WT-2

< PRECAUTION >

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000001716758

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the SRS section.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.

PREPARATION

WT-3

< PREPARATION >

C

D

F

G

H

I

J

K

L

M

A

B

WT

N

O

P

PREPARATION

PREPARATION

Special Service Tool

INFOID:0000000001716759

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Commercial Service Tool

INFOID:0000000001716760

Tool number
(Kent-Moore No.)
Tool name

Description

KV991B1000
(J-45295)
Transmitter activation tool

• Transmitter wake up operation
• ID registration procedure

WEIA0144E

Tool name

Description

Power tool

Removing wheel nuts

PBIC0190E

WT-4

< SYMPTOM DIAGNOSIS >

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000001716761

Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.

×

: Applicable

Reference page

WT

-6

WT

-5



WT

-6

WT

-7

FA

X

-4

, "

NV

H T

rou

bl

es

ho

oti

n

g

 Cha

rt

"

,

FSU-5,

 "

NVH T

ro

u

b

les

h

oot

in

g Ch

art

"

RAX-2, "

NVH T

roub

le

sh

oo

tin

g

 Ch

art

"

,

RSU-2, "

NVH T

ro

ubl

es

ho

ot

ing

 Cha

rt

"

Re

fe

r to

 TI

RE

S

 in

 th

is

 ch

ar

t

Re

fe

r to

ROA

D

 WHEEL

 in

 th

is ch

art

F

AX-4, "

NVH T

rou

bl

es

ho

ot

in

g

 Cha

rt

"

BR-5,

 "

NVH T

ro

u

b

les

ho

ot

ing

 Ch

art

"

ST

-5

, "

NVH T

rou

bl

es

ho

ot

in

g

 Cha

rt

"

Possible cause and SUSPECTED PARTS

Im

pro

per in

st

a

lla

ti

on

lo

os

en

es

s

Ou

t-

of

-ro

un

d

Im

ba

lan

c

e

Incorrect tire pressure

Un

ev

en

 ti

re

 we

ar

De

fo

rm

at

io

n

 o

da

ma

ge

No

n-u

n

if

orm

it

y

In

corre

ct tire

 si

ze

FRONT AXLE AND F

R

ONT

 SUSPENSI

ON

REAR AXLE AND RE

AR SUSPENSI

ON

TIRES

ROA

D

 WHEELS

DRIVE SHA

F

T

BRAKE

STEERI

N

G

Symptom

TIRES

Noise

×

×

×

×

×

×

×

×

×

×

×

×

×

Shake

×

×

×

×

×

×

×

×

×

×

×

×

×

Vibration

×

×

×

×

×

×

Shimmy

×

×

×

×

×

×

×

×

×

×

×

×

×

Shudder

×

×

×

×

×

×

×

×

×

×

×

×

Poor quality ride
or handling

×

×

×

×

×

×

×

×

×

×

ROAD WHEEL

Noise

×

×

×

×

×

×

×

×

×

×

Shake

×

×

×

×

×

×

×

×

×

×

Shimmy, Shud-
der

×

×

×

×

×

×

×

×

×

Poor quality ride
or handling

×

×

×

×

×

×

×

ROAD WHEEL

WT-5

< ON-VEHICLE MAINTENANCE >

C

D

F

G

H

I

J

K

L

M

A

B

WT

N

O

P

ON-VEHICLE MAINTENANCE

ROAD WHEEL

Inspection

INFOID:0000000001716762

ALUMINUM WHEEL

1.

Check tires for wear and improper inflation.

2.

Check wheels for deformation, cracks and other damage. If deformed, remove wheel and check wheel
runout.

a.

Remove tire from aluminum wheel and mount on a tire balance machine.

b.

Set dial indicator as shown.

STEEL WHEEL

1.

Check tires for wear and improper inflation.

2.

Check wheels for deformation, cracks and other damage. If deformed, remove wheel and check wheel
runout.

a.

Remove tire from steel wheel and mount on a tire balance machine.

b.

Set two dial indicators as shown.

c.

Set each dial indicator to 0.

d.

Rotate wheel and check dial indicators at several points around
the circumference of the wheel.

e.

Calculate runout at each point as shown.

f.

Select maximum positive runout value and the maximum nega-
tive value.
Add the two values to determine total runout. In case a positive
or negative value is not available, use the maximum value (neg-
ative or positive) for total runout. If the total runout value
exceeds the limit, replace steel wheel.

Wheel runout
(Dial indicator value)

: Refer to

WT-7, "Road Wheel"

.

SFA975B

Radial runout = (A+B)/2

Lateral runout = (C+D)/2

Wheel runout

: Refer to

WT-7, "Road Wheel"

.

SEIA0558E
