Nissan Qashqai J11. Manual - part 1155
HAC-256
< ECU DIAGNOSIS INFORMATION >
[MANUAL HEATER ]
A/C AMP.
DTC Index
INFOID:0000000010433422
25
(GR)
Ground
Air mix door motor drive 3
Output
• Ignition switch ON
• Immediately after the tem-
perature control dial is op-
erated (when the air mix
door motor operates)
26
(P)
Ground
Air mix door motor drive 4
27
(LG)
Ground
Intake door motor drive 3
Output
• Ignition switch ON
• Immediately after the IN-
TAKE switch is operated
(when intake door motor
operates)
28
(R)
Ground
Intake door motor drive 4
29
(L)
Ground
Mode door motor drive 3
Output
• Ignition switch ON
• Immediately after the each
MODE switch is operated
(when mode door motor
operates)
30
(G)
Ground
Mode door motor drive 4
Terminal No.
(Wire color)
Description
Condition
Value
+
−
Signal name
Input/
Output
JPIIA1647GB
JPIIA1647GB
JPIIA1647GB
DTC
Items
(CONSULT screen terms)
Reference
U1000
CAN COMM CIRCUIT
U1010
CONTROL UNIT (CAN)
B24B7
INTAKE DOOR MOTOR
[CIRCUIT SHORT TO BATTERY]
[CIRC SHORT TO GRND OR OPEN]
B24B9
MODE DOOR MOTOR
[CIRCUIT SHORT TO BATTERY]
[CIRC SHORT TO GRND OR OPEN]
B24BB
LEFT AIR MIX DOOR MOTOR
[CIRCUIT SHORT TO BATTERY]
[CIRC SHORT TO GRND OR OPEN]
