Nissan Qashqai J11. Manual - part 2200

DAS-214

< SYSTEM DESCRIPTION >

[CHASSIS CONTROL]

SYSTEM

• Assist at breaking - To enhance braking feel, Active Engine Brake

adds deceleration by shifting the CVT gear ratio to lower side
depending on the driver’s brake pedal operation.

System Description - Active Ride Control

INFOID:0000000010416970

The Active Ride Control function can be turned ON/OFF by turning the VDC OFF switch ON/OFF.

• Engine control - Enhances ride comfort by adding/subtracting

engine torque in an effort to control the front and rear wheel load
balance.

• Engine control - Enhances handling by adding/subtracting engine

torque in an effort to control the front and rear wheel load balance.

• Brake control - Enhances ride comfort by restraining upper body

movement with small amount of brake control when driving on
bumpy roads.

System Description - Active Trace Control

INFOID:0000000010416971

Active Trace Control function controls the braking utilizing the ABS actuator and electric unit (control unit),
depending on cornering condition calculated from driver’s steering input and plural sensors. Active Trace Con-
trol function is aimed to enhance traceability at corners and smooth the vehicle movement to provide confident
driving.

ALOIA0209GB

ALOIA0210GB

ALOIA0211GB

ALOIA0212GB

DAS

SYSTEM

DAS-215

< SYSTEM DESCRIPTION >

[CHASSIS CONTROL]

C

D

E

F

G

H

I

J

K

L

M

B

N

P

A

Active Trace Control function can be switched ON/OFF through the "Chassis Control" settings on the vehicle
information display. When the Active Trace Control is selected OFF, some functions will be kept ON to assist
driver (for example, avoidance condition).
When the VDC OFF switch is used to turn OFF the VDC system, the Active Trace Control system is also com-
pletely turned OFF.
• Steady cornering - The change of forward and lateral acceleration

is smoothened by applying the necessary amount of brake pres-
sure.

• Transient steering input - Reduces lag of yaw rate against steering

operation.

• Acceleration at corners - Restrains understeer by applying the nec-

essary amount of brake pressure to the inner wheels.

• Quick lane change - achieves stable vehicle behavior at quick

steering operation by applying the necessary amount of brake
pressure to the appropriate wheels.

Fail-Safe (Chassis Control Module)

INFOID:0000000010499276

When a malfunction occurs in the chassis control module, the master warning lamp turns ON and an interrupt
is displayed on the information display of the combination meter.

ALOIA0213GB

ALOIA0214GB

ALOIA0215GB

ALOIA0216GB

DAS-216

< SYSTEM DESCRIPTION >

[CHASSIS CONTROL]

SYSTEM

DTC

Vehicle condition

C1B92-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control
• Active Engine Brake

C1B93-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control (engine)
• Active Engine Brake

C1B94-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control (engine)

C1B95-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control (brake)

C1B99-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control
• Active Engine Brake

C1BA0-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control (brake)

C1BA2-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control (engine)

C1BA5-00

Normal control

C1BAB-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control (engine)

C1BB2-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control
• Active Engine Brake

C1BB3-00

C1BB4-00

C1BB5-00

C1BB6-00

Normal control

C1BB7-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control
• Active Engine Brake

C1BB8-00

C1BB9-00

C1BBA-00

C1BBB-00

C1BBC-00

Normal control

C1BBD-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control
• Active Engine Brake

C1BC0-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control

C1BC1-00

C1BC2-00

C1BC3-00

C1BC4-00

The following functions are suspended.
• Active Ride Control (brake)

C1BC5-00

The following functions are suspended.
• Active Trace Control

DAS

SYSTEM

DAS-217

< SYSTEM DESCRIPTION >

[CHASSIS CONTROL]

C

D

E

F

G

H

I

J

K

L

M

B

N

P

A

C1BC6-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control (brake)

U1A34-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control
• Active Engine Brake

U1A35-00

U1A36-00

U1A39-00

Normal control

U1A3B-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control (brake)
• Active Engine Brake

U1A42-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control (engine)

U1A43-00

U1A48-00

The following functions are suspended.
• Active Trace Control
• Active Ride Control
• Active Engine Brake

U1A4A-00

U1A4B-00

U1A4E-00

The following functions are suspended.
• Active Ride Control

DTC

Vehicle condition
