DAS-234

< WIRING DIAGRAM >

[CHASSIS CONTROL]

CHASSIS CONTROL

WIRING DIAGRAM

CHASSIS CONTROL

Wiring Diagram

INFOID:0000000010416980

JROWC2551GB

DAS

CHASSIS CONTROL

DAS-235

< WIRING DIAGRAM >

[CHASSIS CONTROL]

C

D

E

F

G

H

I

J

K

L

M

B

N

P

A

JROWC2210GB

DAS-236

< WIRING DIAGRAM >

[CHASSIS CONTROL]

CHASSIS CONTROL

JROWC2211GB

DAS

DIAGNOSIS AND REPAIR WORK FLOW

DAS-237

< BASIC INSPECTION >

[CHASSIS CONTROL]

C

D

E

F

G

H

I

J

K

L

M

B

N

P

A

BASIC INSPECTION

DIAGNOSIS AND REPAIR WORK FLOW

Work Flow

INFOID:0000000010416981

DETAILED FLOW

1.

INTERVIEW FROM THE CUSTOMER

Clarify customer complaints before inspection. First of all, perform an interview utilizing

DAS-238, "Diagnostic

Work Sheet"

 and reproduce the symptom as well as fully understand it. Ask customer about his/her complaints

carefully. Check symptoms by driving vehicle with customer, if necessary.

CAUTION:

Customers are not professional. Never guess easily like “maybe the customer means that...,” or
“maybe the customer mentions this symptom”.

>> GO TO 2.

2.

CHECK SYMPTOM

Reproduce the symptom that is indicated by the customer, based on the information from the customer
obtained by the interview. Also check that the symptom is not caused by fail-safe mode. Refer to

DAS-230,

"Fail-Safe (Chassis Control Module)"

.

CAUTION:

When the symptom is caused by normal operation, fully inspect each portion and obtain the under-
standing of customer that the symptom is not caused by a malfunction.

>> GO TO 3.

3.

PERFORM SELF-DIAGNOSIS

With CONSULT

1.

Perform “Self Diagnostic Result“ for “CHASSIS CONTROL“.

Is DTC detected?

YES

>> Record or print self-diagnosis results and freeze frame data (FFD). GO TO 4.

NO

>> Inspection End.

4.

RECHECK THE SYMPTOM

With CONSULT

Perform DTC confirmation procedures for the malfunctioning system.
NOTE:
If some DTCs are detected at the some time, determine the order for performing the diagnosis based on

DAS-

231, "DTC Inspection Priority Chart"

.

Is DTC detected?

YES

>> GO TO 5.

NO

>> Check harness and connectors based on the information obtained by the interview. Refer to

DAS-

210, "Precautions for Harness Repair"

.

5.

REPAIR OR REPLACE MALFUNCTIONING PARTS

1.

Repair or replace malfunctioning parts.

2.

Reconnect part or connector after repairing or replacing.

3.

When DTC is detected, erase “Self Diagnostic Result“ for “CHASSIS CONTROL”.

>> GO TO 6.

6.

FINAL CHECK

With CONSULT

1.

Check the reference value for “CHASSIS CONTROL”.

2.

Recheck the symptom and check that the symptom is not reproduced on the same conditions.
