DIAGNOSIS SYSTEM (BCM)

DLK-681

< SYSTEM DESCRIPTION >

[TYPE 5]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

KEY CYL SW-TR

NOTE:
This item is displayed, but cannot be monitored

TR CANCEL SW

NOTE:
This item is displayed, but cannot be monitored

TRUNK LID OPENER SW

NOTE:
This item is displayed, but cannot be monitored

BACK DOOR OEPENR SW

Indicates [On/Off] condition of back door opener switch

RKE-TR/BD

NOTE:
This item is displayed, but cannot be monitored

Monitor Item

Contents

DLK-682

< ECU DIAGNOSIS INFORMATION >

[TYPE 5]

BCM

ECU DIAGNOSIS INFORMATION

BCM

List of ECU Reference

INFOID:0000000010672318

ECU

Reference

BCM

BCS-63, "Reference Value"

BCS-87, "Fail-safe"

BCS-88, "DTC Inspection Priority Chart"

BCS-89, "DTC Index"

DOOR & LOCK SYSTEM

DLK-683

< WIRING DIAGRAM >

[TYPE 5]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

WIRING DIAGRAM

DOOR & LOCK SYSTEM

LHD

LHD : Wiring Diagram

INFOID:0000000011487300

JRKWE3958GB

DLK-684

< WIRING DIAGRAM >

[TYPE 5]

DOOR & LOCK SYSTEM

JRKWE3959GB
