Theft-alarm system
z One of the doors and the liftgate is opened
z Except for vehicles equipped with the
NOTE
without using the keyless entry system or
F.A.S.T.-key, if the ignition switch is
z The alarm will continue to operate for 3 min-
the F.A.S.T.-key operation.
turned to the “ON” position.
utes. At the end of that period, the alarm will
z The engine hood is opened.
z For vehicles equipped with the F.A.S.T.-
automatically shut off to save battery power.
key, if the operation mode is put in ON.
The system will then be rearmed until the
z All doors and the liftgate are unlocked by
Type of alarm
proper disarming step is taken.
using the keyless entry system or the
N00582500053
z The alarm will resume if unauthorized
actions are taken again, even if the alarm has
F.A.S.T.-key operation.
5
When the alarm is activated:
stopped.
Disarm...by using the keyless entry system or
1. The headlights blink on and off for 3 min-
F.A.S.T.-key operation
utes.
After 3 minutes the headlights automati-
Alarm deactivation
cally shut off.
N00582600041
2. The horn will sound intermittently for 3
The alarm can be deactivated in the following
minutes.
ways.
Horn sounds!
z By using the keyless entry system or the
Headlights blink on and off!
F.A.S.T.-key operation to lock or unlock
the doors and liftgate.
z Except for vehicles equipped with the
NOTE
F.A.S.T.-key, by turning the ignition
z
If the UNLOCK button on the key, or the
switch to the “ON” position.
driver’s
or
front
passenger’s door
z For vehicles equipped with the F.A.S.T.-
lock/unlock switch is pressed when all doors
key, by putting the operation mode in ON.
and the liftgate are closed and no door is
opened within approximately 30 seconds, re-
Disarmed stage
arming will automatically occur.
N00510501257
The system will be disarmed if the following
operation is performed.
5-42
Features and controls
Power window control
6. Disarm the system by unlocking all doors
NOTE
WARNING
and the liftgate by using the keyless entry
z
The amount of time after unlocking until the
z Before operating the power windows,
system or the F.A.S.T.-key operation.
vehicle relocks automatically can be
make sure that nothing is capable of being
adjusted. See an authorized Mitsubishi
trapped (head, hands, fingers, etc.) in the
Motors dealer for details.
window.
Power window control
On vehicles equipped with the Smartphone-
z Never leave the vehicle without carrying
N00510801436
link Display Audio
(SDA) or the Smart-
the key.
phone-link Display Audio (SDA) navigation
z Never leave children or unreliable adults
5
system, the functions can be adjusted on the
unattended inside the vehicle.
screen. For details, refer to a separate
owner’s manual.
z
Once the system has been disarmed, it can-
Main switch
not be rearmed except by repeating the arm-
N00548701238
ing procedure.
Type 1
Testing the theft-alarm system
N00510601160
The main switch located on the driver’s door
Use the following procedure to test the sys-
1-
Open (down)
can be used to operate all the windows.
tem:
2-
Close (up)
A window can be opened or closed by operat-
ing the corresponding switch.
1. Lower the driver’s window.
Press the switch down to open the window,
2. Arm the system as explained in “Armed
NOTE
and pull up the switch to close it.
stage”.
z
Never try to operate the main switch and
If the driver’s door window switch is fully
3. Make sure that the theft-alarm indicator
sub-switch in different directions at the same
pressed down/pulled up, the driver’s door
comes on and flashes for approximately
time. This will freeze the window in posi-
tion.
window automatically opens/closes com-
20 seconds.
z
Operating the power windows repeatedly
pletely.
4. Wait a few seconds and then unlock the
with the engine stopped will run down the
If you want to stop the window movement,
driver’s side door by using the inside door
battery. Use the window switches only while
operate the switch lightly in the reverse direc-
lock knob. Open the door.
the engine is running.
tion.
5. Make sure that the horn sounds intermit-
tently and the headlights blink when a
door is opened.
Features and controls
5-43
Power window control
Sub-switches
N00548801138
5
1- Driver’s door window switch
1- Driver’s door window switch
2- Front passenger’s door window switch
2- Front passenger’s door window switch
3- Left rear door window switch
3- Left rear door window switch
1- Open
4- Right rear door window switch
4- Right rear door window switch
2- Close
5- Lock switch
5- Lock switch
Each sub-switch can be used for its own door
Type 2
NOTE
window, unless the driver’s window lock
z
If the switch is operated repeatedly in a
switch is activated.
short, choppy manner while the door window
The main switch located on the driver’s door
is open, the safety mechanism may not work
can be used to operate all the windows.
NOTE
properly, which may momentarily make it
A window can be opened or closed by operat-
z The rear door windows open only half-way.
impossible to automatically open or close the
ing the corresponding switch.
door window. Should this occur, pull the
Press the switch down to open the window,
switch upwards until the window is com-
and pull up the switch to close it.
pletely closed. The window should now open
Power window timer function
If the door window switch is fully pressed
and close properly.
N00548901171
down/pulled up, the door window automati-
The power windows can be opened or closed
cally opens/closes completely.
when the ignition switch is in the “ON” posi-
If you want to stop the window movement,
tion or the operation mode is in ON.
operate the switch lightly in the reverse direc-
The door windows can be opened or closed
tion.
for a
30-second period after the engine is
5-44
Features and controls
Power window control
stopped. However, once the driver’s door or
Safety mechanism
CAUTION
the front passenger’s door is opened, the
N00528801233
z
Do not deliberately trap your hands or head
power windows cannot be operated.
in order to activate the safety mechanism.
Your hand or head could be trapped and per-
Type 1
Lock switch
sonal injury could result.
N00549001182
If a hand or head is trapped, for safety the
When this switch is in the lock mode, the sub-
driver’s door window is automatically low-
switches cannot be used to open or close the
NOTE
5
ered a little.
door windows, and the main switch will open
z
The safety mechanism can be activated if the
After the door window is lowered, clear the
or close only the driver’s door window. To
driving conditions or other circumstances
obstruction, then pull up the switch again to
cause the driver’s door window to be sub-
unlock the switch, press it again.
close the driver’s door window.
jected to a physical shock similar to that
caused by trapped hand or head.
z
If the following operation is performed, the
WARNING
safety mechanism will be cancelled and the
z
If the battery terminals are disconnected
driver’s door window will not automatically
or the fuse for power window is replaced,
open/close completely.
the safety mechanism will be cancelled.
• When the battery terminals are discon-
If a hand or head got trapped, a serious
nected.
injury could result.
• When the fuse for power window is
replaced.
• When the safety mechanism is activated
CAUTION
five or more times consecutively.
z
The safety mechanism is deactivated just
In such a case, the following procedure
1-
Lock
before the door window closes. This allows
should be implemented to rectify this situa-
2- Unlock
the door window to close completely. There-
tion.
fore be especially careful that fingers are not
If the window is open, repeatedly raise the
trapped in the door window opening.
driver’s door window switch until that win-
WARNING
z
The safety mechanism is deactivated while
dow has been fully closed. Following this,
z Before driving with a child in the vehicle,
the switch is pulled up. Therefore be espe-
release the switch, raise the switch once
be sure to lock the window switch to make
cially careful that fingers are not trapped in
again and hold it in this condition for at least
it inoperative. Children tampering with
the door window opening.
1 second, then release it. You should now be
the switch could easily trap their hands or
able to operate the driver’s door window in
heads in the window.
the normal fashion.
Features and controls
5-45
Power panoramic sunroof (if so equipped)
Type 2
NOTE
What to do if you hear wind
z
The safety mechanism can be activated if the
buffeting when driving
If a hand or head is trapped, for safety the
driving conditions or other circumstances
N00551400043
cause the door window to be subjected to a
door window is automatically lowered a little.
Wind buffeting can be described as the per-
physical shock similar to that caused by
After the door window is lowered, clear the
trapped hand or head.
ception of pressure on the ears or a booming
obstruction, then pull up the switch again to
z
If the following operation is performed, the
or rumbling sound. Your vehicle may exhibit
close the door window.
safety mechanism will be cancelled and the
wind buffeting when driving with one or both
5
door window will not automatically
rear door windows down or partially opened.
WARNING
open/close completely.
This is a normal occurrence that can be mini-
z
If the battery terminals are disconnected
• When the battery terminals are discon-
mized. If the buffeting occurs with the rear
or the fuse for power window is replaced,
nected.
door windows open, open the front door win-
the safety mechanism will be cancelled.
• When the fuse for power window is
dows as well as the rear door windows to
If a hand or head got trapped, a serious
replaced.
minimize the condition.
injury could result.
• When the safety mechanism is activated
five or more times consecutively.
In such a case, the following procedure
Power panoramic sunroof (if
CAUTION
should be implemented to rectify this situa-
so equipped)
tion.
z
The safety mechanism is deactivated just
N00594700036
If the window is open, repeatedly raise the
before the door window closes. This allows
appropriate window switch until that win-
the door window to close completely. There-
dow has been fully closed. Following this,
WARNING
fore be especially careful that fingers are not
release the switch, raise the switch once
trapped in the door window opening.
z Do not put head, hands or anything else
again and hold it in this condition for at least
z
The safety mechanism is deactivated while
out of the front sunroof opening while
1 second, then release it. You should now be
the switch is pulled up. Therefore be espe-
driving the vehicle.
able to operate the door window in the nor-
cially careful that fingers are not trapped in
z Never leave children or unreliable adults
mal fashion.
the door window opening.
unattended inside the vehicle.
z
Do not deliberately trap your hands or head
z Never leave the vehicle without carrying
in order to activate the safety mechanism.
the key.
Your hand or head could be trapped and per-
z Before operating the front sunroof, front
sonal injury could result.
shade, or rear shade, make sure that noth-
ing is capable of being trapped
(head,
hands, fingers, etc.) in the front sunroof,
front shade, or rear shade.
5-46
Features and controls
Power panoramic sunroof (if so equipped)
WARNING
NOTE
z
Because the front sunroof opens to the
z Be sure to close the front sunroof completely
outside of the vehicle, do not open the sun-
when washing the vehicle or when leaving
roof when cleaning the top of the roof, etc.
the vehicle.
Your hands or arms could be trapped.
z After washing the vehicle or after rain be
sure to wipe off any water that is on the front
sunroof before operating it.
NOTE
z Operating the front sunroof, front shade, or
5
z
When leaving the vehicle unattended, be
rear shade repeatedly with the engine turned
sure to close the front sunroof and carry the
off will run down the battery. Operate the
key.
front sunroof, front shade, and rear shade
only while the engine is running.
z
Do not try to operate the front sunroof if it is
frozen closed
(after snow fall or during
extreme cold).
Front sunroof & front shade
z
Do not sit or place heavy luggage on the
1-
Open (front sunroof)
front sunroof or roof opening edge.
2-
Tilt up (front sunroof)
The front sunroof & front shade can be
z
Do not apply any force that may cause dam-
3-
Close (front sunroof)
age to the sunroof.
opened or closed with the ignition switch in
4-
Tilt down (front sunroof)
z
Release the switch when the front sunroof,
the “ON” position or the operation mode in
5-
Open (front shade)
front shade, or rear shade starts to move.
ON.
6-
Close (front shade)
z
If the front sunroof, front shade, or rear
shade does not operate when the switch is
operated, release the switch and check
Opening the front sunroof
whether something is trapped by the sunroof
or shade. If nothing is trapped, we recom-
mend you to have the sunroof or shade
Press the switch in direction (1) to open the
checked at an authorized Mitsubishi Motors
front sunroof automatically.
dealer.
To stop the sunroof before it is fully open,
z
Be careful when tilting up the front sunroof
operate the switches in any of the directions
if a ski carrier or a roof carrier is installed.
(1) to (6).
Depending on the model of ski carrier or roof
carrier, the front sunroof may contact the car-
rier when the front sunroof is tilted up.
Features and controls
5-47
Power panoramic sunroof (if so equipped)
To stop the shade before it is fully closed,
NOTE
NOTE
operate the switches in any of the directions
z The front sunroof automatically stops just
z Depending on the position of the front shade,
(1) to (6).
before reaching the fully open position to
the front shade will open together with the
reduce wind noise.
front sunroof.
Press the switch again to fully open it.
NOTE
z Depending on the position of the front shade,
z If the front sunroof is open, it will close
the front shade will open together with the
together with the front shade.
Tilting down the front sunroof
front sunroof.
5
Press the switch in direction (3) or pull the
Timer function
switch in direction (4) to fully close the front
Closing the front sunroof
sunroof automatically.
Within approximately 30 seconds after the
Press the switch in direction (3) to fully close
ignition switch is changed to
“ACC” or
NOTE
the front sunroof automatically.
“OFF” or the operation mode is changed to
z When you press the switch in direction (6),
To stop the sunroof before it is fully closed,
ACC or OFF, the front sunroof and front
the front sunroof will close slightly, and then
operate the switches in any of the directions
shade can be opened and closed.
the sunroof and front shade will fully close
(1) to (6).
However, if the driver’s or front passenger’s
automatically.
door is opened within 30 seconds after the
NOTE
ignition switch is changed to
“ACC” or
“OFF” or the operation mode is changed to
z When you press the switch in direction (6),
Opening the front shade
the front sunroof will close slightly, and then
ACC or OFF, the front sunroof and front
the sunroof and front shade will fully close
shade cannot be opened or closed.
Press the switch in direction (5) to fully open
automatically.
the front shade automatically.
To stop the shade before it is fully open, oper-
Safety mechanism
ate the switches in any of the directions (1) to
Tilting up the front sunroof
(6).
If a person’s hand, neck, etc., is trapped in the
front sunroof or front shade, the front sunroof
Press the switch in direction (2) to raise the
or front shade will automatically open a max-
Closing the front shade
rear edge of the front sunroof as it opens.
imum of 8 inches (20 cm) as a safety func-
tion. After the front sunroof and front shade
Press the switch in direction (6) to fully close
open, you can use the switch to close them.
the front shade automatically.
5-48
Features and controls
Power panoramic sunroof (if so equipped)
If the safety mechanism operates five times or
CAUTION
more consecutively, you will not be able to
z
The safety mechanism is cancelled just
close the front sunroof and front shade nor-
before the front sunroof and front shade are
mally.
fully closed. This allows the front sunroof
If this occurs, perform the following proce-
and front shade to close completely. There-
dure to reset the safety mechanism.
fore be especially careful that no fingers are
trapped in the front sunroof and front shade.
1. Press and hold the switch in direction (3)
or pull and hold the switch in direction
5
(4).
NOTE
2. The front sunroof
(if open) and front
z
The safety mechanism can be activated if the
shade will move to the fully closed posi-
driving conditions or other circumstances
tions in small increments.
cause the front sunroof or the front shade to
be subjected to a physical shock similar to
NOTE
that caused by a trapped hand or head.
7-
Open (rear shade)
z If the front sunroof and front shade are both
z
Do not release the switch until the resetting
8-
Close (rear shade)
open, the front sunroof will move to the fully
procedure is finished. If you release the
closed position, and then the front shade will
switch, the resetting mode will be cancelled.
move to the fully closed position.
To perform the resetting procedure again,
Opening the rear shade
repeat the procedure from step 1.
3. When the front sunroof and front shade
Press the switch in direction (7) to fully open
have both stopped in the fully closed posi-
the rear shade automatically.
tions, release the switch.
(The resetting
Rear shade
To stop the shade before it is fully open, press
procedure is finished.)
the switch in direction (7) or (8).
The rear shade can be opened or closed with
If the front sunroof and front shade do not
the ignition switch in the “ON” position or
move correctly to the fully closed positions
Closing the rear shade
the operation mode in ON.
after you perform the resetting procedure,
contact an authorized Mitsubishi Motors
Press the switch in direction (8) to fully close
dealer.
the rear shade automatically.
To stop the shade before it is fully closed,
press the switch in direction (7) or (8).
Features and controls
5-49
Parking brake
Safety mechanism
NOTE
Lever type parking brake (if so
z The safety mechanism can be activated if the
equipped)
If a person’s hand, neck, etc., is trapped in the
driving conditions or other circumstances
N00593100059
cause the rear shade to be subjected to a
rear shade, the shade will automatically open
physical shock similar to that caused by a
a maximum of 8 inches (20 cm) as a safety
trapped hand or head.
To apply
function. After the rear shade opens, you can
z Do not release the switch until the resetting
use the switch to close it.
procedure is finished. If you release the
5
If the safety mechanism operates five times or
switch, the resetting mode will be cancelled.
more consecutively, you will not be able to
To perform the resetting procedure again,
close the rear shade normally.
repeat the procedure from step 1.
If this occurs, perform the following proce-
dure to reset the safety mechanism.
Parking brake
1. Press and hold the switch in direction (8).
2. The rear shade will move to the fully
N00511401527
closed position in small increments.
To park the vehicle, first bring it to a com-
3. When the rear shade has stopped in the
plete stop, firmly apply the parking brake,
fully closed position, release the switch.
and then move the selector lever to the “P”
1-
Pull the lever up without pressing the
(The resetting procedure is finished.)
(PARK) position.
button at the end of hand grip.
Make sure the brake warning light is illumi-
When the parking brake is set and the
If the rear shade does not move correctly to
nated.
ignition switch is in the “ON” position,
the fully closed positions after you perform
or the operation mode is in ON the
the resetting procedure, contact an authorized
brake warning light in the instrument
Mitsubishi Motors dealer.
cluster will come on.
CAUTION
When parking on a hill, set the parking brake,
z The safety mechanism is cancelled just
and turn the front wheels toward the curb on a
before the rear shade is fully closed. This
downhill, or away from the curb on an uphill.
allows the rear shade to close completely.
Therefore be especially careful that no fin-
gers are trapped in the rear shade.
5-50
Features and controls
Parking brake
To release
CAUTION
NOTE
z
Before driving, be sure that the parking
z
You may hear an operation noise from the
brake is fully released and brake warning
vehicle body when operating the Electric
light is off.
parking brake. This does not indicate a mal-
If you drive without the parking brake fully
function and the Electric parking brake is
released, the warning display will appear on
operating normally.
the information screen in the multi-informa-
z
When the battery is weak or dead, the Elec-
tion display.
tric parking brake cannot be applied or
5
If a vehicle is driven without releasing the
released. Refer to “Jump-starting the engine”
parking brake, the brakes will be overheated,
on page 8-2.
resulting in ineffective braking and possible
z
You may feel the brake pedal moving when
brake failure.
operating the Electric parking brake.
This does not indicate a malfunction.
Warning light
1-
Pull the lever up slightly.
2-
Press and hold the button at the end of
or
the hand grip.
To apply
3-
Pressing the lever downward.
Warning display
Before driving, be sure to release the parking
brake.
Electric parking brake (if so
equipped)
N00593200119
1. Stop the vehicle completely.
The Electric parking brake is the system that
2. Pull up the Electric parking brake switch
applies the parking brake by the electric
while depressing the brake pedal.
motor.
Features and controls
5-51
Parking brake
When the Electric parking brake is applied,
NOTE
NOTE
the brake warning light in the instrument
z
If the Electric parking brake must be applied
z
If the Electric parking brake switch is repeat-
cluster and the indicator light (A) on the Elec-
in an emergency situation, pull and hold the
edly operated in a short time, the following
tric parking brake switch will come on.
Electric parking brake switch to apply the
warning display will appear in the multi-
Electric parking brake. At that time, the fol-
information display and the Electric parking
When parking on a hill, set the parking brake,
lowing warning display will appear in the
brake will temporarily stop working. In such
and turn the front wheels toward the curb on a
multi-information display and a buzzer will
case, wait for approximately 1 minute until
downhill, or away from the curb on an uphill.
sound, however you should continue to pull
the warning display disappears, and operate
5
and hold the Electric parking brake switch.
the Electric parking brake switch again.
CAUTION
z
Do not place any items near the Electric
parking brake switch.
Items may come into contact with the switch,
which may unexpectedly trigger operation of
the Electric parking brake.
z
When parking on steep grades, pull up the
z
The brake warning light and the indicator
z
While the vehicle is in motion, do not apply
Electric parking brake switch twice
(once
light on the Electric parking brake switch
the Electric parking brake. Doing so may
more after the operation is completed once).
may blink. This does not indicate a malfunc-
cause overheating and/or premature wear of
The maximum effect of the parking brake
tion, the lights go off when/if the Electric
brake parts, reducing brake performance.
will be obtained.
parking brake is released.
z
If the parking brake does not hold the vehicle
z
Depending on the situation, the Electric
stationary after the foot brake is released,
parking brake may be applied automatically.
contact an authorized Mitsubishi Motors
Refer to “Brake auto hold” on page 5-77.
NOTE
dealer or a repair facility of your choice.
z
In the following conditions, the brake warn-
z
When the operation mode is other than ON,
ing light will illuminate for approximately
if the parking brake is applied, the Electric
15 seconds and then go off.
parking brake indicator light comes on for a
• While the Electric parking brake is applied,
while.
the operation mode is put in OFF.
• While the operation mode is in OFF, the
Electric parking brake switch is pulled up.
5-52
Features and controls
Parking brake
When the Electric parking brake is released,
To release
CAUTION
the brake warning light and the indicator light
z
If the acceleration of the vehicle seems
on the Electric parking brake switch light
abnormally slow after the vehicle has been
Manual operation
turns off and no longer illuminates.
parked with the Electric parking brake
applied in cold weather, stop the vehicle in a
Before driving, be sure that the parking brake
safe place, then apply and release the Elec-
is released and that no warning lights are illu-
tric parking brake. If the vehicle acceleration
minated.
is still slow, contact the nearest authorized
5
Mitsubishi Motors dealer or a repair facility
of your choice.
CAUTION
z
After the Electric parking brake switch has
been operated to apply or release the Electric
parking brake, if the brake warning light and
NOTE
the indicator light on the Electric parking
z
When the operation mode is other than ON,
brake switch remain blinking or the Electric
the parking brake cannot be released.
parking brake warning light remain illumi-
z
If the Electric parking brake does not auto-
1.
Make sure that the operation mode is in
nated, the Electric parking brake system may
matically release, it may be released by man-
ON.
be malfunctioning and the parking brake
ual operation.
2.
Press down the Electric parking brake
may not be applied or released. Immediately
z
When the selector lever is other than “P”
switch while depressing the brake pedal.
park your vehicle in a safe place and contact
(PARK) position, if you try to release the
the nearest authorized Mitsubishi Motors
Electric parking brake without depressing
dealer or a repair facility of your choice.
the brake pedal, the warning display will
Automatic operation
z
If a vehicle is driven without releasing the
appear.
parking brake, the brake will overheat,
When the accelerator pedal is depressed
resulting in ineffective braking and possible
slowly while all of the following conditions
brake failure.
are met, the Electric parking brake is auto-
z
If the brake warning light does not go off
matically released.
after the parking brake has been released, the
brake system may be malfunctioning.
z The engine is running.
Contact the nearest authorized Mitsubishi
z The selector lever is in the “D” (DRIVE)
Motors dealer or a repair facility of your
or the “R” (REVERSE) position.
choice.
z The driver’s seat belt is fastened.
Features and controls
5-53
Steering wheel height and reach adjustment
Under normal conditions, the warning light
NOTE
NOTE
only comes on when the operation mode is
z If you start driving without releasing the
z
If the following warning is displayed in the
put in ON and goes off a few seconds later.
Electric parking brake, the warning display
information screen in the multi-information
will appear.
display, operate the Electric parking brake
CAUTION
switch several times.
z
When the Electric parking brake warning
After operating the switch, if the display dis-
light does not illuminate or remains illumi-
appears, there is no abnormality.
nated when the operation mode is put in ON,
5
or comes on while driving, the Electric park-
z If the driver’s foot contacts the accelerator
ing brake may not be applied or released.
pedal in the condition that the Electric park-
Immediately contact the nearest authorized
ing brake can release by an automatic opera-
Mitsubishi Motors dealer or a repair facility
tion, the Electric parking brake may be
of your choice. For details, refer to “Electric
released automatically.
parking brake warning light” on page 5-186.
When parking your vehicle while the Elec-
Steering wheel height and
tric parking brake warning light is illumi-
Warning light/display
nated, park the vehicle on level and stable
reach adjustment
ground, move the selector lever to the “P”
N00511501241
Warning light
(PARK) position and place chocks, blocks,
To adjust the steering wheel to the desired
stones behind and in front of the tires to pre-
vent the vehicle from moving.
position, move the lever upward or down-
ward while moving the steering wheel to the
desired position.
Warning display
If there is a malfunction in the system, the
warning light will come on. In addition, the
warning display appears on the information
screen in the multi-information display.
5-54
Features and controls
Inside rearview mirror
Type 1
1
Type 2
2
5
1- Wheel lock
Type 3
2- Release
WARNING
z After adjusting, make sure the lock lever
is secured in the locked (1) position.
z Do not attempt to adjust the steering
WARNING
wheel while driving. This can be danger-
z Do not attempt to adjust the inside rear-
ous.
view mirror while driving. This can be
dangerous.
Be sure to adjust the mirrors before driv-
ing.
Inside rearview mirror
N00511601503
Adjust the inside mirror to maximize the
Adjust the inside rearview mirror only after
view through the rear window.
making any seat adjustments so as to have a
clear view to the rear of the vehicle.
To adjust the mirror position
It is possible to move the mirror up/down and
left/right to adjust its position.
Features and controls
5-55
Inside rearview mirror
To reduce the glare
Type 2
Type 3
When the headlights of the vehicles behind
When the headlights of the vehicles behind
you are very bright, the reflection factor of
you are very bright, the reflection factor of
Type 1
the rearview mirror is automatically changed
the rearview mirror is automatically changed
to reduce the glare.
to reduce the glare.
The day/night knob (A) at the bottom of the
mirror can be used to adjust the mirror to
5
reduce the glare from the headlights of vehi-
cles behind you during night driving.
When the operation mode is put in ON, the
Normally, use the automatic mode. When the
reflection factor of the mirror is automatically
operation mode is put in ON, the green indi-
changed.
cator (1) illuminates and the reflection factor
1- Daytime position
of the mirror is automatically changed.
2- Night position
NOTE
z Do not hang items on, or spray glass cleaner
NOTE
on the sensor
(1), as reduced sensitivity
z Do not hang items on, or spray glass cleaner
could result.
on the sensors
(2), as reduced sensitivity
could result.
z If you want to stop automatic mode, press
the switch (3) and the indicator will go off.
To return to automatic mode, press the
switch again or put the operation mode in
ON after putting the operation mode in OFF.
5-56
Features and controls
Outside rearview mirrors
4- Left
Outside rearview mirrors
To adjust the mirror position
N00512201232
N00549101196
NOTE
The outside rearview mirrors can be adjusted
Adjust the outside rearview mirrors only after
z After completing the adjustment, return the
when the ignition switch is in the “ON” or
making any seat adjustments so as to have a
switch (A) to the center position.
“ACC” position or the operation mode is put
clear view to the rear of the vehicle.
in ON or ACC.
Push the switch (A) to the same side as the
WARNING
To retract the mirror
mirror you wish to adjust.
5
z
Do not attempt to adjust the outside rear-
N00549201298
view mirrors while driving. This can be
The outside mirror can be retracted towards
dangerous.
Type 1
the side window to prevent damage when
Be sure to adjust the mirrors before driv-
parking in tight locations.
ing.
z
Your passenger’s side mirror is convex.
Except for vehicles equipped with the
The objects you see in the mirror will look
mirror retractor switch
smaller and farther away than they
appear in a regular flat mirror.
Push the mirror towards the back of the vehi-
Do not use this mirror to estimate the dis-
Type 2
cle with your hand to retract it in. When
tance of vehicles following you when
extending the mirror, pull it out towards the
changing lanes.
front of the vehicle until it clicks to lock in
place.
L- Left outside mirror adjustment
R- Right outside mirror adjustment
Press the switch (B) to adjust the mirror posi-
tion.
1- Up
2- Down
3- Right
Features and controls
5-57
Outside rearview mirrors
For vehicles equipped with the mirror
Retracting and extending the mir-
CAUTION
retractor switch
z
It is possible to retract and extend the mirrors
rors without using the mirror
by hand. After retracting a mirror using the
retractor switch (automatic exten-
mirror retractor switch, however, you should
Retracting and extending the mir-
sion function)
extend it by using the switch again, not by
rors using the mirror retractor
hand. If you extended the mirror by hand
switch
after retracting it using the switch, it would
The mirrors automatically retract or extend
not properly lock in position. As a result, the
when the doors are locked or unlocked using
5
With the operation mode in ON or ACC, push
mirror could move because of the wind or
the key buttons or the F.A.S.T.-key operation.
the mirror retractor switch to retract the mir-
vibration while you are driving, and this may
Refer to “To operate using the F.A.S.T.-key”
rors. Push it again to extend the mirrors to
impair the driver’s rearward visibility.
on page 5-16.
their original positions.
After putting the operation mode in OFF, it is
NOTE
NOTE
possible to retract and extend the mirrors
z
Functions can be modified as stated below.
using the mirror retractor switch for approxi-
z
Be careful not to get your hands trapped
Please consult an authorized Mitsubishi
mately 30 seconds.
while a mirror is moving.
Motors dealer.
z
If you move a mirror by hand or it moves
On vehicles equipped with the Smartphone-
after hitting a person or object, you may not
link Display Audio
(SDA) or the Smart-
be able to return it to its original position
phone-link Display Audio (SDA) navigation
using the mirror retractor switch. If this hap-
system, screen operations can be used to
pens, push the mirror retractor switch to
make the adjustment. Refer to the separate
place the mirror in its retracted position and
owner’s manual for details.
then push the switch again to return the mir-
• Automatically extend when the operation
ror to its original position.
mode is put in ON with the driver’s door
z
When freezing has occurred and mirrors fail
closed, and automatically retract when the
to operate as intended, please refrain from
operation mode is put in OFF or ACC with
repeated pushing of the retractor switch as
the driver’s door opened.
this action can result in burn-out of the mir-
• Automatically extend when the vehicle
ror motor circuits.
speed reaches approximately
19 mph
(30 km/h).
• Deactivate the automatic extension func-
tion.
5-58
Features and controls
Outside rearview mirrors
Integrated Blind Spot Mirrors
(if so equipped)
N00595900022
WARNING
z Even if no vehicles are shown to the side of
your vehicle in the Integrated Blind Spot
5
Mirrors (A), be sure to confirm that traf-
fic is clear before changing lanes.
z Because the Integrated Blind Spot Mir-
rors (A) are wide-angle mirrors, objects
appear smaller than their actual size.
Also, be careful because vehicles and other
objects shown in the mirrors are closer to
your vehicle than they appear.
The Integrated Blind Spot Mirror (A) is a
mirror for showing vehicles and other objects
in the driver's blind spot
(C) that are not
shown in the main mirror (B).
When checking the area to the rear of your
D- When a vehicle is traveling far behind
vehicle, check the main mirror (B), and then
your vehicle, the main mirror (B) shows
check the Integrated Blind Spot Mirror (A).
an image of the vehicle and the Inte-
grated Blind Spot Mirror (A) shows a
small image of the vehicle.
E- When the vehicle moves closer to your
vehicle, the main mirror (B) shows a
larger image of the vehicle and the Inte-
grated Blind Spot Mirror (A) also shows
a larger image of the vehicle.
Features and controls
5-59
Ignition switch
F- When the vehicle moves even closer to
[Except for vehicles equipped with the
your vehicle and is located in the driver's
F.A.S.T.-key]
blind spot (C), the main mirror (B) does
not show an image of the vehicle and
only the Integrated Blind Spot Mirror
(A) shows an image of the vehicle.
5
Heated outside rearview mirror
(if so equipped)
N00549301361
When the rear window defogger switch is
NOTE
pressed with the engine running, the outside
z
The heated outside rearview mirror can be
rearview mirrors are defogged or defrosted.
turned on automatically.
Current will flow through the heater element
For further information, please contact your
inside the mirrors, thus clearing away frost or
authorized Mitsubishi Motors dealer.
OFF
condensation.
On vehicles equipped with the SDA or the
The indicator light (A) will illuminate while
SDA navigation system, screen operations
The engine is off. The key can be inserted and
the defogger is on.
can be used to make the adjustment.
removed only when the switch is in this posi-
The heater will be turned off automatically in
Refer to the separate owner’s manual for
tion.
details.
approximately 15 to 20 minutes depending on
the outside temperature.
ACC
Ignition switch
N00512401755
Allows operation of electrical accessories
with the engine off.
[For vehicles equipped with the F.A.S.T.-
key]
For information on operations for vehicles
ON
equipped with the F.A.S.T.-key, refer to
“Free-hand Advanced Security Transmitter
All accessories can be used.
(F.A.S.T.-key): Engine switch” on page 5-18.
5-60
Features and controls
Starting the engine
START
NOTE
NOTE
• The time until the power cuts out can be
z
The key cannot be removed unless the selec-
changed to approximately 60 minutes.
tor lever is set to the “P” (PARK) position,
Engages the starter. Release the key when the
• The ACC power auto-cutout function can
which allows the ignition switch to turn to
engine starts.It will automatically return to
be deactivated.
the “OFF” position.
the “ON” position.
For details, we recommend you to consult an
NOTE
authorized Mitsubishi Motors dealer.
CAUTION
5
z Your vehicle is equipped with an electronic
On vehicles equipped with the Smartphone-
z
If the engine is stopped while driving, the
immobilizer. To start the engine, the ID code
link Display Audio (SDA), screen operations
power brake booster will stop functioning
which the transponder inside the key sends
can be used to make the adjustment.
and greater effort for braking will be
must match the one registered to the immobi-
Refer to the separate owner’s manual for
required. Also, the power steering system
lizer computer. (Refer to “Electronic immo-
details.
will not function and it will require greater
bilizer” on page 5-4.)
effort to manually steer the vehicle.
z
Do not leave the key in the “ON” position for
To remove the key
a long time when the engine is not running.
N00550901253
ACC power auto-cutout func-
This will cause the battery to run down.
When removing the key, first set the selector
z
Do not turn the key to the “START” position
tion
lever to the “P” (PARK) position, and then
when the engine is running. It will damage
N00539601156
turn the key to the
“OFF” position and
the starter motor.
After approximately 30 minutes has elapsed
remove it.
with the ignition switch in the “ACC” posi-
tion, the function automatically cuts out the
Starting the engine
power for the audio system and other electric
N00512601874
devices that can be operated with that posi-
[For vehicles equipped with the F.A.S.T.-
tion.
key]
When the ignition switch is turned from the
For information on operation for vehicles
“ACC” position, the power is supplied again
equipped with the F.A.S.T.-key, refer to
to those devices.
“Free-hand Advanced Security Transmitter
(F.A.S.T.-key): Starting” on page 5-13.
NOTE
z It is possible to modify functions as follows:
Features and controls
5-61
Starting the engine
[Except for vehicles equipped with the
2. Insert the ignition key.
WARNING
F.A.S.T.-key]
3. Press and hold the brake pedal down
z
Never run the engine in a closed or poorly
firmly with your right foot.
ventilated area any longer than is needed
4. Make sure the selector lever is in the “P”
Tips for starting
to move your vehicle out of the area. Car-
(PARK) position.
bon monoxide gas, which is odorless and
5. Turn the ignition switch to the “ON” posi-
z
Do not operate the starter motor continu-
extremely poisonous, could build up and
ously for longer than 15 seconds as this
cause serious injury or death.
tion and make certain that all warning
lights are functioning properly before
could run the battery down or damage the
5
starting the engine.
starter motor. If the engine does not start,
CAUTION
6. Turn the ignition switch to the “START”
turn the ignition switch back to the
z
Do not push-start the vehicle.
position without pressing the accelerator
“OFF”, wait a few seconds, and then try
z
Do not run the engine at high revolutions or
pedal. Release the ignition switch when
again. Trying repeatedly with the engine
drive at high speeds until the engine has had
the engine starts.
or starter motor still turning will damage
a chance to warm up.
the starter mechanism.
z
Release the ignition switch as soon as the
NOTE
z
If the engine will not start because the bat-
engine starts. Otherwise, the starter motor
tery is weak or discharged, refer to
z Minor noises may be heard on engine start-
will be damaged
up. These will disappear as the engine warms
“Jump-starting the engine” (on page 8-2)
up.
for instructions.
z
A longer warm up period will only con-
Starting the engine
sume extra fuel. The engine is warmed up
When the engine is hard to start
enough for driving when the bar graph of
engine coolant temperature display starts
This model is equipped with an electronically
to move or the low coolant temperature
controlled fuel injection system. This is a sys-
After several attempts, you may experience
indicator goes out. Refer to “Engine cool-
tem that automatically controls fuel injection.
that the engine still does not start.
ant temperature display” on page 5-150.
There is usually no need to depress the accel-
erator pedal when starting the engine.
1. Make sure that all electric devices, such
The starter should not be run for more than
as lights, air conditioning blower and rear
15 seconds at a time.
window defogger, are turned off.
To prevent battery drain, wait a few seconds
between attempts to restart the engine.
1. Make sure all occupants are properly
seated with seat belts fastened.
5-62
Features and controls
Turbocharger operation
2. While depressing the brake pedal, press
lever in the
“D”
(DRIVE) or
“R”
Continuously variable
the accelerator pedal halfway and hold it
(REVERSE) position.
there, then crank the engine. Release the
This occurs because the transaxle has not
transmission (CVT)
accelerator pedal, immediately after the
warmed up sufficiently; it does not indicate a
N00560201103
engine starts.
problem. If this occurs, place the selector
The CVT will automatically and continuously
3. If the engine still will not start, the engine
lever in the “P” (PARK) position and let the
change its gear ratio depending on road and
could be flooded with too much gasoline.
engine idle for at least 10 minutes.
driving conditions. This helps achieve
While depressing the brake pedal, push
The transaxle will warm up, and you will be
smooth driving and excellent fuel efficiency.
5
the accelerator pedal all the way down
able to start normally.
Also you can manually shift the transmission
and hold it there, then crank the engine for
Do not leave the vehicle during warm-up
up and down. Refer to “Sports mode” on page
5 to 6 seconds. Return the ignition switch
operation.
5-67.
to the “OFF” and release the accelerator
pedal. Wait a few seconds, and then crank
Turbocharger operation
DRIVING UPHILL
the engine again for 5 to 6 seconds while
N00537301090
depressing the brake pedal, but do not
push the accelerator pedal. Release the
The transmission prevents unnecessary
CAUTION
ignition switch if the engine starts. If the
upshifts even when the accelerator pedal is
z Do not run the engine at high speeds (for
engine fails to start, repeat these proce-
released and ensures smooth driving.
example, by revving it or by accelerating
dures. If the engine still will not start, con-
rapidly) immediately after starting it.
tact your local Mitsubishi Motors dealer
z Do not stop the engine immediately after
DRIVING DOWNHILL
or a repair facility of your choice for
high-speed or uphill driving. First allow the
assistance.
engine to idle to give the turbocharger a
According to the conditions, the transmission
chance to cool down.
will automatically shift to a lower gear ratio
z Replace the engine oil at the specified inter-
Startability of CVT vehicle with
vals. If the engine oil is not replaced, the tur-
to achieve stronger engine braking. This may
ambient temperature of -22 °F
bocharger could malfunction.
help reduce your need to use the service
(-30 °C) or lower
brake.
When the ambient temperature is
-22
°F
Selector lever operation
(-30 °C) or lower, it may not be possible to
N00560301120
start from a standstill even with the selector
As an additional safety precaution, models
equipped with a CVT have a shift-lock device
Features and controls
5-63















Content      ..     4      5      6      7     ..
