ENGINE MAINTENANCE (HR16DE)
MA-25
< ON-VEHICLE MAINTENANCE >
C
D
E
F
G
H
I
J
K
L
M
B
MA
N
O
A
11. Refill reservoir tank to “MAX” level line with engine coolant.
12. Repeat steps 6 through 11 two or more times with radiator cap installed until engine coolant level no
longer drops.
13. Check cooling system for leaks with engine running.
14. Warm up engine, and check for sound of engine coolant flow while running engine from idle up to 3,000
rpm with heater temperature controller set at several position between “COOL” and “WARM”.
• Sound may be noticeable at heater unit.
15. Repeat step 14 three times.
16. If sound is heard, bleed air from cooling system by repeating steps 6 through 11 until engine coolant level
no longer drops.
FLUSHING COOLING SYSTEM
1.
Install reservoir tank if removed.
2.
Install radiator drain plug.
• If water drain plug on cylinder block is removed, close and tighten it. Refer to
CAUTION:
Be sure to clean radiator drain plug and install with new O-ring. Refer to
3.
Fill radiator and reservoir tank with water and reinstall radiator cap.
4.
Run engine and warm it up to normal operating temperature.
5.
Rev engine two or three times under no-load.
6.
Stop engine and wait until it cools down.
7.
Drain water from the cooling system. Refer to
CO-11, "Changing Engine Coolant"
.
8.
Repeat steps 1 through 7 until clear water begins to drain from radiator.
RADIATOR
RADIATOR : Checking Radiator
INFOID:0000000001730858
Check radiator for mud or clogging. If necessary, clean radiator as follows.
• Be careful not to bend or damage radiator fins.
• When radiator is cleaned without removal, remove all surrounding parts such as cooling fan, radiator shroud
and horns. Then tape harness and connectors to prevent water from entering.
1.
Apply water by hose to the back side of the radiator core vertically downward.
2.
Apply water again to all radiator core surface once per minute.
3.
Stop washing if any stains no longer flow out from radiator.
4.
Blow air into the back side of radiator core vertically downward.
• Use compressed air lower than 490 kPa (4.9 bar, 5 kg/cm
2
, 71 psi) and keep distance more than 30 cm
(11.8 in).
5.
Blow air again into all the radiator core surfaces once per minute until no water sprays out.
FUEL LINES
FUEL LINES : Inspection
INFOID:0000000001277610
Inspect fuel lines, filler cap and tank for improper attachment, leaks,
cracks, damage, loose connections, chafing or deterioration.
If necessary, repair or replace damaged parts.
AIR CLEANER FILTER
SMA803A
