Nissan Juke F15. Manual - part 74





BCS

BCM

BCS-51

< ECU DIAGNOSIS INFORMATION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

34

(V)

Ground

Combination switch
OUTPUT 3

Output

Combination
switch

All switches OFF
(Wiper intermittent dial 4)

7.0 - 8.0 V

Lighting switch 2ND
(Wiper intermittent dial 4)

1.2 V

Lighting switch HI
(Wiper intermittent dial 4)

Rear washer switch ON
(Wiper intermittent dial 4)

Any of the condition below
with all switches OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 3

35

(R)

Ground

Combination switch
OUTPUT 2

Output

Combination
switch
(Wiper intermit-
tent dial 4)

All switches OFF

7.0 - 8.0 V

Lighting switch 2ND

1.2 V

Lighting switch PASS

Front wiper switch INT

Front wiper switch HI

36

(P)

Ground

Combination switch
OUTPUT 1

Output

Combination
switch
(Wiper intermit-
tent dial 4)

All switches OFF

7.0 - 8.0 V

Turn signal switch RH

1.2 V

Turn signal switch LH

Front wiper switch LO

Front wiper switch MIST

Front washer switch ON

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

PKIB4960J

PKIB4958J

PKIB4960J

PKIB4958J

PKIB4960J

PKIB4958J

BCS-52

< ECU DIAGNOSIS INFORMATION >

[WITH INTELLIGENT KEY SYSTEM]

BCM

37

(G)

Ground Detention switch

Input

Selector lever

P position (Release selec-
tor button)

0 V

P position (Push selector
button)

12 V

Any position other than P

38

(SB)

Ground

Receiver communi-
cation

Input/

Output

Ignition switch
OFF (Remote
keyless entry
communication)

Waiting

ñÒ12 V

When operating either
button on Intelligent Key

Ignition switch
ON (TPMS
communication)

Waiting

When receiving signal
from tire pressure sensor

39

(L)

Ground CAN-H

Input/

Output

40

(P)

Ground CAN-L

Input/

Output

43

(P)

Ground Back door switch

Input

Back door
switch

OFF
(When back door closed)

7.0 - 8.0 V

ON
(When back door opened)

0 V

44

(LG)

Ground

Rear wiper stop po-
sition

Input

Ignition switch
ON

Rear wiper stop position

12 V

Any position other than
rear wiper stop position

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JMMIA0572GB

JMMIA0573GB

JMMIA0574GB

PKIB4960J

BCS

BCM

BCS-53

< ECU DIAGNOSIS INFORMATION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

45

(R)

Ground

Passenger door
switch

Input

Passenger door
switch

OFF (When passenger
door closed)

7.0 - 8.0 V

ON (When passenger
door opened)

0 V

46

(LG)

Ground Rear RH door switch

Input

Rear RH door
switch

OFF (When rear RH door
closed)

7.0 - 8.0 V

ON (When rear RH door
opened)

0 V

47

(SB)

Ground Driver door switch

Input

Driver door
switch

OFF (When driver door
closed)

7.0 - 8.0 V

ON (When driver door
opened)

0 V

48

(BR)

Ground Rear LH door switch

Input

Rear LH door
switch

OFF (When rear LH door
closed)

7.0 - 8.0 V

ON (When rear door LH
opened)

0 V

49

(L)

Ground Luggage room lamp

Output

Luggage room
lamp

OFF

12 V

ON

0 V

51

(Y)

Ground

Back door request
switch

Input

Back door re-
quest switch

ON (Pressed)

0 V

OFF (Not pressed)

12 V

53

(GR)

Ground Back door open

Output

Back door

OFF (Actuator is not acti-
vated)

0 V

OPEN (Actuator is activat-
ed)

12 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

PKIB4960J

PKIB4960J

PKIB4960J

PKIB4960J

BCS-54

< ECU DIAGNOSIS INFORMATION >

[WITH INTELLIGENT KEY SYSTEM]

BCM

54

(P)

Ground Rear wiper

Output

Rear wiper

OFF (Stopped)

0 V

ON (Activated)

12 V

55

(G)

Ground Rear door UNLOCK

Output

Rear door

UNLOCK (Actuator is acti-
vated)

12 V

Other than UNLOCK (Ac-
tuator is not activated)

0 V

56

(P)

Ground

Interior room lamp
power supply

Output

Interior room lamp battery saver is activated.
(Cuts the interior room lamp power supply)

0 V

Interior room lamp battery saver is not acti-
vated.
(Outputs the interior room lamp power sup-
ply)

12 V

57

(P)

Ground

Battery power sup-
ply

Input

Ignition switch OFF

Battery voltage

59

(SB)

Ground

Passenger door UN-
LOCK

Output

Passenger door

UNLOCK (Actuator is acti-
vated)

12 V

Other than UNLOCK (Ac-
tuator is not activated)

0 V

60

(V)

Ground Turn signal LH

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch LH

6.0 V

61

(W)

Ground Turn signal RH

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch RH

6.0 V

63

(BR)

Ground

Interior room lamp
control

Output

Interior room
lamp

OFF

12 V

ON

0 V

64

*4

(R)

Ground Cranking request

input

Ignition switch OFF

3.6 V

Ignition switch
ON

Engine stopped (Selector
lever is in P position)

0 V

Engine stopped (Selector
lever is not in P position)

12 V

Engine running

12 V

65

(V)

Ground All doors LOCK

Output

All doors

LOCK (Actuator is activat-
ed)

12 V

Other than LOCK (Actua-
tor is not activated)

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

PKIC6370E

PKIC6370E
