CALIFORNIA PROPOSITION 65 WARNING

• This product contains or emits chemicals known to the State of California to cause cancer and

birth defects or other reproductive harm.

WARNINGS REGARDING SERVICING OF SUPPLEMENTAL RESTRAINT

SYSTEM (SRS) EQUIPPED VEHICLES

• Improper service or maintenance of any component of the SRS, or any SRS-related component,

can lead to personal injury or death to service personnel (from inadvertent firing of the air bag)
or to the driver and passenger (from rendering the SRS inoperative).

• If it is possible that the SRS components are subjected to heat over 93 ° C (200 ° F) in baking or

in drying after painting, remove the SRS components [air bag module (driver's side and front
passenger's side), SRS-ECU, clock spring, side impact sensor, front seat assembly (side air bag
module)] beforehand.

• Service or maintenance of any SRS component or SRS-related component must be performed

only at an authorized MITSUBISHI dealer.

• MITSUBISHI dealer personnel must thoroughly review this manual, and especially its GROUP

52B, Supplemental Restraint System (SRS), before beginning any service or maintenance of any
component of the SRS or any SRS-related component.

NOTE
Section titles with the asterisks (*) in the table of contents in each group indicate operations requiring
warnings.

WARNING

WARNING

MITSUBISHI PUBLICATION COMMENT FORM

Use this form to advise us of any errors you might find in this publication. We also welcome your
suggestions that might help us improve Mitsubishi publications.

Publication that contains error: __________________________________________________________

Page number where the error appears:____________________________________________________

Figure number where the error appears:___________________________________________________

Vehicle application and system identification: _______________________________________________

Describe, in detail, the error found or your suggestion. Please attach additional pages as necessary.

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

___________________________________________________________________________________

Dealer ___________________________________ Dealer Code________________________________

From: Name_________________________________________________________________________

City/Town____________________________ State________________ Zip Code______________

Signature ____________________________ Date ________________ Phone________________

Mail To: Mitsubishi Motors North America, Inc.

6400 Katella Avenue
P.O. Box 6400
Cypress, California 90630-0064
Attn: Technical Information Dept.

Fax to: Mitsubishi Motors North America, Inc.

Technical Information Dept.
(714) 373-1021

GROUP INDEX

36

Parking Brakes . . . . . . . . . . . . . . . . .

37

Steering . . . . . . . . . . . . . . . . . . . . . . .

42

Body. . . . . . . . . . . . . . . . . . . . . . . . . .

51

Exterior  . . . . . . . . . . . . . . . . . . . . . . .

52

 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

54

Chassis Electrical . . . . . . . . . . . . . . .

55

 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

70

Component Locations . . . . . . . . . . .

80

 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

90

Circuit Diagrams . . . . . . . . . . . . . . . .

NOTE:
For the information on all service manual
groups not listed above, please refer to
Volume

 1

and

 2.

Alphabetical Index  . . . . . . . . . . . . . .

2007

MITSUBISHI

OUTLANDER

SERVICE MANUAL

Volume 3

FOREWORD

This service manual is subdivided into various group

categories. Each section contains diagnostic,

disassembly, repair, and installation procedures,

along with complete specifications and tightening

references. Use of this manual will aid in properly

performing any service necessary to maintain or

restore the high levels of performance and reliability

designed into this Mitsubishi vehicle.

This manual is designed for use with the 2007

OUTLANDER Service Manual Volume

 1, 2

and the

2007 OUTLANDER Body Repair Manual

 to provide

complete service information for the 2007 OUTLAND-

ER.

When reference is made in this manual to a brand

name, number, or specific tool, an equivalent product

may be used in place of the recommended item. All

information, illustrations and specifications contained

in this manual are based on the latest product

information available at the time of publication

approval. The right is reserved to make changes at

any time without notice.

No part of this publication may be reproduced, stored in any retrieval

system of transmitted, in any form or by any means, including but not

limited to electronic, mechanical photocopying, recording or otherwise,

without the prior written permission of Mitsubishi Motors Corporation.

2006 Mitsubishi Motors Corporation

All Rights, Reserved

Printed in USA

MS

CD-007B-2007(3/3)

Interior and Supplemental

Restraint System (SRS) . . . . . . . . . .

Heater, Air Conditioning

and Ventilation  . . . . . . . . . . . . . . . . .

Configuration Diagrams

and Splice Locations  . . . . . . . . . . . .

Proper service methods and repair procedures are necessary for the safe,
reliable operation of all motor vehicles as well as the personal safety of the
person doing the repair. There are many types of procedures, techniques,
tools, and parts for servicing vehicles, as well as differences in the skills of
the people doing the work. This manual cannot give advice or precautions for
every possible situation. Because of this, anyone who does not follow the
instructions in this manual must first make sure that the choice of methods,
tools, or parts will not cause damage to the vehicle or injury to the person
doing the work. The following list contains general precautions that should
always be followed while working on a vehicle.

• Always wear safety glasses for eye protection.

• Use safety stands whenever a procedure requires work under the

vehicle.

• Be sure the ignition switch is always "off" unless otherwise specified by

a procedure.

• Set the parking brake when working on a vehicle.

• Operate the engine only in a well-ventilated area.

• Keep clear of moving parts when the engine is running.

• To prevent serious burns, avoid contact with hot metal parts such as the

radiator, exhaust manifold, tail pipe, catalytic converter and muffler.

• Do not smoke while working on or near a vehicle.

WARNING
