DLK-462 < REMOVAL AND INSTALLATION > [WITH I-KEY & SUPER LOCK] REAR DOOR LOCK REAR DOOR LOCK Component Parts Location INFOID:0000000001732028 Removal and Installation INFOID:0000000001732029 REMOVAL 1. Remove the partition glass. Refer to XX-XX, "*****" . 2. Support door glass while lifting it up to the door window completely closed position. 3. Remove inside handle bolt, slide handle toward rear of vehicle, 4. Disconnect the inside handle and lock knob cables from the CAUTION: During removal and installation, do not to bend the ends of 1. Rear door 2. Inside handle 3. Inside handle cable 4. Door lock assembly 5. TORX bolt (T30) 6. Outside handle cable 7. Grommet 8. TORX bolt (T30) 9. Rear gasket 10. Outside handle escutcheon 11. Outside handle 12. Front gasket 13. Lock knob cable 14. Outside handle bracket PIIB6530E PIIB6524E PIIB6525E |
