HA-98 < PRECAUTION > [TYPE 3] PRECAUTIONS • Explain that recovery of the contaminated refrigerant could damage service equipment and refrigerant sup- ply. • Suggest the customer return the vehicle to the location of previous service where the contamination may have occurred. • In case of repairing, recover the refrigerant using only dedicated equipment and containers. Never recover contaminated refrigerant into the existing service equipment. Contact a local refrigerant prod- • The air conditioner warranty is void if the vehicle is within the warranty period. Please contact Nissan Cus- tomer Affairs for further assistance. REFRIGERANT CONNECTION A new type refrigerant connection has been introduced to all refrigerant lines except the following location. WARNING: Check that all refrigerant is discharged into the recycling equipment and the pressure in the system is CAUTION: Observe the following when replacing or cleaning refrigerant cycle components. to do so will cause lubricant to enter the low-pressure chamber. • Use always a torque wrench and a back-up wrench when connecting tubes. Never remove the seal caps of pipes and other components until just before required for connection. • Allow components stored in cool areas to warm to working area temperature before removing seal caps. This prevents condensation from forming inside A/C components. • Remove thoroughly moisture from the refrigeration system before charging the refrigerant. apply lubricant to threaded portion. • O-ring must be closely attached to the groove portion of tube. installed to tube correctly. • Perform leakage test and make sure that there is no leakage from connections after connecting line. Disconnect that line and replace the O-ring when the refrigerant leaking point is found. Then tighten COMPRESSOR CAUTION: RHA861F |
