EC-1022

< ECU DIAGNOSIS >

[MR18DE]

ECM

DRIVING PATTERN

• The time required for each diagnosis varies with road surface conditions, weather, altitude, individual driving

habits, etc.
Zone A refers to the range where the time, required for the diagnosis under normal conditions*, is the short-
est.
Zone B refers to the range where the diagnosis can still be performed if the diagnosis is not completed within
zone A.

*: Normal conditions refer to the following:

PBIB3651E

ECM

EC-1023

< ECU DIAGNOSIS >

[MR18DE]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

• Sea level
• Flat road
• Ambient air temperature: 20 - 30

°

C (68 - 86

°

F)

• Diagnosis is performed as quickly as possible under normal conditions.

Under different conditions [For example: ambient air temperature other than 20 - 30

°

C (68 - 86

°

F)], diagno-

sis may also be performed.

Pattern 1:
• The engine is started at the engine coolant temperature of

−

10 to 35

°

C (14 to 95

°

F)

(where the voltage between the ECM terminal 46 and ground is 3.0 - 4.3V).

• The engine must be operated at idle speed until the engine coolant temperature is greater than 70

°

C

(158

°

F) (where the voltage between the ECM terminal 46 and ground is lower than 1.4V).

• The engine is started at the fuel tank temperature of warmer than 0

°

C (32

°

F) (where the voltage

between the ECM terminal 95 and ground is less than 4.1V).

Pattern 2:
• When steady-state driving is performed again even after it is interrupted, each diagnosis can be conducted.

In this case, the time required for diagnosis may be extended.

Test Value and Test Limit

INFOID:0000000001161996

The following is the information specified in Service $06 of ISO 15031-5.
The test value is a parameter used to determine whether a system/circuit diagnostic test is OK or NG while
being monitored by the ECM during self-diagnosis. The test limit is a reference value which is specified as the
maximum or minimum value and is compared with the test value being monitored.
These data (test value and test limit) are specified by Test ID (TID) and Component ID (CID) and can be dis-
played on the GST screen.

SRT item

Self-diagnostic test item

DTC

Test value

(GST display)

Test limit

TID

CID

CATALYST

Three way catalyst function

P0420

01H

01H

Max.

P0420

02H

81H

Min.

HO2S

Heated oxygen sensor 1

P0133

09H

04H

Max.

P1143

0AH

84H

Min.

P1144

0BH

04H

Max.

P0132

0CH

04H

Max.

P0134

0DH

04H

Max.

Heated oxygen sensor 2

P0139

19H

86H

Min.

P1147

1AH

86H

Min.

P1146

1BH

06H

Max.

P0138

1CH

06H

Max.

HO2S HTR

Heated oxygen sensor 1 heater

P0135

29H

08H

Max.

2AH

88H

Min.

Heated oxygen sensor 2 heater

P0141

2DH

0AH

Max.

2EH

8AH

Min.

EC-1024

< SYMPTOM DIAGNOSIS >

[MR18DE]

ENGINE CONTROL SYSTEM
