart the engine before
releasing the parking brake.

• To use the stop/start system, the vehicle needs to recognize the status of battery. For this reason, the stop/

start system may not be activated immediately after battery change.

• When restarting the vehicle under stop/start system operating condition, continue depressing the clutch

pedal until the restart completes.

ON BOARD DIAGNOSTIC (OBD) SYSTEM

ECK-51

< SYSTEM DESCRIPTION >

[K9K]

C

D

E

F

G

H

I

J

K

L

M

A

ECK

N

P

O

ON BOARD DIAGNOSTIC (OBD) SYSTEM

Diagnosis Description

INFOID:0000000010289665

DESCRIPTION

This system uses two malfunction indicator lamps. When detecting a system error, ECM turns ON the mal-
function indicator lamp to alert the driver of the presence of malfunction.

MALFUNCTION INDICATOR LAMP (MIL) (YELLOW)

ECM turns ON MIL (yellow) when an emission-related malfunction occurs or when a component part specified
by European laws and regulations becomes inoperable three trips in a raw.

MALFUNCTION INDICATOR LAMP (MIL) (RED)

ECM may turn ON MIL (red) when a malfunction occurs in the engine.
