Nissan Qashqai J11. Manual - part 193

ECH-70

< ECU DIAGNOSIS INFORMATION >

[HRA2DDT]

ECM

132

(R)

136

(L)

Throttle control motor
(Open)

Output

[Ignition switch: ON]
• Engine stopped
• Gear position: 1st
• Accelerator pedal: Fully depressed

1.40 V

133

(GR)

—

Sensor power supply
(Camshaft position sen-
sor)

—

[Ignition switch: ON]

5 V

134

(Y)

—

Sensor ground
(Camshaft position sen-
sor)

—

—

—

135

(L)

134

(Y)

Camshaft position sensor

Input

[Engine is running]
• Warm-up condition
• Idle speed

NOTE:
The pulse cycle changes depending
on rpm at idle

2.56 - 3.09

[Engine is running]
• Engine speed is 2,000 rpm

2.56 - 2.83

136

(L)

132

(R)

Throttle control motor
(Close)

Output

[Ignition switch: ON]
• Engine stopped
• Gear position:1st
• Accelerator pedal: Fully released

1.4 V

137

(P)

106

(BR)

Sensor power supply
(Turbocharger boost sen-
sor)

—

[Ignition switch: ON]

5 V

143
(W)

29

(B)

PNP signal

Input

[Ignition switch: ON]
• Gear position: Neutral

Battery voltage

(11 - 14 V)

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

−

Signal name

Input/

Output

JSBIA4770ZZ

JSBIA4771ZZ

JSBIA4772ZZ

JSBIA4773ZZ

ECM

ECH-71

< ECU DIAGNOSIS INFORMATION >

[HRA2DDT]

C

D

E

F

G

H

I

J

K

L

M

A

ECH

N

P

O

DTC Index

INFOID:0000000010379038

X: Applicable —: Not applicable

153

(LG)

29

(B)

Fuel injector No. 1 (HI)

Output

[Engine is running]
• Warm-up condition
• Idle speed

NOTE:
The pulse cycle changes depending
on rpm at idle

BATTERY VOLTAGE

(11 - 14 V)

154

(LG)

Fuel injector No. 3 (HI)

155

(P)

Fuel injector No. 2 (HI)

[Engine is running]
• Engine speed is 2,000 rpm

BATTERY VOLTAGE

(11 - 14 V)

156
(W)

Fuel injector No. 4 (HI)

157

(R)

29

(B)

Fuel injector No. 1 (LO)

Output

[Engine is running]
• Warm-up condition
• Idle speed

NOTE:
The pulse cycle changes depending
on rpm at idle

BATTERY VOLTAGE

(11 - 14 V)

158

(SB)

Fuel injector No. 3 (LO)

159

(V)

Fuel injector No. 2 (LO)

[Engine is running]
• Engine speed is 2,000 rpm

BATTERY VOLTAGE

(11 - 14 V)

160

(B)

Fuel injector No. 4 (LO)

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

−

Signal name

Input/

Output

JSBIA4774ZZ

JSBIA4775ZZ

JSBIA4776ZZ

JSBIA4777ZZ

DTC*

Items

(CONSULT screen item)

Trip

MIL

Fault code

Reference page

U0111

COMMUNICATION ERROR (LOST)

10

–

08, 63

ECH-126

U0121

LOST COMM (ABS)

10

–

87

ECH-127

U0298

COMMUNICATION ERROR (LOST)

10

–

01

ECH-128

U0299

COMMUNICATION ERROR (LOST)

10

–

08

ECH-130

U0315

VEHICLE SPEED

10

–

82, 86, 87

ECH-132

U0415

ABS CONTROL MODULE

10

–

64, 82

ECH-133

B1900

DC/DC CONVERTER

10

–

01

ECH-134

B1901

DC/DC CONVERTER

10

–

01

ECH-136

B1902

DC/DC CONVERTER

10

–

01

ECH-138

B1903

DC/DC CONVERTER

10

–

01

ECH-140

ECH-72

< ECU DIAGNOSIS INFORMATION >

[HRA2DDT]

ECM

B1904

—

10

–

01

ECH-142

P0001

FUEL VOLUME REGULATOR

3

×

11, 12, 13

ECH-143

P0010

CAMSHAFT POS ACTUATOR A B1

10

–

11, 12, 13

ECH-145

P0011

CAMSHAFT POSITION A B1

10

–

77, 78, 92

ECH-147

P0013

CAMSHAFT POS ACTUATOR B B1

10

–

11, 12, 13

ECH-149

P0014

CAMSHAFT POSITION B B1

10

–

77, 78, 92

ECH-151

P0016

CKP/S A - CMP/S A CORRELATION B1

3

×

62

ECH-153

P0017

CKP/S B - CMP/S B CORRELATION B1

3

×

62

ECH-155

P0033

TC/SC BYPASS VALVE A

10

–

16, 17

ECH-157

P0089

FUEL PRESSURE REGULATOR 1

10

–

63

ECH-159

P0090

FUEL PRESSURE REGULATOR 1

1

×

77

ECH-160

P0095

INTAKE AIR TEMPERATURE 2 B1

3

×

16, 17

ECH-162

P0105

ABSOL PRESS SENSOR [P0105]

3

×

16, 17

ECH-164

P0106

MAP/BAROMETRIC PRESS SENSOR

3

×

64

ECH-166

P0115

COOLANT TEMP SEN [P0115]

3

×

16, 17, 2F

ECH-168

P0120

THROTTLE POSI SEN [P0120]

3

×

29

ECH-170

P012A

TC/SC INLET PRESSURE SENSOR

3

×

16, 17

ECH-172

P0130

O2 SENSOR 1 B1

1 or 3

×

09, 11, 12, 13

ECH-175

P0135

O2 SENSOR 1 HEATER B1

3

×

11, 12, 13

ECH-177

P0136

O2 SENSOR 2 B1

3

×

11, 12, 13

ECH-179

P0141

O2 SENSOR 2 HEATER B1

3

×

11, 12, 13

ECH-181

P0170

FUEL TRIM B1

3

×

09

ECH-183

P0190

FUEL RAIL PRESSURE SENSOR A

1 or 3

×

16, 17, 64

ECH-186

P0201

INJECTOR CIRC-CYL1 [P0201]

3

×

11, 12, 13, 24

ECH-188

P0202

INJECTOR CIRC-CYL2 [P0202]

3

×

11, 12, 13, 24

ECH-188

P0203

INJECTOR CIRC-CYL3 [P0203]

3

×

11, 12, 13, 24

ECH-188

P0204

INJECTOR CIRC-CYL4 [P0204]

3

×

11, 12, 13, 24

ECH-188

P0217

ENG COOLANT TEMP

10

–

98

ECH-191

P0220

THROTTLE/PEDAL POSI SEN/SW B

3

×

29

ECH-194

P0225

THROTTLE/PEDAL POSI SEN/SW C

3

×

16 or 17

ECH-196

P0226

THROTTLE/PEDAL POSI SEN/SW C

1 or 3

×

 or –

64, F1, F2, F3

ECH-198

P0243

TC/SC WASTEGATE SOLENOID A

3

×

11, 12, 13

ECH-200

P025A

FUEL PUMP MODULE A

1

×

00, 11, 12

ECH-202

P0300

MULTI CYL MISFIRE [P0300]

3

×

66, F8

ECH-204

P0301

CYL 1 MISFIRE [P0301]

3

×

66, F8

ECH-204

P0302

CYL 2 MISFIRE [P0302]

1 or 3

×

66, F8

ECH-204

P0303

CYL 3 MISFIRE [P0303]

1 or 3

×

66, F8

ECH-204

P0304

CYL 4 MISFIRE [P0304]

1 or 3

×

66, F8

ECH-204

P0313

MISFIRE DETECTED

1 or 3

×

66, F8

ECH-204

P0315

CRANKSHAFT POSITION SYSTEM

3

×

09

ECH-206

P0325

KNOCK SENSOR [P0325]

3

–

1C

ECH-208

P0335

CRANK POS SEN (OBD) [P0335]

3

×

25, 29, 31, 38,

62, 64, 96

ECH-210

P0340

CAMSHAFT POSI SEN [P0340]

3

×

29, 31, 38, 64

ECH-212

DTC*

Items

(CONSULT screen item)

Trip

MIL

Fault code

Reference page

ECM

ECH-73

< ECU DIAGNOSIS INFORMATION >

[HRA2DDT]

C

D

E

F

G

H

I

J

K

L

M

A

ECH

N

P

O

*: This number is prescribed by ISO 15031-6.

P0351

IGNITION COIL A

3

×

11, 12, 13

ECH-215

P0352

IGNITION COIL B

3

×

11, 12, 13

ECH-215

P0353

IGNITION COIL C

3

×

11, 12, 13

ECH-215

P0354

IGNITION COIL D

3

×

11, 12, 13

ECH-215

P0365

CAMSHAFT POSITION SENSOR B B1

3

×

29, 31, 38, 64

ECH-219

P0420

CATALYST SYSTEM

3

×

09

ECH-221

P0443

CANISTER PURGE VALVE

3 or 10

×

 or –

11, 12, 13

ECH-223

P0530

A/C REFRIGERANT PRESSURE SEN A

16, 17

ECH-225

P0560

BATTERY VOLTAGE

3 or 10

×

 or –

16, 17, 61

ECH-228

P0564

CRUISE CONTROL

10

–

15, 29, 1C

ECH-230

P0575

CRUISE CONTROL

10

–

64

ECH-232

P0597

THERMOSTAT

3 or 10

×

 or –

11, 12, 13

ECH-234

P0606

CONTROL MODULE

3

×

04

ECH-236

P060A

INTERNAL CONTROL MODULE

1

×

49

ECH-237

P060B

INTERNAL CONTROL MODULE

3

×

49

ECH-238

P061A

INTERNAL CONTROL MODULE

1 or 3 or 10

×

 or –

61, 62, 64, F9

ECH-239

P062D

FUEL INJECTOR DRIVER B1

3

×

8F, F7

ECH-240

P062E

FUEL INJECTOR DRIVER B2

3

×

8F, F7

ECH-241

P0638

THROTTLE ACTUATOR B1

1

×

77

ECH-242

P0641

SENSOR REFERENCE VOLTAGE A

1

×

16, 17

ECH-246

P0651

SENSOR REFERENCE VOLTAGE B

1

×

16, 17

ECH-248

P0657

ACTUATORS SUPPLY VOLTAGE A

10

–

11

ECH-250

P0697

SENSOR REFERENCE VOLTAGE C

1

×

16, 17

ECH-252

P0833

CLUTCH PEDAL SWITCH B

10

–

62

ECH-254

P10AA

CONTROL MODULE

3

×

16, 17, 25

ECH-258

P1512

STARTER MOTOR

10

–

01

ECH-259

P1525

CRUISE CONTROL/SPEED LIMITER

10

–

F3

ECH-260

P1589

NEUTRAL SWITCH

10

–

29, 64

ECH-261

P158A

CLUTCH SWITCH

10

–

62

ECH-263

P160C

CONTROL MODULE

3

×

04

ECH-267

P1650

—

10

–

72, 73

ECH-269

P1655

—

10

–

01

ECH-272

P1656

ENGINE RESTART BYPASS RELAY

10

–

01

ECH-276

P1675

ENGINE COOLANT TEMPERATURE

1

×

98

ECH-280

P2100

THROTTLE ACTUATOR A

3

×

01

ECH-283

P2119

THROTTLE ACTUATOR A

3

×

07, 75, 91

ECH-285

P2120

THROTTLE/PEDAL POSI SEN/SW D

3

×

16, 17

ECH-288

P2135

THRTL/PDL POS SEN/SW A/B CRL TN

3 or 10

×

 or –

64, 2F

ECH-291

P2263

TC/SC BOOST SYSTEM

3

×

21, 22

ECH-293

P2504

CHARGING SYSTEM

10

–

01, 79

ECH-295

DTC*

Items

(CONSULT screen item)

Trip

MIL

Fault code

Reference page
