P0138 HO2S2 EC-285 < DTC/CIRCUIT DIAGNOSIS > [MR FOR NISMO RS MODELS] C D E F G H I J K L M A EC N P O Is the inspection result normal? YES >> INSPECTION END NO >> GO TO 4. 4. CHECK HEATED OXYGEN SENSOR 2-II Check the voltage between ECM harness connector and ground as per the following condition. Is the inspection result normal? YES >> INSPECTION END NO >> GO TO 5. 5. CHECK HEATED OXYGEN SENSOR 2-III Check the voltage between ECM harness connector and ground as per the following condition. Is the inspection result normal? YES >> INSPECTION END NO >> GO TO 6. 6. REPLACE HEATED OXYGEN SENSOR 2 Replace heated oxygen sensor 2. Refer to . CAUTION: • Discard any sensor which has been dropped from a height of more than 0.5 m (19.7 in) onto a hard surface such as a concrete floor; use a new one. • Before installing new sensor, clean exhaust system threads using Oxygen Sensor Thread Cleaner [commercial service tool (J-43897-18 or J43897-12)] and approved Anti-seize Lubricant (commercial service tool). >> INSPECTION END ECM Condition Voltage Connector + − Terminal F25 29 33 Revving up to 4,000 rpm under no The voltage should be above 0.68 V ECM Condition Voltage Connector + − Terminal F25 29 33 Keeping engine speed at idle for 10 The voltage should be above 0.68 V ECM Condition Voltage Connector + − Terminal F25 29 33 Coasting from 80 km/h (50 MPH) in The voltage should be above 0.68 V |
