STEP 4. Check of wheel speed detection encoder ZC601558 0000 Magnetic Rear hub Rear wheel bearing Ball bearing Rear hub Magnetic <FWD> <AWD> Check the encoder for adhesion of foreign materials or Q:Is the check result normal? YES: Go to Step 5. NO (Presence of foreign materials): Remove the foreign materials and clean the encoder so as not to disturb the NO (Deformation): Replace the rear wheel hub assembly. STEP 5. Check whether the diagnostic trouble code is reset. (1) Erase the diagnostic trouble code. (2) Drive the vehicle at 12mph (20 km/h) or more. NOTE: The ABS warning light does not turn OFF in some cases unless the vehicle runs at 12mph (20 km/h) or Q:Is DTC C1044 set? YES: Replace the ASC-ECU. NO: Intermittent malfunction. (Refer to GROUP 00 - How to Cope with Intermittent Malfunction P.00-15.) ACTIVE SKID CONTROL SYSTEM (ASC) 35C-79 DIAGNOSIS |
