BODY ALIGNMENT

MEASUREMENT POINTS

Unit: mm (in)

: Vehicle front

JSKIA3928ZZ

Point

Material

Point

Material

Cowl top positioning mark of center positioning
mark















Center pillar indent

Upper front roof rail flange end of center position-
ing mark







Rear fender indent



Outer side body joggle

Trans control reinforcement hole center of center
positioning mark 12

×

14 (0.47

×

0.55)

BODY ALIGNMENT

BRM-309

< SERVICE DATA AND SPECIFICATIONS (SDS)

[FOR RUSSIA]

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

Rear Body

INFOID:0000000010499732

MEASUREMENT

Dimensions marked with

″

*

″

 indicate symmetrically identical dimensions on both the right and left hand of the

vehicle.

«The others»

Unit: mm (in)

MEASUREMENT POINTS



Outer side body indent



Rear seat crossmember hole center

:

φ

16 (0.63)

: 18

×

16 (0.71

×

0.63)







Front pillar indent















Door hinge installing hole center







:

φ

12 (0.47)







:

φ

9 (0.35)

Point

Material

Point

Material

Unit: mm (in)

JSKIA3915GB

Point

Dimension

Memo

Point

Dimension

Memo

Point

Dimension

Memo

 –

987 (38.86)*

 –

688 (27.09)*

 –

578 (22.76)*

BRM-310

< SERVICE DATA AND SPECIFICATIONS (SDS)

[FOR RUSSIA]

BODY ALIGNMENT

Unit: mm (in)

: Vehicle front

JSKIA3916ZZ

Point

Material

Point

Material

Roof flange end of center positioning mark



Lower rear pillar reinforcement joggle



Rear fender extension joggle



Back door lock support hole center

φ

14 (0.55)



Lower back pillar main joggle

LOCATION OF PLASTIC PARTS

BRM-311

< SERVICE DATA AND SPECIFICATIONS (SDS)

[FOR RUSSIA]

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

LOCATION OF PLASTIC PARTS

Precautions for Plastics

INFOID:0000000010499733

CAUTION:

• When repairing and painting a portion of the body adjacent to plastic parts, consider their characteristics (influence of heat

and solvent) and remove them if necessary or take suitable measures to protect them.

• Plastic parts should be repaired and painted using methods suiting the materials

,

 characteristics.

Abbre-

viation

Material name

Heat resisting

temperature

°

C (

°

F)

Resistance to gasoline and

solvents

Other cautions

PE

Polyethylene

60 (140)

Gasoline and most solvents are
harmless if applied for a very
short time (wipe out quickly).

Flammable

ABS

Acrylonitrile Butadiene Styrene

80 (176)

Avoid gasoline and solvents.

—

AES

Acrylonitrile Ethylene Styrene

80 (176)

↑

—

EPM/
EPDM

Ethylene Propylene (Diene) co-
polymer

80 (176)

Gasoline and most solvents are
harmless if applied for a very
short time (wipe out quickly).

Flammable

PS

Polystyrene

80 (176)

Avoid solvents.

Flammable

PVC

Poly Vinyl Chloride

80 (176)

Gasoline and most solvents are
harmless if applied for a very
short time (wipe out quickly).

Poisonous gas is emitted
when burned.

TPO

Thermoplastic Olefine

80 (176)

↑

Flammable

AAS

Acrylonitrile Acrylic Styrene

85 (185)

Avoid gasoline and solvents.

—

PMMA

Poly Methyl Methacrylate

85 (185)

↑

—

EVAC

Ethylene Vinyl Acetate

90 (194)

↑

—

PP

Polypropylene

90 (194)

Gasoline and most solvents are
harmless if applied for a very
short time (wipe out quickly).

Flammable, avoid bat-
tery acid.

PUR

Polyurethane

90 (194)

Avoid gasoline and solvents.

—

UP

Unsaturated Polyester

90 (194)

↑

Flammable

ASA

Acrylonitrile Styrene Acrylate

100 (212)

↑

Flammable

PPE

Poly Phenylene Ether

110 (230)

↑

—

TPU

Thermoplastic Urethane

110 (230)

↑

—

PBT+
PC

Poly Butylene Terephthalate +
Polycarbonate

120 (248)

↑

Flammable

PC

Polycarbonate

120 (248)

↑

—

POM

Poly Oxymethylene

120 (248)

↑

Avoid battery acid.

PA

Polyamide

140 (284)

↑

Avoid immersing in wa-
ter.

PBT

Poly Butylene Terephthalate

140 (284)

↑

—

PAR

Polyarylate

180 (356)

↑

—

PET

Polyethylene terephthalate

180 (356)

↑

—

PEI

Polyetherimide

200 (392)

↑

—
