Mitsubishi L200 (2018 year). Instruction - part 15

Item

Details

Specification

Advanced Audio Coding
MPEG4/AAC-LC
MPEG2/AAC-LC

Sampling

frequency

[kHz]

MPE

8/11.025/12/16/22.05/
24/32/44.1/48

MPE

8/11.025/12/16/22.05/
24/32/44.1/48

Bit rate

[kbps]

MPE

16 to 320

MPE

16 to 320

VBR (variable

bit rate)

Support

Channel mode Stereo/Monaural

File extension m4a

Supported tag

information

AAC tags or ID3 tags
Title, Artist name, Album
name

Maximum num-

ber of characters

that can be indi-

cated on the dis-

play

64 characters

Important Points on Safety
for the Customer

E00737001120

This product features a number of pictorial
indications as well as points concerning han-
dling so that you can use the product correct-
ly and in a safe manner, as well as prevent in-
jury or damage to yourself, other users, or
property.

WARNING

The driver should not pay close attention
to the display while driving.
This may prevent the driver looking
where they are going, and cause an acci-
dent.

The driver should not perform complica-
ted operations while driving.
Performing  complicated  operations  while
driving  may  prevent  the  driver  looking
where  they  are  going,  and  cause  an  acci-
dent.
Therefore  stop  the  vehicle  in  a  safe  loca-
tion before performing such operations.

Do not use during malfunctions, such as
when no sound is audible.
This may lead to accident, fire, or electric
shock.

Ensure water or other foreign objects do
not enter the product.
This may lead to smoking, fire, electric
shock, or malfunction.

WARNING

Do not insert foreign objects into the disc
slot.
This may lead to fire, electric shock, or
malfunction.

In  the  event  of  abnormalities  occurring
when  foreign  objects  or  water  enter  the
product,  resulting  in  smoke  or  a  strange
smell, immediately stop using the product,
and  consult  a  MITSUBISHI  MOTORS
Authorized Service Point.
Continuing to use the product may result
in accident, fire, or electric shock.

Do not disassemble or modify the prod-
uct.
This may lead to malfunction, fire, or
electric shock.

During thunderstorms, do not touch the
antenna or the front panel.
This may lead to electrical shock from
lightning.

CAUTION

Do not block ventilation holes or heat sinks
on the product.
Blocking ventilation holes or heat sinks may
prevent heat from escaping from within the
product, leading to fire or malfunction.

Important Points on Safety for the Customer

7-24

OKTE18E1

For pleasant driving

CAUTION

Do not turn the volume up to the extent that
you cannot hear sounds from outside the ve-
hicle while driving.
Driving without being able to hear sounds
from outside the vehicle may result in an ac-
cident.

Do not insert your hand or fingers into the
disc slot.
This may result in injury.

Operation Keys

E00737101134

Turn the Power ON/ OFF

E00737201193

1. Press the SEL•PWR•VOL key.

Turn the power on, and resume playback
from the previous status.

2. Hold down the SEL•PWR•VOL key.

Turn the power OFF.

NOTE

Hold down the steering MODE button (Type
1)/SOURCE button (Type 2) to also turn the
audio function ON/OFF.

Adjust Volume

E00737301035

1. Turn the SEL•PWR•VOL key to adjust

the volume.

Turn the SEL•PWR•VOL key clockwise
to increase, and anticlockwise to de-
crease the volume.

NOTE

The maximum value for volume is 49, and
the minimum is 0.

The initial setting for volume is “17”.

Insert/Eject Discs

E00737401049

1. Insert the disc into the disc slot with the

label surface up.

Disc
*Label side

Disc slot

Push the disc in a certain amount, and
the product will pull the disc in, and
playback will start.

2. Press the

key.

This will eject the disc from the product,
so remove the disc.

Operation Keys

7-25

OKTE18E1

For pleasant driving

CAUTION

When replacing discs, first ensure that the
vehicle is stopped in an area in which stop-
ping is permitted.

Do not insert your hand, fingers, or foreign
objects into the disc slot. This may lead to
injury, smoking, or fire.

8 cm CDs are not supported.

Operation Keys

7-26

OKTE18E1

For pleasant driving

Explanation of Buttons

E00737501138

This explains names and functions of each part.

key

Use to eject a disc.

2- 1DISP key

Switch the content of the display.
For radio, use as preset key 1.

3- 2PAGE key

Display the content page forward.
For radio, use as preset key 2.

4- 3key

For radio, use as preset key 3.

5- MEDIA key

Each time this is pressed, the audio
source switches in the order “CD”,
“USB/iPod”, and “AUX”.

6- RADIO key

Switch the radio and the band.

key/

key

For audio, press to select audio track/file
and hold down to rewind/fast forward;
for radio, select radio station.

8- SEL•PWR•VOL key

Adjust the volume, and turn the power
ON/OFF. Additionally, adjust audio
quality and select items.

key

Return during audio track search

10- Disc slot
11- AUTO-P key

Auto preset the radio.

12- 4RPT key

For audio, press to turn repeat playback
mode on/off; for radio, use as preset key
4.

Operation Keys

7-27

OKTE18E1

For pleasant driving

13- 5RDM key

For audio, press to turn random playback
mode on/off; for radio, use as preset key
5.

14- 6key

For radio, use as preset key 6.

15-

/MENU key

Switch to Menu mode.

16- Auxiliary Audio connector (mini-jack)

Connect a commercially-available audio
device.

Steering wheel audio remote

control switches*

E00737601461

Type 1

Type 2

1- Volume up/down switch

Adjust audio functions volume.

2- button, button

Select CD and other audio source tracks
and radio stations.
Hold down to fast forward and rewind.

3- MODE button (Type 1)/SOURCE but-

ton (Type 2)
Hold down to turn the audio function
ON/OFF. Additionally, each time this is
pressed, this switches the audio source.
The order of switching is as shown be-
low.

FM1,FM2,AM

DISC

iPod or USB

AUX

Listen to Radio

E00737701127

This explains how to listen to AM and FM
radio broadcasts.

To Listen to the Radio

Press the RADIO key to switch the band.
Switch between AM and FM bands.
The selected band is indicated on the display.

NOTE

Each time the RADIO key is pressed, this
switches in the order “FM1”, “FM2”, and
“AM”.

Manual/Seek Station Selection

Press the

key or the

key to the fre-

quency to listen to.

key

Increases the frequency
being received.

key

Reduces the frequency
being received.

Listen to Radio

7-28

OKTE18E1

For pleasant driving

key

(hold down)

Release the button to start
seek station selection, and
when a station is re-
ceived, scanning stops.

key

(hold down)

Preset Memory

1. Tune in to the frequency to register.
2. Hold down any of the keys from the

1DISP key to the 6 key.
A “Beep” sounds, and the preset key is
registered.

NOTE

The preset memory can register a maximum
of 6 stations for each band.

If a preset key that already has a station reg-
istered is selected, then this is overwritten
with the new preset.

Pressing the preset key will select the previ-
ously registered frequency.

Auto Preset

The top 6 stations with a strong signal can be
automatically registered in order with preset
keys in the AUTO-P mode.
Hold down the AUTO-P key.
Switch to the AUTO-P mode, and start auto-
matic station selection.

After completion of operations, the product
will receive the station registered in the pre-
set key [1].

CAUTION

Please be aware that the formerly-registered
frequency in the memory will be overwrit-
ten.

NOTE

Pressing the preset key will select the previ-
ously registered frequency.

Each time the AUTO-P key is pressed, this
switches between normal reception and AU-
TO-P mode.

In the AUTO-P mode, manual/seek station
selection, as well as scan operation is also
possible.

Listen to CDs

E00737801131

This explains how to listen to audio CDs
(CD-DA/CD-TEXT).

Play CDs

Insert the disc.

Insert a disc to automatically start playback.
→ “Insert/Eject Discs” (P.7-25)

If a disc is already within the product, press
the MEDIA key to switch to CD as the
source.

Select the Track

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the

key or

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback and random playback are
possible.

Repeat Playback (RPT)

Press the 4RPT key.

Repeat playback of the track currently being
played.

NOTE

Pressing again will cancel.

Ejecting will cancel this.

Listen to CDs

7-29

OKTE18E1

For pleasant driving

Random Playback (RDM)

Press the 5RDM key.

Play the tracks on the disc in a random order.

NOTE

Pressing again will cancel.

Ejecting will cancel this.

Search Tracks

This enables search of the track while playing
music.

1. Press the SEL•PWR•VOL key.
2. Turn the SEL•PWR•VOL key to select

the track.

3. Press the SEL•PWR•VOL key.

This plays the selected track.

Listen to MP3s/WMAs/
AACs

E00737901132

This explains how to listen to audio files on a
disc.

To Listen to MP3s/WMAs/

AACs

Insert the disc.

Insert a disc to automatically start playback.
→ “Insert/Eject Discs” (P.7-25)
If a disc is already within the product, press
the MEDIA key to switch to CD as the
source.

NOTE

Depending on the file structure, it may take
some time to read the contents of the disc.

Select the Track (File)

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the

key or

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback and random playback are
possible.

Repeat Playback (RPT)

Press the 4RPT key.
Repeat playback of the track currently being
played.

NOTE

Pressing the 4RPT key two times will can-
cel.

Ejecting will cancel this.

Folder Repeat Playback

Press the 4RPT key during repeat playback of
a track.

Repeat playback of the tracks within the fold-
er currently being played.

NOTE

Pressing again will cancel.

Ejecting will cancel this.

Even if the file is selected, folder repeat
playback will not be cancelled.

Random Playback (RDM)

Press the 5RDM key.
Play the tracks in the folder in a random or-
der.

NOTE

Pressing the 5RDM key two times will can-
cel.

Ejecting will cancel this.

Listen to MP3s/WMAs/AACs

7-30

OKTE18E1

For pleasant driving

Folder Random Playback

Press the 5RDM key during playback of the
tracks in the folder in a random order.

Play all tracks in folders on the disc in a ran-
dom order.

NOTE

Pressing again will cancel.

Search Tracks

Search folders and files, and select a track.

1. Press the SEL•PWR•VOL key.
2. Turn the SEL•PWR•VOL key to select

the folder.

3. Press the SEL•PWR•VOL key.

Files within the selected folder are dis-
played.

4. Turn the SEL•PWR•VOL key to select

the file.

5. Press the SEL•PWR•VOL key.

This plays the selected file (track).

NOTE

While the folder is selected, press the
key to cancel track search mode.

NOTE

If there is no operation for 10 seconds after
selecting the folder, then track search mode
will be cancelled.

While the file is selected, press the

key

to return to the previous operation.

While the file is selected, hold down

the

key to cancel track search mode.

Disc operations such as selecting a track will
cancel track search mode.

Listen to an iPod*

E00738001420

By connecting commercially-available iPod/
iPhone devices to this product, you can play
tracks on these through the product.

CAUTION

Do not leave the iPod/iPhone unattended in
the vehicle.

Never hold these devices in your hand to op-
erate while driving, as this is dangerous.

No indemnification for data loss resulting
when the iPod/iPhone is connected to the
product will be possible.

Depending on how the devices are handled,
audio files being damaged or lost, therefore
it is recommended that data be backed up.

NOTE

Depending on the generation, model, or soft-
ware version of the iPod/iPhone, playback
on this product may not be possible. (→P.
7-18) Additionally, playback as explained in
this document may not be possible.

Usage of iPod/iPhone hardware with the lat-
est software version is recommended.

Regarding how to connect the iPod/iPhone,
refer to “How to connect an iPod” on page
7-97.

When connecting the iPod/iPhone, use a
commercially-available iPod connection ca-
ble.

Set up the device in order that no unsafe ac-
tions, such as plugging in the connection ca-
ble are taken while driving.

When inserting and removing the iPod/
iPhone, for safety’s sake first stop the vehi-
cle.

Depending on the status of the iPod/iPhone,
it may take some time until the device is rec-
ognized, or playback starts.

Depending on the iPod/iPhone, the button
functions on the product may not operate
while the iPod/iPhone is connected.

iPod/iPhone specifications and settings may
mean that connection is not possible, or re-
sult in differences in operation or display.

Depending on audio data in the iPod/iPhone,
track information may not be displayed cor-
rectly.

Depending on the status of the vehicle and
device, the iPod/iPhone may not be played
after starting the engine.

Listen to an iPod*

7-31

OKTE18E1

For pleasant driving

NOTE

Data containing copyright information may
not be played back.

It is recommended that the iPod/iPhone
equaliser settings be set to flat.

Operate the iPod/iPhone while connected to
this product.

If an iPod/iPhone does not operate correctly,
then remove the iPod/iPhone from the prod-
uct, reset, then reconnect.

Play iPod

Press the MEDIA key to set the USB (iPod)
as the source.

The selected source is indicated on the dis-
play.

Select the Track (File)

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the

key or

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback and shuffle playback are
possible.

Repeat Playback (RPT)

Press the 4RPT key.

Repeat playback of the track currently being
played.

NOTE

Pressing again will cancel.

Shuffle Playback (RDM)

Press the 5RDM key.

Play tracks in the category currently being
played in a random order.

NOTE

Pressing the 5RDM key two times will can-
cel.

Album Shuffle Playback

Press the 5RDM key during playback of the
album in a random order.

Play the album in a random order (tracks in
any order on the album).

NOTE

Pressing again will cancel.

Search Tracks

Search categories or track names, and select a
track.

1. Press the SEL•PWR•VOL key.
2. Turn the SEL•PWR•VOL key to select

the category.

3. Press the SEL•PWR•VOL key. Catego-

ries or tracks within the selected catego-
ry are displayed.

4. Turn the SEL•PWR•VOL key to select

the category or track.

5. Press the SEL•PWR•VOL key.

Repeat steps 1 to 4, and search for
tracks.
Select the track, and press the
SEL•PWR•VOL key to play.

NOTE

While the category (1

level) is selected,

press the

key to cancel track search

mode.

If there is no operation for 10 seconds after
selecting the category, then track search
mode will be cancelled.

While the track is selected, press the

key

to return to the previous operation.

Listen to an iPod*

7-32

OKTE18E1

For pleasant driving

NOTE

While the track is selected, hold down the

key to cancel track search mode.

iPod operations such as selecting a track will
cancel track search mode.

Listen to Audio Files on a
USB Device*

E00736501434

By connecting commercially-available USB
devices such as USB memory to this product,
you can play audio files on these through the
product.

CAUTION

Do not leave the USB device unattended in
the vehicle.

Never hold these devices in your hand to op-
erate while driving, as this is dangerous.

Do not use hard discs, card readers, or mem-
ory readers, as damage may occur to these or
to the data contained therein. If these are er-
roneously connected, then turn the ignition
switch to the “LOCK” position or put the
operation mode in OFF, then remove.

Because of the risk of data loss, it is recom-
mended that files be backed up.

No guarantee is made as regards damage to
the USB device, nor regarding loss or dam-
age to data contained therein.

CAUTION

Depending on how the devices are handled,
audio files being damaged or lost, therefore
it is recommended that data be backed up.

NOTE

Digital audio players that support the mass
storage class specifications can be connec-
ted.

Regarding how to connect USB devices, re-
fer to “How to connect a USB memory de-
vice” on page 7-96.

When connecting a USB device, use a con-
nection cable. Failure to use a connection ca-
ble when connecting may place undue load
on, or damage the USB connector.

Set up the device in order that no unsafe ac-
tions, such as plugging in the connection ca-
ble are taken while driving.

When inserting and removing the USB de-
vice, for safety’s sake first stop the vehicle.

Do not insert other than audio devices into
the USB port. Damage to the device or
equipment may result.

Depending on the status of the USB device,
it may take some time until the device is rec-
ognized, or playback starts.

Depending on the USB device, the button
functions on the product may not operate
while the USB device is connected.

USB device specifications and settings may
mean that connection is not possible, or re-
sult in differences in operation or display.

NOTE

Depending on audio data in the USB device,
track information may not be displayed cor-
rectly.

Depending on the status of the vehicle and
device, the iPod/iPhone may not be played
after starting the engine.

Data containing copyright information may
not be played back.

This product can play MP3, WMA, and
AAC format audio files.

Depending on the type of USB device, usage
may not be possible, or functions that can be
used may be restricted.

The recommended file system for USB
memory is FAT32.

The maximum supported capacity for USB
memory is 32GB.

Operate the USB device containing recorded
audio files while connected to this product.

Playback of Audio Files on a

USB Device

Press the MEDIA key to set

USB as the source. The selected source is in-
dicated on the display.

Select the Track (File)

Press the

key or

key to select the

track.

Listen to Audio Files on a USB Device*

7-33

OKTE18E1

For pleasant driving

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the

key or

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback and random playback are
possible.

Repeat Playback (RPT)

Press the 4RPT key.

Repeat playback of the track currently being
played.

NOTE

Pressing the 4RPT key two times will can-
cel.

Folder Repeat Playback

Press the 4RPT key during repeat playback of
a track.

Repeat playback of the tracks within the fold-
er currently being played.

NOTE

Pressing again will cancel.

Even if the file is selected, folder repeat
playback will not be cancelled.

Folder Random Playback

(RDM)

Press the 5RDM key.

Play tracks in the folder currently being
played in a random order.

NOTE

Pressing the 5RDM key two times will can-
cel.

All Folder Random Playback

Press the 5RDM key during playback of the
tracks in the folder in a random order.

Play the tracks in all folders in a random or-
der.

NOTE

Pressing again will cancel.

Even if the file is selected, all folder random
playback will not be cancelled.

Search Tracks

Search folders and files, and select a track.

1. Press the SEL•PWR•VOL key.
2. Turn the SEL•PWR•VOL key to select

the folder.

3. Press the SEL•PWR•VOL key.

Files within the selected folder are dis-
played.

4. Turn the SEL•PWR•VOL key to select

the file.

5. Press the SEL•PWR•VOL key.

This plays the selected file (track).

NOTE

While the folder is selected, press the
key to cancel track search mode.

If there is no operation for 10 seconds after
selecting the folder, then track search mode
will be cancelled.

While the file is selected, press the

key

to return to the previous operation.

While the file is selected, hold down the
key to cancel track search mode.

Operations such as selecting a track will
cancel track search mode.

Using AUX*

E00736901177

By connecting external input cables and
AUX devices to this product, you can play
tracks on these devices through the product.

Using AUX*

7-34

OKTE18E1

For pleasant driving

Press the MEDIA key to switch to the AUX
mode.

A- Auxiliary Audio connector (mini-jack)

CAUTION

Connect an audio device with external sound
input mode cancelled, or with the sound
turned down.

Even if not inserted, the product will switch
to AUX, therefore take care with volume
levels when not inserted.

NOTE

Depending on the audio device to be con-
nected, noise may be emitted.

NOTE

For power, use the battery power source in-
cluded in the audio device to be connected.
Using the connected audio device while
charging through the cigarette lighter socket
in the vehicle may lead to noise being emit-
ted through the speakers.

If no audio devices are connected, then do
not select the external sound input mode. If
external sound input mode is selected while
no audio devices are connected, then sound
may be emitted through the speakers.

Display Indicator

E00738101085

This explains content of the display indicator.

Change the Display Mode

E00738501106

You can change the content of the display in-
dicator.

Press the 1DISP key to switch the display
content.

Each time the 1DISP key is pressed, the dis-
play content changes.

CAUTION

The operation of changing display contents
may impede safe driving, therefore check
safety before operation.

NOTE

Up to 10 characters may be displayed at one
time. To display 11 or more characters, press
the 2PAGE key, and subsequent characters
will be displayed.

During CD-DA playback

This  switches  in  the  order  “Track  no/Play
time”,  “Folder  no/File  no”,  “Folder  text”,
“File  text”,  “Artist  text”,  “Album  text”  and
“Song text”.

NOTE

If there is no artist text information to dis-
play, then “ARTIST” is displayed.

If there is no album text information to dis-
play, then “ALBUM” is displayed.

If there is no song text information to dis-
play, then “SONG” is displayed.

Display Indicator

7-35

OKTE18E1

For pleasant driving

During MP3/WMA/AAC Play-

back

This  switches  in  the  order  “Track  no/Play
time”,  “Folder  no/File  no”,  “Folder  text”,
“File  text”,  “Artist  text”,  “Album  text”  and
“Song text”.

NOTE

If there is no artist text information to dis-
play, then “ARTIST” is displayed.

If there is no album text information to dis-
play, then “ALBUM” is displayed.

If there is no song text information to dis-
play, then “SONG” is displayed.

During iPod Playback

E00738901054

During other than Podcast playback, this
switches in the order “Track No. + playtime”,
“Artist text”, “Album text” and “Song text”.
During Podcast playback, this switches in the
order “Track No. + playtime”, “Podcast
name”, “Episode name” and “Release date”.

NOTE

If there is no artist text information to dis-
play, then “ARTIST” is displayed.

If there is no album text information to dis-
play, then “ALBUM” is displayed.

NOTE

If there is no song text information to dis-
play, then “SONG” is displayed.

Audio Quality and Volume
Balance Adjustment

E00738201262

Change audio quality settings.

Adjust Audio Quality and Vol-

ume Balance

1. Press the /MENU key.
2. Turn the SEL•PWR•VOL key to select

adjustment  items  and  press  the
SEL•PWR•VOL key.
Turning  the  SEL•PWR•VOL  key  anti-
clockwise  or  clockwise,  the  adjustment
items switch as shown below.
BASS↔TREBLE↔FADER↔BAL-
ANCE

3. Turn the SEL•PWR•VOL key to adjust

the adjustment items selected.

Adjust-

ment

items

Turn counter-

clockwise

Turn clockwise

BASS -5~0

(Decrease low
frequency vol-
ume)

0~+5
(Increase

low

frequency vol-
ume)

TRE-

BLE

-5~0
(Decrease high
frequency vol-
ume)

0~+5
(Increase high
frequency vol-
ume)

FADER R11~0

(Emphasise
REAR)

0~F11
(Emphasise
FRONT)

BAL-

ANCE

L11~0
(Emphasise
LEFT)

0~R11
(Emphasise
RIGHT)

Time Setting

E00770700035

This explains how to set time.

1. Hold down the /MENU key.
2. Turn the SEL•PWR•VOL key to select

“CLOCK MODE” or “CLOCK AD-
JUST MODE”.

3. Press the SEL•PWR•VOL key to com-

plete.
The selected item is indicated on the dis-
play.

Audio Quality and Volume Balance Adjustment

7-36

OKTE18E1

For pleasant driving

CLOCK MODE

This enables selection of the 12-hour clock or
the 24-hour clock.

1. Turn the SEL•PWR•VOL key to select

the 12-hour clock or the 24-hour clock.

2. Press the SEL•PWR•VOL key to com-

plete and the clock display is changed.

CLOCK ADJUST MODE

Set the time manually.

1. Turn the SEL•PWR•VOL key to adjust

the hour.

2. Turn the SEL•PWR•VOL key to adjust

the hour.

3. Turn the SEL•PWR•VOL key to adjust

the minutes.

4. Press the /MENU key.

This completes the adjustment.

Time Setting

7-37

OKTE18E1

For pleasant driving

Troubleshooting

E00738401222

Please check these items if a message appears on the display, or if you think something is not working properly.

If This Message Appears...

A message is displayed on this product according to the situation.

Mode

Message

Cause

Response

DISC_ERROR

The disc is damaged and/or dirty.

Clean the read surface of the disc.

EJECT_E

The disc cannot be ejected.

Wait a while before ejecting again. If the problem
persists, consult a MITSUBISHI MOTORS Au-
thorized Service Point.

UNSUPPORT

Unsupported audio files have been played.

Confirm audio files that can be played. → “Audio
files (MP3/WMA/AAC)” (P.7-20)

PROTECT

Audio files protected by DRM (Digital Rights
Management) have been played.

Use audio files without DRM (Digital Rights Man-
agement).

COM_ERROR

Reading the contents of the CD has malfunctioned
for some reason.

Turn the power OFF and wait a while. If the prob-
lem persists, consult a MITSUBISHI MOTORS
Authorized Service Point.

USB

NO _ FILE

There are no audio files that can be played.

Confirm audio files that can be played. → “Audio
files (MP3/WMA/AAC)” (P.7-20)

DEVICE _ ERR

An unsupported USB device has been connected.

Confirm the USB device.

BUS_POWER

There is high electrical current.

Confirm the USB device.

UNSUPPORT

Unsupported audio files have been played.

Select audio files that can be played. → “Audio
files (MP3/WMA/AAC)” (P.7-20)

PROTECT

Audio files protected by DRM (Digital Rights
Management) have been played.

Select audio files that can be played. → “Audio
files (MP3/WMA/AAC)” (P.7-20)

Troubleshooting

7-38

OKTE18E1

For pleasant driving

Mode

Message

Cause

Response

COM_ERROR

Reading the contents of the USB has malfunc-
tioned for some reason.

Turn the power OFF and wait a while. If the prob-
lem persists, consult a MITSUBISHI MOTORS
Authorized Service Point.

iPod

NO _ SONG

There are no audio files that can be played.

Confirm audio files that can be played. → “Audio
files (MP3/WMA/AAC)” (P.7-20)

DEVICE _ ERR

Audio data in the iPod/iPhone cannot be read.

Confirm the iPod/iPhone that can be used. →
“Trademarks” (P.7-18)

BUS_POWER

There is high electrical current.

Confirm the USB device.

AUT-ERROR

iPod/iPhone is not recognized correctly.

Confirm the iPod/iPhone.

COM_ERROR

Reading the audio data in the iPod/iPhone has mal-
functioned for some reason.

Turn the power OFF and wait a while. If the prob-
lem persists, consult a MITSUBISHI MOTORS
Authorized Service Point.

VER_ERROR

This iPod/iPhone software version is not suppor-
ted.

Please change to a supported software version.

LW/MW/FM radio/CD
player*

E00708503651

The audio system can only be used when the
ignition switch or the operation mode is in
ON or ACC.

NOTE

For  vehicles  equipped  with  the  Keyless  op-
eration system, if the operation mode is left
in ACC, the accessory power will automati-
cally  turn  off  after  a  certain  period  of  time
and you will no longer be able to use the au-
dio  system.  The  accessory  power  comes  on
again if the engine switch is operated with it
in the “ACC” position. Refer to “ACC pow-
er auto-cutout function” on page 6-15.

NOTE

If a cellular phone is used inside the vehicle,
it may create noise from the audio equip-
ment. This does not mean that anything is
wrong with your audio equipment. In such a
case, use the cellular phone at a place as far
away as possible from the audio equipment.

LW/MW/FM radio/CD player*

7-39

OKTE18E1

For pleasant driving

Content .. 13 14 15 16 ..
