INSPECTION PROCEDURE 23: Ignition Switch-ST System and Transmission Range
Switch System

M11310100307USA0000010001

M

1

1

1

2

3
4

5 6

1 2 3 4

7

8

9

10

71 72 73 74 75 76 77 78 79 80 81 82

83 84 85 86 87 88 89 90 91 92 93 94

95 96 97 98 99

100 101 102 103 104

112 113 114

109

108

107

110 111

115 116

106

105

118

117

7

3

8

1

4

9

13 14

16

15

10 11 12

17 18 19

2

5 6

1

6

4

5

9

8

10 11

13

15

14

12

16

7

2 3

1 2 3
4 5 6

ZK602872

1

10 111213 14 1516 17 1819 20

2 3 4

5 6 7 8 9

D

Ds

N

R

P

OFF

ON

1

OFF

ON

10

106

B-11

105

15

7

C-304

ENGINE
CONTROL
MODULE

A-13

ETACS-ECU

7

R

IG2

ST

LOCK

ACC

IG1

5

B-114

(MU801211)

B-110

MU802355

STARTER

STARTER
RELAY

TRANSMISSION
RANGE
SWITCH

B-113

A-27X

6

3

1

4

2

BLA

CK-RED

RED-WHITE

RED-WHITE

WHITE

GREEN

GREEN

ORANGE

LIGHT

GREEN

BLA

CK

BLA

CK

BLA

CK

BLACK-RED

BLACK-RED

A-13

12

11

C-315

MU801890

C-210

IGNITION SWITCH

STARTING SYSTEM CIRCUIT

AA00

BATTERY

FUSIBLE LINK

24

1

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

13Ab-819

SYMPTOM PROCEDURES

ZK603638AA00

C-210

Connector: C-210

ZK603650AA00

A-13

Connector: A-13

ZK603639 AA00

B-114

Connectors: B-113, B-114

B-113

ZK603647 AA00

ETACS-ECU

C-315

Connectors: C-304, C-315

C-304

ZK603649

B-110(B)

Connector: B-110

AA00

ZK603592

ECM

B-11 (GR)

Connector: B-11

AA00

13Ab-820

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

SYMPTOM PROCEDURES

ZK603640

Starter relay

A-27X

Connector: A-27X

AA00



CIRCUIT OPERATION

If the selector lever is moved to "P" or "N" range and
the  ignition  switch  is  turned  to  "START"  position,
battery positive voltage is supplied to starter relay
coil.  With  this,  the  starter  relay  turns  "ON"  the
battery  positive  voltage  is  supplied  to  the  starter
motor (terminal No. 1) from the battery.

COMMENT

Faulty  starting  system  and  the  related  circuit  are
suspected to be the causes.

TROUBLESHOOTING HINTS (The most likely
causes for this case:)

Battery failed

Malfunction of the starter motor relay.

Malfunction of the starter motor.

Open circuit or short circuit in the starting system or
the related circuit or poor contact in the connectors

Malfunction of the transmission range switch.

Malfunction of the ECM



DIAGNOSIS

STEP 1. Using scan tool MB991958, check data list.

ZC501967

AC404789

ZC5019680000

MB991824

MB991827

MB991910

Data link

connector

(1)

Turn the ignition switch to the "ON" position.

(2)

Check the following items of the data list. Refer to Data List
Reference Table P.13Ab-837.

a
.

Item 79: Cranking signal.

(3)

Turn the ignition switch to the "LOCK" (OFF) position.

Q:Is the sensor operating properly?

YES:

 Go to Step 2.

NO:

 Repair harness wire between ETACS-ECU connector

C-304 (terminal No. 15) and ECM connector (terminal No.
105) because of open circuit. Then confirm that the
malfunction symptom is eliminated.

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

13Ab-821

SYMPTOM PROCEDURES

STEP 2. Check harness connector B-110 at transmission
range switch and harness connector B-10 at ECM for
damage.

Q:Is the connector in good condition?

YES:

 Go to Step 3.

NO:

 Repair or replace it. Refer to GROUP 00E, Harness

Connector Inspection P.00E-2. Then confirm that the
malfunction symptom is eliminated.

STEP 3. Check the transmission range switch.
Refer to GROUP 23A, On-vehicle Service - Essential Service -
Transmission Range Switch Continuity Check P.23A-157.

Q:Are there any abnormalities?

YES:

 Repair or replace it. Then confirm that the

malfunction symptom is eliminated.

NO:

 Go to Step 4.

STEP 4. Check for open circuit or short circuit to ground or
harness damage between transmission range switch
connector B-110 and ECM connector B-11.

(1)

Disconnect the connector B-110 and B-11 measure at the
harness side.

82

81 80 79 78 77 76 75 74 73 72

71

94

93 92 91 90 89 88 87 86 85 84 83

99 98 97 96 95

100

101

102

103

104

105

106

112

113

114

109

108

107

110

111

115

116

117

118

ZK603865

B-11 harness
connector:
component side

B-110 harness
connector:
component side

AA00

8

9

3

4

5

1

2

6

7

10

(2)

Measure the resistance between connector B-110 (terminal
No. 10) and connector B-11 (terminal No. 106).

Should be less than 2 ohms.

13Ab-822

MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>

SYMPTOM PROCEDURES
