MWI-40
< ECU DIAGNOSIS INFORMATION >
COMBINATION METER
DTC Index
INFOID:0000000010329963
Warning lamp/
indicator lamp
ABS warning lamp
Turned on by suspending communication.
Brake warning lamp
EPS warning lamp
VDC warning lamp
AWD warning lamp
Malfunction indicator lamp
VDC OFF indicator lamp
Turned off by suspending communication.
SPORT mode indicator lamp
AWD LOCK indicator lamp
Engine oil pressure warning lamp
High beam indicator lamp
Turn signal indicator lamp
Position lamp indicator lamp
A/T CHECK indicator lamp
Low tire pressure warning lamp
After blinking for 1 minute, the lamp remains
ON.
Function
Specifications
Display contents of CONSULT
Time
Diagnostic item is detected when...
Refer to
CAN COMM CIRCUIT
[U1000]
CRNT, 1 - 39
Combination meter is not transmitting or receiving CAN
communication signal for 2 seconds or more.
CONTROL UNIT (CAN)
[U1010]
CRNT, 1 - 39
Detecting error during the initial diagnosis of CAN control-
ler of combination meter.
VEHICLE SPEED
[B2205]
CRNT, 1 - 39
The abnormal vehicle speed signal is input from ABS ac-
tuator and electric unit (control unit) for 2 seconds or more.
ENGINE SPEED
[B2267]
CRNT, 1 - 39
ECM continuously transmits abnormal engine speed sig-
nals for 2 seconds or more.
WATER TEMP
[B2268]
CRNT, 1 - 39
ECM continuously transmits abnormal engine coolant tem-
perature signals for 60 seconds or more.
OIL LEV SEN SHORT
[B2321, B2322]
CRNT, 1 - 39
ECM continuously transmits abnormal engine oil level sig-
nals for 60 seconds or more.
ILLUMINATION OUTPUT CIR-
CUIT
[B2323]
CRNT, 1 - 39
ECM continuously transmits abnormal illumination control
signals for 60 seconds or more.
